DRIVE AXLE (RWD) TROUBLE SHOOTING FWD AXLE SHAFTS & CV JOINTS TROUBLE SHOOTING BASIC FWD AXLE SHAFTS & CV JOINTS TROUBLE SHOOTING CHART STEERING & SUSPENSION MANUAL STEERING GEAR TROUBLE SHOOTING BASIC MANUAL STEERING GEAR TROUBLE SHOOTING CHART CONDITION & POSSIBLE CAUSE CORRECTION Knocking or Clunking Differential Side Gear Clearance Check Clearance Worn Pinion Shaft Replace Pinion Shaft Axle Shaft End Play Check End Play Missing Gear Teeth Check Differential/Replace Gear Wrong Axle Backlash Check Backlash Misaligned Driveline Realign Driveline Clinking During Engagement Side Gear Clearance Check Clearance Ring and Pinion Backlash Check Backlash Worn/Loose Pinion Shaft Replace Shaft/Bearing Bad "U" Joint Replace "U" Joint Sticking Slip Yoke Lube Slip Yoke Broken Rear Axle Mount Replace Mount Loose Drive Shaft Flange Check Flange Click/Chatter On Turns Differential Side Gear Clearance Check Clearance Wrong Turn On Plates (1) Replace Clutch Plates Wrong Differential Lubricant (1) Change Lubricant Knock Or Click Flat Spot on Rear Wheel Bearing Replace Wheel Bearing Low Vibration At All Speeds Faulty Wheel Bearing Replace Wheel Bearing Faulty "U" Joint Replace "U" Joint Faulty Drive Shaft Balance Drive Shaft Faulty Companion Flange Replace Flange Faulty Slip Yoke Flange Replace Flange (1) Limited slip differential only. NOTE: This is GENERAL information. This article is not intended to be specific to any unique situation or CONDITION POSSIBLE CAUSE Grease Leaks CV boot torn or cracked Clicking Noise on Cornering Damaged outer CV Clunk Noise on Acceleration Damaged inner CV Vibration or Shudder on Acceleration Sticking, damaged or worn CV Misalignment or spring height NOTE: This is GENERAL information. This article is not intended to be specific to any unique situation or CONDITION & POSSIBLE CAUSE CORRECTION Rattle or Chucking Noise in Rack and Pinion Rack and pinion mounting bracket loose Tighten all mounting bolts Lack of/or incorrect lubricant Correct as necessary Steering gear mounting bolts loose Tighten all mounting bolts Excessive Play Front wheel bearing improperly adjusted See FRONT SUSPENSION article Loose or worn steering linkage See STEERING LINKAGE article Loose or worn steering gear shift See MANUAL STEERING GEAR article Steering arm loose on gear shaft See MANUAL STEERING GEAR article Steering gear housing bolts loose Tighten all mounting bolts |
