REAR SUSPENSION/TRACK/TRACTION

7.15

REAR SUSPENSION SHOCKS Fox

t

Shock Specifications

Fox

t

FRONT TRACK SHOCKS

Shock PN

Body

Length (in)

Shaft

Length (in)

Max.

Length (in)

Max.

Travel (in)

IFP Depth (in)

Shaft Part #

7041294

5.050

5.350

10.470

2.850

0.544

1500040

7041386

8.955

9.125

18.150

6.375

1.140

1500068

7041402

5.430

5.570

11.070

3.070

0.586

1500153

7041413

5.050

5.350

10.470

2.850

0.544

1500040

7041493

5.430

5.570

11.070

3.070

0.590

1500153

7041507

5.330

6.400

11.060

3.150

4.570

1500076

7041584

5.430

5.570

11.070

3.070

0.586

1500153

7041589

5.430

5.570

11.070

3.070

0.586

1500153

7041641

5.330

5.570

10.970

3.070

0.600

1500153

7041642

5.330

5.570

10.970

3.070

0.600

1500153

7041706

5.330

5.570

10.850

3.070

0.600

1500153

7041735

5.330

5.570

10.850

3.070

0.600

1500153

7041779

5.330

5.570

10.850

3.070

0.600

1500153

7041808

5.330

5.570

10.850

3.070

0.600

1500153

7041810

5.330

5.570

10.850

3.070

0.600

1500153

7041905

6.150

6.250

12.10

3.500

0.750

1500321

7041907

6.150

6.250

12.10

3.500

0.750

1500321

7041847

6.150

6.250

12.10

3.500

0.750

1500321

7041893

6.000

6.150

12.22

3.650

0.690

1500247

7041951

5.330

5.570

10.85

3.070

0.600

1500153

REAR SUSPENSION/TRACK/TRACTION

REAR SUSPENSION/TRACK/TRACTION

7.16

REAR SUSPENSION SHOCKS Fox

t

Shock Specifications

Fox

t

REAR TRACK SHOCKS

Shock PN

Body

Length (in)

Shaft

Length (in)

Max.

Length (in)

Max.

Travel (in)

IFP Depth (in)

Shaft Part #

7041293

7.440

7.450

14.523

4.700

0.835

1500152

7041345

7.440

7.450

14.523

4.700

0.835

1500152

7041347

7.440

7.450

14.523

4.700

0.835

1500152

7041387

5.850

6.350

12.320

3.650

0.633

1500076

7041403

6.825

6.850

13.560

4.350

0.795

1500133

7041444

7.440

7.450

14.523

4.700

0.835

1500152

7041480

5.850

6.350

12.320

3.650

0.630

1500076

7041492

7.440

7.450

14.520

4.700

0.835

1500152

7041585

7.440

7.450

14.523

4.700

0.835

1500152

7041588

7.440

7.450

14.523

4.700

0.835

1500152

7041595

7.440

7.450

14.523

4.700

0.835

1500152

7041599

7.440

7.450

14.520

4.700

1.500

1500152

7041695

7.440

7.450

14.523

4.700

0.835

1500152

7041707

7.440

7.450

14.520

4.700

1.500

1500152

7041728

7.440

7.450

14.523

4.700

0.835

1500152

7041751

7.440

7.450

14.523

4.700

0.835

1500152

7041809

7.440

7.450

14.520

4.700

0.835

1500035

7041906

8.665

8.350

16.650

5.600

1.600

1500322

7041894

7.285

7.340

14.49

4.84

.870

1500453

* IFP depth for limited build 1996 440 XCR SP with handlebar shock adjuster=4.570

〉

REAR SUSPENSION/TRACK/TRACTION

REAR SUSPENSION/TRACK/TRACTION

7.17

Front Track Shock - 2001 XCF SP - EDGE

ARVIN

t

Front Track Shock

PN 7041992

Immulsion shock (no IFP)

7C

1.250 x .010

6C

.800 x .012

5C

.900 x .015

4C

1.000 x .012

3C

1.100 x .012

2C

1.250 x .012

1C

1.300 x .012

0.059 Orifice

1R

1.250 x .010

2R

1.100 x .010

3R

1.000 x .012

4R

.900 x .010

5R

.800 x .010

11.98

〉

Extended

8.24

〉

Compressed

with upper spring
retainer installed

Shock Design Details

Travel

3.74

〉

Extended Length

11.98

〉

Compressed Length

8.24

〉

Nitrogen Pressure

200 psi

REAR SUSPENSION/TRACK/TRACTION

REAR SUSPENSION/TRACK/TRACTION

7.18

Front Track Shock - 2001 440/600 Edge Pro X

ARVIN

t

Front Track Shock PN 7041973

8C

.800 x .015

7C

.1.000 x .015

6C

.1.300 x .010

5C

.1.000 x .015

4C

1.100 x .010

3C

1.250 x .010

2C

.700 x .004

1C

1.300 x .012

0.070 Orifice

1R

1.250 x .008

2R

1.100 x .008

3R

1.000 x .010

4R

.900 x .012

5R

.800 x .012

6R

.700 x .012

11.99

〉

Extended

8.24

〉

Compressed

Shock Design Details

Travel

3.75

〉

Extended Length

11.99

〉

Compressed Length

8.24

〉

Nitrogen Pressure

200 psi

IFP Depth

1.60”

IFP Depth
