Removing collar

2. Insert a plastic wedge between the backrest cover -1- and the collar -2- and unclip collar.

Disengaging cover for backrest

3. Press out cover for backrest -1- from the cushion carrier -2- lower left and right using a screwdriver -3- .

Loosening cover piping

4. Press out cover piping -1- right and left from backrest frame

-2-

 .

5. Remove side airbag. → 696319 Removing and installing side airbag - section on "Removing"

Diagnostic system: reading out fault memory and activating systems

Removing cover for front backrest

3381

Loosening connection at frame for side airbag

6. Slightly loosen connection of backrest cover -1- from frame for side airbag -2- with a screwdriver -3- and

pull out all around by hand.

Loosening cover for rear backrest

7. Press out cover for backrest -1- from the cushion carrier -2- lower left and right using a screwdriver -3-

-Arrows A-

 .

8. Pull out cover for backrest -1- all around by hand from the rear of the cushion carrier -2- -Arrows B- .

Folding cover piping at the sides

9. Fold cover piping -1- at the sides right and left in direction of arrow.

Diagnostic system: reading out fault memory and activating systems

Removing cover for front backrest

3382

Installing cover for backrest

10. Press plastic strip -2- on cover for backrest -1- out of the fixing clips -3-

.

Removing cover for backrest

11. Remove cover for backrest -1- .

Removing guide for seat belt

Loosening guide for seat belt at top

1.

Diagnostic system: reading out fault memory and activating systems

Removing guide for seat belt

3383

Remove guide for seat belt -1- at top -Arrow
A-

 .

2. Unscrew fastening screw -2- and remove push button -3- -Arrow B- .

Loosening guide for seat belt at bottom

3. Press out cap -2- and unscrew fastening screw -3- with spacer

-4-

 .

4. Remove guide for seat belt -1- and sleeve -5- .

Removing cover for front backrest

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing cover for front backrest
