116. Below Right Side of Dash (Manual A/C)

BLOWER
MOTOR

BLOWER
RESISTOR

117. Behind Passenger’s Dashboard Lower Cover

EVAPORATOR
TEMPERATURE
SENSOR
CONNECTOR
(2-GRY)

RADIATOR
FAN CONTROL
MODULE (V6)

118. Behind Passenger’s Dashboard Lower Cover

PASSENGER’S
MULTIPLEX
CONTROL UNIT

G504

119. Behind Glove Box

BLOWER
MOTOR
HIGH RELAY

RECIRCULATION
CONTROL
MOTOR
