© 200505 1-1 BE engine TECHNICAL DATA ΛΦ45/55 series 2 0 1. BE ENGINE 1.1 GENERAL Engine types General specifications Compression ratio Intake manifold Exhaust manifold Cold engine A cold engine is an engine which, having reached operating temperature, has been allowed to cool down for at least six hours. Warm engine A warm engine is an engine which, having reached operating temperature, has been at a standstill for not more than thirty minutes. Direction of rotation of the engine The direction of rotation of the engine is clockwise, as seen from the vibration damper end. First cylinder of the engine The first cylinder of the engine is the cylinder at the vibration damper end of the engine. Left-hand and right-hand side of the engine The left-hand side of the engine is the side where the air compressor and electronic unit are mounted. The right-hand side of the engine is the side where the turbocharger and oil filter are mounted. Coding BE 99 C Environmental standard Euro 3 (C) Number of cylinders 4 cylinders in line Valves 4 per cylinder Bore x stroke 102 x 120 mm Cubic capacity 3.9 litres Weight approx. 391 kg Cooling fluid Air inlet system Turbocharger intercooling Fuel injection direct Injection sequence 1-3-4-2 BE 99 C 17.0 : 1 BE 110 C 17.0 : 1 BE 123 C 17.3 : 1 ENGINE TYPE P (kW) at rpm M (Nm) at rpm BE 99 C 99 at 2500 500 at 1200 - 1600 BE 110 C 110 at 2500 550 at 1250 - 1600 BE 123 C 123 at 2500 600 at 1200 - 1600 Fit the intake manifold using sealant Loctite Ultra Grey Maximum flatness deviation 0.20 mm |
