Diagnostic system: reading out fault memory and activating systems

Installing rain sensor

3925

92 15 19 Removing and installing wiper motor - as of
MY 2005

- Preliminary work on wiper motor
- Removing wiper motor
- Installing wiper motor
- Reworking wiper motor

Preliminary work on wiper motor

Preliminary work on wiper motor

Disconnect the battery and cover terminal or battery. → 271000  Work instructions after disconnecting the
battery
Left plenum chamber cover → 852219 Removing and installing cover - chapter on "Removing"

Removing wiper motor

Removing wiper motor

3926

Removing wiper link drive

1. Unscrew the fastening nut -1- for the wiper link drive and remove the

drive.

2. Unscrew the three fastening screws -2- for the wiper motor and the fastening screw -3- for the wiper

link.

Removing wiper motor in a downward direction

3. Carefully raise the wiper link and remove the wiper motor downwards.

4. Unlock the electric connector a and pull it out of the wiper motor.

Installing wiper motor

Installing wiper motor

Positioning wiper motor from below

1. Carefully raise the wiper link and position the wiper motor from

below.

2. Push electrical connector onto wiper motor until it is felt to engage.

Diagnostic system: reading out fault memory and activating systems

Removing wiper motor

3927

Screwing down wiper motor to wiper link

3. Secure the wiper motor with the three fastening screws -2- to the wiper link. → Tightening torque: 6 ftlb.

4. Screw down the fastening screw -3- for the wiper link. → Tightening torque: 7.5 ftlb.

5. Connect battery, ignition on, and actuate wiper

motor.

Installation position for wiper motor drive

6. Allow wiper motor to run in parking position. Place the link on the drive on the wiper motor. Place

fastening nuts -1- . The installation position of the link is identified by a 0 marking (parking position) on
the console.

7. If the position -0- matches, then screw down the fastening nut -1- . → Tightening torque: 13 ftlb.

8. Connect the battery .

9. Switch on the wiper motor and check the wiper position.

Reworking wiper motor

Diagnostic system: reading out fault memory and activating systems

Installing wiper motor

3928
