92 12 19 Removing and installing rain sensor - as of
MY 2005

- Removing rain sensor
- Installing rain sensor

Removing rain sensor

Removing rain sensor

Note

An adhesive pad must be used when reinstalling the rain sensor. See PET, main group 9, sub-group
04.

•

When fitting the adhesive pad, make sure there is no air trapped between the windscreen and the
adhesive pad or between the adhesive pad and the rain sensor.

•

When installing the adhesive pad, the temperature of the windscreen, rain sensor and adhesive pad
must be approx 20 °C. Carefully heat the windscreen with a hot-air gun for example.

•

Do not touch the adhesive surface of the sensor with your fingers.

•

If the sensor is new, remove the protection cap before sticking the sensor on to the windscreen.

•

When sticking on a new sensor, make sure that no air pockets are caught between the gel and the
windscreen. Air pockets could impair the function of the sensor.

•

Sensor, orientation lights, wires and wiring ducts are spare parts.

•

Limited functionality of the rain sensor if the following points are not observed: → Please observe note
"An adhesive pad must be used when reinstalling the rain sensor. See PET, main group 9, sub-group 04."

3917

Removing roof console

1. Unclip the two covers on the roof console and unscrew both fastening screws

-1-

 .

Wire routing

2. Disengage holder -2- for the wire -arrow- and pull wire forward behind the roof liner.

Disconnecting plug connection

3. Release and pull electrical plug apart -3- .

Removing cover of rain sensor

Diagnostic system: reading out fault memory and activating systems

Removing rain sensor

3918

4. Carefully unclip the cover -1- from the rain sensor from above using a narrow screwdriver.

Removing orientation lights

5. Remove orientation lights -2- .

Disconnecting plug connection

6. Carefully pull the plug connection -3- out of the holder and pull it apart.

Pushing mirror down from mirror holder

7. Fold mirror downwards -4- and push down from the front windscreen bracket.

Diagnostic system: reading out fault memory and activating systems

Removing rain sensor

3919

Unclipping rain sensor holder

8. Carefully unclip holder from rain sensor at the top, bottom left and

right.

Removing rain sensor from windscreen

9. Slowly remove rain sensor -6- from the windscreen.

Pulling off adhesive pad

10. If the rain sensor is to be reinstalled, then slowly pull the adhesive pad -7- off the rain sensor.

Installing rain sensor

Installing rain sensor

Note

An adhesive pad must be used when reinstalling the rain sensor. See PET, main group 9, sub-group
04.

•

When fitting the adhesive pad, make sure there is no air trapped between the windscreen and the
adhesive pad or between the adhesive pad and the rain sensor.

•

Diagnostic system: reading out fault memory and activating systems

 Installing rain sensor
