© 200505 1-5 BE engine TECHNICAL DATA ΛΦ45/55 series 2 0 Flywheel/starter ring gear Flywheel housing Vibration damper M201199 A B Radial run-out, measured on the inside of the flywheel outer edge (A) max. 0.127 mm Axial deviation, measured on the flywheel outer edge (B) max. 0.406 mm Heat starter ring gear (max. 20 min.) max. 125 C Fit flywheel housing using sealant Loctite 5205 Difference in thickness at 4 places must not exceed 6.35 mm |
