Ford Festiva. Instruction - part 62

STEERING COLUMN TROUBLE SHOOTING

BASIC STEERING COLUMN TROUBLE SHOOTING CHART

PUMP article

Excessive internal gear leakage

See POWER STEERING

PUMP article

Flange rubs against gear adjust plug

See STEERING COLUMN

article

Loose pump belt

Adjust or replace if necessary

Low fluid level

Check and add proper amount

of fluid

Engine idle too low

Adjust to correct setting

Steering gear-to-column misaligned

See STEERING COLUMN

article

No Power, Left Turn

Left turn reaction seal "O" ring worn

See POWER STEERING

GEAR article

Left turn reaction seal damaged/missing

See POWER STEERING

GEAR article

Cylinder head "O" ring damaged

See POWER STEERING

PUMP article

No Power, Right Turns

Column pot coupling bottomed

See STEERING COLUMN

article

Right turn reaction seal "O" ring worn

See POWER STEERING

GEAR article

Right turn reaction seal damaged

See POWER STEERING

GEAR article

Internal leakage through piston end plug

See POWER STEERING

GEAR article

Internal leakage through side plugs

See POWER STEERING

GEAR article

Lack of Effort in Turning

Left and/or right reaction seal sticking in cylinder head

Replace, see POWER

STEERING GEAR article

Wanders to One Side

Front end alignment incorrect

See WHEEL ALIGNMENT

article

Unbalanced steering gear valve

See POWER STEERING

GEAR article

Low Pressure Due to Steering Pump

Flow control valve stuck or inoperative

See POWER STEERING

PUMP article

Pressure plate not flat against cam ring

See POWER STEERING

PUMP article

Extreme wear of cam ring

Replace and check

adjustments

Scored plate, thrust plate or rotor

See POWER STEERING

PUMP article

Vanes not installed properly

See POWER STEERING

PUMP article

Vanes sticking in rotor slots

See POWER STEERING

PUMP article

Cracked/broken thrust or pressure plate

See POWER STEERING

PUMP article

NOTE:

This is GENERAL information. This article is not intended to be specific to any unique situation or
individual vehicle configuration. The purpose of this Trouble Shooting information is to provide a list
of common causes to problem symptoms. For model-specific Trouble Shooting, refer to SUBJECT,
DIAGNOSTIC, or TESTING articles available in the section(s) you are accessing.

CONDITION & POSSIBLE CAUSE

CORRECTION

Noise in Steering

Coupling pulled apart

See STEERING COLUMNS

article

Column not correctly aligned

See STEERING COLUMNS

article

Broken lower joint

Replace joint

Horn contact ring not

See STEERING COLUMN

article

Bearing not lubricated

See STEERING COLUMN

article

Shaft snap ring not properly seated

Reseat or replace snap ring

Plastic spherical joint not lubricated

See STEERING COLUMN

SUSPENSION TROUBLE SHOOTING

BASIC SUSPENSION TROUBLE SHOOTING CHART

article

Shroud or housing loose

Tighten holding screws

Lock plate retaining ring not seated

See STEERING COLUMN

article

Loose sight shield

Tighten holding screws

High Steering Shaft Effort

Column assembly misaligned

See STEERING COLUMN

article

Improperly installed dust shield

Adjust or replace

Tight steering universal joint

See STEERING COLUMN

article

High Shift Effort

Column is out of alignment

See STEERING COLUMN

article

Improperly installed dust shield

Adjust or replace

Seals or bearings not lubricated

See STEERING COLUMNS

article

Mounting bracket screws too long

Replace with new shorter

screws

Burrs on shift tube

Remove burrs or replace tube

Lower bowl bearing assembled wrong

See STEERING COLUMN

article

Shift tube bent or broken

Replace as necessary

Improper adjustment of shift levers

See STEERING COLUMN

article

Improper Trans. Shifting

Sheared shift tube joint

Replace as necessary

Sheared lower shaft lever

Replace as necessary

Improper shift lever adjustment

See STEERING COLUMN

article

Improper gate plate adjustment

See STEERING COLUMN

article

Excess Play in Column

Instrument panel bracket bolts loose

Tighten bolts and check

bracket

Broken weld nut on jacket

See STEERING COLUMN

article

Instrument bracket capsule sheared

See STEERING COLUMN

article

Column bracket/jacket bolts loose

Tighten bolts and check

bracket

Steering Locks in Gear

Release lever mechanism

See STEERING COLUMN

article

NOTE:

CONDITION & POSSIBLE CAUSE

CORRECTION

Front End Noise

Loose or worn wheel

See Wheel Bearing

Adjustment in SUSPENSION

Worn shocks or shock mountings

Replace struts or strut

mountings

Worn struts or strut mountings

Replace struts or strut

mountings

Loose or worn lower control arm

See SUSPENSION

Loose steering gear-to-frame bolts

See STEERING

Worn control arm bushings

See SUSPENSION

Ball joints not lubricated

Lubricate ball joints & see

Ball Joint Checking in

SUSPENSION

Front Wheel Shake, Shimmy, or Vibration

Tires or wheels out of balance

Check tire balance

Incorrect wheel alignment

See WHEEL ALIGNMENT

Drive shaft unbalanced

Check drive shaft balance

Loose or worn wheel bearings

See WHEEL ALIGNMENT

Loose or worn tie rod ends

See SUSPENSION

WHEEL ALIGNMENT TROUBLE SHOOTING

BASIC WHEEL ALIGNMENT TROUBLE SHOOTING CHART

Worn upper ball joints

See Ball Joint Checking in

SUSPENSION

Worn shock absorbers

Replace shock absorbers

Worn strut bushings

Replace strut bushings

Car Pulls to One Side

Mismatched or uneven tires

Check tire condition

Broken or sagging springs

See SUSPENSION

Loose or worn strut bushings

See SUSPENSION

Improper wheel alignment

See WHEEL ALIGNMENT

Improper rear axle alignment

Check rear axle alignment

Power steering gear unbalanced

See STEERING

Front brakes dragging

See BRAKES

Abnormal Tire Wear

Unbalanced tires

Check tire balance & rotation

Sagging or broken springs

See SUSPENSION

Incorrect front end alignment

See WHEEL ALIGNMENT

Faulty shock absorbers

Replace chock absorbers

Scuffed Tires

Toe-In incorrect

See WHEEL ALIGNMENT

Suspension arm bent or twisted

See appropriate

SUSPENSION article

Springs Bottom or Sag

Bent or broken springs

See SUSPENSION

Leaking or worn shock absorbers

Replace shock absorbers

Frame misalignment

Check frame for damage

Spring Noises

Loose "U" Bolts

See SUSPENSION

Loose or worn bushings

See SUSPENSION

Worn or missing interliners

See SUSPENSION

Shock Absorber Noise

Loose shock mountings

Check & tighten mountings

Worn bushings

Replace bushings

Air in system

Bleed air from system

Undercoating on shocks

Remove undercoating

Car Leans or Sways on Corners

Loose stabilizer bar

See SUSPENSION

Faulty shocks or mountings

Replace shocks or mountings

Broken or sagging springs

See SUSPENSION

Shock Absorbers Leaking

Worn seals or reservoir tube crimped

See SUSPENSION

Broken Springs

Loose "U" bolts

See SUSPENSION

Inoperative shock absorbers

Replace shock absorbers

NOTE:

CONDITION & POSSIBLE CAUSE

CORRECTION

Premature Tire Wear

Improper tire inflation

Check tire pressure

Front alignment out of tolerance

See ALIGNMENT SPECS in

WHEEL ALIGNMENT

section

Suspension components worn

See SUSPENSION section

Steering system components worn

See STEERING section

Improper standing height

See WHEEL ALIGNMENT

Uneven or sagging springs

See SUSPENSION section

Bent wheel

See WHEEL ALIGNMENT

Improper torsion bar adjustment

See SUSPENSION section

Loose or worn wheel bearings

See WHEEL BEARING ADJ.

in SUSPENSION section

Worn or defective shock

Replace shock absorbers

Tires out of balance

Check tire balance

Pulls to One Side

Improper tire inflation

Check tire pressure

Brake dragging

See BRAKE section

Mismatched tires

See WHEEL ALIGNMENT

Broken or sagging spring

See SUSPENSION section

Broken torsion bar

See SUSPENSION section

Power steering valve not centered

See STEERING section

Front alignment out of tolerance

See WHEEL ALIGNMENT

section

Defective wheel bearing

See WHEEL BEARINGS in

SUSPENSION section

Uneven sway bar links

See SUSPENSION section

Frame bent

Check for frame damage

Steering system bushing worn

See STEERING section

Hard Steering

Idler arm bushing too tight

See STEERING LINKAGE in

STEERING section

Ball joint tight or seized

See SUSPENSION section

Steering linkage too tight

See STEERING LINKAGE in

STEERING section

Power steering fluid low

Add proper amount of fluid

Power steering drive belt loose

See STEERING section

Power steering pump defective

See STEERING section

Steering gear out of adjustment

See STEERING section

Incorrect wheel alignment

See WHEEL ALIGNMENT

Damaged steering gear

See STEERING section

Damaged suspension

See SUSPENSION section

Bent steering knuckle or supports

See SUSPENSION section

Vehicle "Wanders"

Strut rod or control arm bushing worn

See SUSPENSION section

Loose or worn wheel bearings

See WHEEL BEARINGS in

SUSPENSION section

Improper tire inflation

Check tire pressure

Stabilizer bar missing or defective

See SUSPENSION section

Wheel alignment out of tolerance

See Adjustment in WHEEL

ALIGNMENT section

Broken spring

See SUSPENSION section

Defective shock absorber

Replace shock absorbers

Worn steering & suspension components

See SUSPENSION section

Front End Shimmy

Tire out of balance/round

Check tire balance

Excessive wheel runout

See WHEEL ALIGNMENT

Insufficient or improper caster

See WHEEL ALIGNMENT

section

Worn suspension or steering components

See SUSPENSION section

Defective shock absorbers

Replace shock absorber

Wheel bearings worn or loose

See WHEEL BEARING ADJ.

in SUSPENSION section

Power steering reaction Bracket loose

See STEERING section

Steering gear box (rack) mounting loose

See STEERING section

Steering gear adjustment loose

See STEERING section

Worn spherical joints

See SUSPENSION section

Toe-In Not Adjustable

Lower control arm bent

See SUSPENSION section

Frame bent

Check frame for damage

Camber Not Adjustable

Control arm bent

See SUSPENSION section

Frame bent

Check frame for damage

Hub & bearing not seated properly

See SUSPENSION section

Article GUID: A00027342
