*NO RESPONSE FROM FCM (CONTINUED) 7. (F202) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN AT FCM PDM CONNECTOR Turn the ignition on. Using a 12-volt test light connected to ground, check the (F202) Fused Does the test light illuminate brightly? Yes >> Replace and program the Front Control Module in accor- dance with the service information. Perform BODY VERIFICATION TEST - VER 1. No >> Repair the (F202) Fused Ignition Switch Output circuit for an open. Inspect the connector for damage. Perform BODY VERIFICATION TEST - VER 1. HB ELECTRONIC CONTROL MODULES - ELECTRICAL DIAGNOSTICS 8E - 141 |
