Installing latch at front Installing front lock Pushing on connector for microswitch 1. Push on connector -1- for roof microswitch -2- -arrow- until it is heard to engage. 2. Push the electric connecting lines for the interior light and the garage door opener control unit from above through the assembly openings on the front lock. Installing front lock Note When fitting the front lock make sure the electric connecting lines are laid so that they are not trapped. 3. Mount front lock -1- from below -arrow- on windscreen frame. 4. Tighten front lock with the two fastening screws -2- . → Tightening torque: 7.5 ftlb. Subsequent work Diagnostic system: reading out fault memory and activating systems Installing latch at front 2161 |
