7 LF45/55 series Removal and installation FRONT AXLE, F60 3-17 11. Fit the king pin (5) in the swivel axle using a copper punch. Note: 12. Position the swivel axle underneath the press. Note: 13. Ensure that the swivel axle, the thrust bearing and the axle end are aligned. ;; ;; ;;; ;; ;;; ;; ;; ;; ; ;; ; ;; ; ;; ;; ; ; ;;; ;; ;; ; S 700 729 8 4 A 6 5 11 12 14. Press the king pin into the swivel axle with the specified force, see “Technical data”. 15. Check the O-rings of the covers (2 and 9). 16. Fit the covers and the circlips (1 and 10). Note: 17. Thoroughly lubricate the swivel axle (12) while it is unloaded. 18. Check that the swivel axle operates smoothly and is not getting stuck anywhere. 19. Fit the wheel speed sensor. 20. Fit the compact bearing housing 21. Fit the track rod. 22. Install the axle assembly. 23. Check the ABS system for correct operation. ; ;;; ;;; ;;; ;;; ;;; ;;; ;;; ;;; ;; ; ; ; ; ;; ;;;; ;; ;; ;; ;; ; ; ;; ;; ;; ;; ;; ;; ;; ;; ; ;; ; ;; ;; ; ;; ;; ;;;; ;; ;; ;; ;; ;; ; ; ; ; ; ; ; ; ; ; ; ; ; S 700 659 1 2 7 3 5 6 8 9 10 11 12 4 7 ᓻ 200322 |
