Porshe 911 (997). Manual - part 502

1. Remove convertible top lock. → 611919 Removing and installing convertible top lock - chapter on

"Removing"

Unscrewing fastening screws

2. Unscrew fastening screws at the left and right.

Pulling off front clamping rail

3. Pull off sewn-on clamping rail of headliner at roof frame 1 front left and right.

Diagnostic system: reading out fault memory and activating systems

Removing front inner lining of convertible top

2165

Pulling off the rear clamping rail

4. Pull off sewn-on clamping rail of headliner at roof frame 1 rear left and

right.

Loosen connection of convertible-top inner lining to roof frame

5. Unscrew expander nuts -1- from covering strips -2- and roof frame 1 at rear.

Diagnostic system: reading out fault memory and activating systems

Removing front inner lining of convertible top

2166

Removing clamping rail from main folding top bow

6. Unscrew fastening screws -1- at the left and right. Remove clamping rail connection -2- from the main

folding top bow.

7. Open Velcro fastener of convertible-top inner lining on left and right.

Opening Velcro fastener

8. Open Velcro fastener of headliner on the corner bow.

Diagnostic system: reading out fault memory and activating systems

Removing front inner lining of convertible top

2167

Removing bracing straps

9. Unscrew fastening screw -1- from bracing straps -2 and 3- .

Removing corner bow connection

10. Using a plastic spatula, press out the connection strips -1- of the convertible-top inner lining from the rear

groove of the corner bow. Detach convertible-top inner lining connection -2- from the front groove of the
corner bow.

Removing inner lining of convertible top at rear

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing inner lining of convertible top at rear

2168
