DRIVER SUPPORT

356

City Safety messages

A number of messages related to City Safety
may be displayed in the instrument panel.

Some examples of symbols and messages are shown in the table below.

Message

Meaning

City Safety

Automatic intervention

When City Safety is braking or has activated the automatic braking function, one or more symbols may illuminate in
the instrument panel and a text message may be displayed.

City Safety

Reduced functionality Service
required

The system is not functioning as intended. Contact a workshop

‒ an authorized Volvo workshop is recommended.

A text message can be erased by briefly pressing
the

button in the center of the right-side

steering wheel keypad.

If the message persists: Contact a workshop

‒ an

authorized Volvo workshop is recommended.

Related information

•

City Safety™ (p. 344)

DRIVER SUPPORT

357

Rear Collision Warning

The Rear Collision Warning (RCW) function can
help the driver avoid rear-end collisions from
vehicles approaching from behind.

RCW is automatically activated each time the
engine is started.

RCW can warn the driver of a potential collision
with vehicles approaching from behind by rapidly
flashing the turn signals.

If, at a speed below 30 km/h (20 mph), the RCW
function detects that the car is in danger of being
hit from behind, the seatbelt tensioners may ten-
sion the front seatbelts and activate the Whiplash
Protection System safety system.

Immediately before a collision from behind, RCW
may also activate the foot brake in order to
reduce the forward acceleration of the car during
the collision. However, the brakes will only be
applied if your vehicle is stationary. The brakes
will be immediately released if the accelerator
pedal is depressed.

Related information

•

Rear Collision Warning limitations (p. 357)

•

Whiplash Protection System (p. 46)

Rear Collision Warning limitations

In some situations, it may be difficult for RCW to
warn the driver of a collision risk.

This may be the case if:

•

the vehicle approaching from the rear is
detected at a late stage

•

the vehicle approaching from the rear
changes lanes at a late stage

•

the vehicle approaching from the rear is mov-
ing at a speed above 80 km/h (50 mph)

•

a trailer, bicycle holder or similar is con-
nected to the vehicle's electrical system - the
RCW function will then be automatically
deactivated.

NOTE

In certain markets RCW does not warn with
the direction indicators due to local traffic
regulations – in such cases, that part of the
function is deactivated.

NOTE

The warning with direction indicators for Rear
Collision Warning is deactivated if the colli-
sion warning distance in the City Safety func-
tion is set to the lowest level "

Late

The seat belt tensioning and braking func-
tions remain active.

Related information

•

Rear Collision Warning (p. 357)

DRIVER SUPPORT

* Option/accessory.

358

BLIS*

The BLIS

function is designed to help provide

assistance in heavy traffic with several lanes
moving in the same direction by helping the
driver to detect the presence of vehicles in the
"blind spot" area behind and to the side of the
vehicle.

BLIS is a driver support system designed to alert
the driver of:

•

vehicles in your "blind spot"

•

vehicles approaching rapidly in adjacent
lanes.

Location of BLIS indicator light.

Indicator light

The BLIS button in the center display's Func-
tion view is used to activate/deactivate the
function.

BLIS overview

Blind spot zone

Rapidly approaching vehicle zone.

The BLIS function is active at speeds
above 10 km/h (6 mph).

The system is designed to react to:

•

vehicles passing your vehicle

•

vehicles that are rapidly approaching your
vehicle from behind.

When BLIS detects a vehicle in zone 1 or a rap-
idly approaching vehicle in zone 2, an indicator
light will illuminate in the relevant rearview mirror
and glow steadily. If the driver then uses the turn
signal on the side in which the warning has been

Blind Spot Information Systems

Note: This illustration is general and details may vary depending on model.

DRIVER SUPPORT

}}

359

given, the indicator light will become brighter and
begin flashing.

NOTE

The light illuminates on the side of the vehicle
where the system has detected the vehicle. If
the vehicle is passed on both sides simulta-
neously, both lights come on.

WARNING

•

The BLIS function is supplementary driver
support intended to facilitate driving and
help make it safer – it cannot handle all
situations in all traffic, weather and road
conditions.

•

The responsibility for changing lanes
safely and using good judgment always
rests with the driver.

•

BLIS is not a substitute for the driver's
attention and judgment. The driver is
always responsible for ensuring the vehi-
cle is driven in a safe manner, at the
appropriate speed, with an appropriate
distance to other vehicles, and in accord-
ance with current traffic rules and regula-
tions.

Related information

•

Activating/deactivating BLIS (p. 359)

•

BLIS limitations (p. 360)

•

BLIS messages (p. 362)

Activating/deactivating BLIS

The BLIS

function can be activated/deacti-

vated.

Location of BLIS indicator light.

Indicator light

The BLIS button in the center display's Func-
tion view is used to activate/deactivate the
function.

–

Tap the

BLIS

button in Function view.

> The BLIS indicator light shows the status

of the function: GREEN (on) or GRAY
(off).

If BLIS is activated when the engine is started,
the indicator lights in the rearview mirrors will
flash once.

If BLIS is deactivated when the engine is turned
off, it will remain off the next time the engine is
started and the indicator lights will not illuminate.

DRIVER SUPPORT

* Option/accessory.

360

Related information

•

BLIS* (p. 358)

BLIS limitations

BLIS

functionality may be reduced in certain

situations.

Keep the marked area clean (on both the left and right
sides of the vehicle)

Examples of limitations:

•

Dirt, ice and snow covering the sensors may
reduce functionality and prevent the system
from providing warnings.

•

The BLIS function is automatically deacti-
vated if a trailer, bicycle holder or similar is
connected to the vehicle's electrical system.

•

For BLIS to function optimally, bicycle hold-
ers, luggage racks or similar should not be
mounted on the vehicle's towbar.

WARNING

•

BLIS does not work in sharp curves.

•

BLIS does not work when the vehicle is
being reversed.

Related information

•

BLIS* (p. 358)

Blind Spot Information

Note: This illustration is general and details may vary depending on model.

Blind Spot Information

Note: This illustration is general and details may vary depending on model.

DRIVER SUPPORT

* Option/accessory.

361

Recommended maintenance for

BLIS

•

For optimal performance, it is important to
keep the areas in front of the sensors clean.

•

Do not attach any objects, tape or decals to
the surface of the sensors.

Keep the marked area clean (on both the left and right
sides of the vehicle)

The BLIS sensors are located on the inside of
each of the rear fenders/bumpers and are also
used by the Cross Traffic Alert (CTA) and Rear
Collision Warning functions.

CAUTION

Repair of BLIS and CTA components or
repainting of the bumper may only be per-
formed by a workshop – an authorized Volvo
workshop is recommended.

Related information

•

BLIS* (p. 358)

•

Cross Traffic Alert* (p. 363)

•

Activating/deactivating Cross Traffic Alert
(p. 364)

•

Cross Traffic Alert limitations (p. 364)

•

Cross Traffic Alert messages (p. 366)

•

Rear Collision Warning (p. 357)

Note: This illustration is general and details may vary depending on model.

DRIVER SUPPORT

* Option/accessory.

362

BLIS messages

A number of messages related to BLIS

may

be displayed in the instrument panel.

Some examples of symbols and messages are shown in the table below.

Message

Meaning

Blind spot sensor

Service required

The system is not functioning as intended. Contact a workshop

‒ an authorized Volvo workshop is recommended.

Blind spot system off

Trailer attached

BLIS and CTA have been deactivated because a trailer has been connected to the vehicle's electrical system.

A text message can be erased by briefly pressing
the

button in the center of the right-side

steering wheel keypad.

If the message persists: Contact a workshop

‒ an

authorized Volvo workshop is recommended.

Related information

•

BLIS* (p. 358)

Blind Spot Information

DRIVER SUPPORT

* Option/accessory.

363

Cross Traffic Alert*

CTA

is a supplementary driver support system

to BLIS

that is intended to help the driver

detect vehicles crossing behind the vehicle
while backing up.

CTA overview.

CTA supplements BLIS by detecting traffic cross-
ing from the side, e.g. when backing out of a
parking space.

CTA is primarily designed to detect vehicles, but
in certain cases can also detect pedestrians or
smaller objects such as bicycles.

CTA is only active when the vehicle is moving
backward or if reverse gear is engaged.

If CTA detects that something is approaching
your vehicle from the side:

•

an audible signal will sound from either the
left or right speaker, depending on which
side of your vehicle the object is approaching
from.

•

an icon will illuminate in the PAS

graphic

on the screen.

•

an icon will appear in the Park Assist Cam-
era's Top view.

Illuminated CTA icon in the PAS graphic

on the

screen.

WARNING

•

The Cross Traffic Alert function is supple-
mentary driver support intended to facili-
tate driving and make it safer – it cannot
handle all situations in all traffic, weather
and road conditions.

•

The responsibility for reversing the vehicle
safely and using good judgment always
rests with the driver.

•

Cross Traffic Alert is not a substitute for
the driver's attention and judgment. The
driver is always responsible for ensuring
the vehicle is driven in a safe manner, at
the appropriate speed, with an appropri-
ate distance to other vehicles, and in
accordance with current traffic rules and
regulations.

Related information

•

Activating/deactivating Cross Traffic Alert
(p. 364)

•

Cross Traffic Alert limitations (p. 364)

•

Cross Traffic Alert messages (p. 366)

Cross Traffic Alert

Blind Spot Information

Park Assist System: Parking assistance with reversing sensors

Note: This illustration is general and details may vary depending on model.

DRIVER SUPPORT

* Option/accessory.

364

Activating/deactivating Cross Traffic

Alert

The driver can choose to deactivate the CTA

function as follows:

Press the

Cross Traffic Alert

button in the center display's
Function view.

•

GRAY button indicator light - CTA is deacti-
vated.

•

GREEN button indicator light - CTA is acti-
vated.

CTA is automatically activated each time the
engine is started.

Related information

•

Cross Traffic Alert* (p. 363)

Cross Traffic Alert limitations

CTA

functionality may be reduced in certain

situations.

CTA does not function optimally in all situations
and has certain limitations. The CTA sensors, for
example, cannot "see" through other parked
vehicles or objects blocking the vehicle.

Below are a few examples of situations in which
CTA's field of vision may be initially limited and
approaching vehicles may therefore not be
detected until they are very close to your vehicle:

The vehicle is parked very far into a parking space.

In a diagonal parking space, CTA may be completely
"blind" on one side of your vehicle.

CTA's blind zone.

CTA's field of vision.

However, as you back your vehicle slowly out of a
parking space, CTA's field of vision changes in
relation to the obstructing vehicle/object and its
blind zone is reduced.

Cross Traffic Alert

DRIVER SUPPORT

* Option/accessory.

365

Examples of further limitations

•

Dirt, ice and snow covering the sensors may
reduce functionality and prevent the system
from providing warnings. For additional infor-
mation, see the section "Recommended
maintenance for Cross Traffic Alert".

•

CTA is automatically deactivated if a trailer,
bicycle holder or similar is connected to the
vehicle's electrical system.

•

For CTA to function optimally, bicycle hold-
ers, luggage racks or similar should not be
mounted on the vehicle's towbar.

Related information

•

Cross Traffic Alert* (p. 363)

•

Recommended maintenance for

Cross Traffic Alert

•

For optimal performance, it is important to
keep the areas in front of the sensors clean.

•

Do not attach any objects, tape or decals to
the surface of the sensors.

Keep the marked area clean (on both the left and right
sides of the vehicle)

The CTA sensors are located on the inside of
each of the rear fenders/bumpers and are also
used by the BLIS

and Rear Collision Warning

functions.

CAUTION

Repair of BLIS and CTA components or
repainting of the bumper may only be per-
formed by a workshop – an authorized Volvo
workshop is recommended.

Related information

•

Cross Traffic Alert* (p. 363)

•

BLIS* (p. 358)

•

Rear Collision Warning (p. 357)

Note: This illustration is general and details may vary depending on model.

Blind Spot Information

DRIVER SUPPORT

* Option/accessory.

366

Cross Traffic Alert messages

A number of messages related to CTA

may be

displayed in the instrument panel.

Some examples of symbols and messages are shown in the table below.

Message

Meaning

Blind spot sensor

Service required

The system is not functioning as intended. Contact a workshop

‒ an authorized Volvo workshop is recommended.

Blind spot system off

Trailer attached

BLIS and CTA have been deactivated because a trailer has been connected to the vehicle's electrical system.

A text message can be erased by briefly pressing
the

button in the center of the right-side

steering wheel keypad.

If the message persists: Contact a workshop

‒ an

authorized Volvo workshop is recommended.

Related information

•

Cross Traffic Alert* (p. 363)

Cross Traffic Alert

DRIVER SUPPORT

}}

* Option/accessory.

367

Road Sign Information*

The Road Sign Information (RSI

) function can

help the driver observe speed-related road
signs.

Examples of signs that can be detected

Example

of registered speed information.

If the vehicle passes a speed limit sign, it will be
displayed in the instrument panel and the head-
up display*.

NOTE

In certain markets, the Road Sign Information
function (RSI) is only available in combination
with Sensus Navigation*.

WARNING

•

The Road Sign Information function is
supplementary driver support intended to
facilitate driving and help make it safer –
it cannot handle all situations in all traffic,
weather and road conditions.

•

Road Sign Information is not a substitute
for the driver's attention and judgment.
The driver is always responsible for
ensuring the vehicle is driven in a safe
manner, at the appropriate speed, with an
appropriate distance to other vehicles,
and in accordance with current traffic
rules and regulations.

Related information

•

Activating/deactivating Road Sign Informa-
tion (p. 368)

•

Road Sign Information and sign displays
(p. 369)

•

Road Sign Information and Sensus
Navigation (p. 369)

•

Road Sign Information with Speed Warning
and Settings (p. 370)

•

Activating/deactivating Speed Warning in
Road Sign Information (p. 371)

Road Sign Information

Road signs differ according to market

‒ the illustrations shown here are just some examples.

DRIVER SUPPORT

* Option/accessory.

368

•

Road Sign Information with speed camera
information (p. 371)

•

Road Sign Information limitations (p. 372)

Activating/deactivating Road Sign

Information

The Road Sign Information function can be
switched On or Off.

Press the

Road Sign

Information

button in the cen-

ter display's Function view.

•

GREEN button indicator light - RSI is acti-
vated.

•

GRAY button indicator light - RSI is deacti-
vated.

NOTE

•

If the Automatic Speed Limiter function is
activated, road sign information is shown
in the driver display even if RSI

is not

activated.

•

To remove road sign information from the
driver display, you must deactivate both
Automatic Speed Limiter and RSI.

•

When the Automatic Speed Limiter func-
tion is activated but RSI is deactivated, no
warnings are given from RSI. RSI must
also be activated for warnings to be pos-
sible.

Related information

•

Road Sign Information* (p. 367)

Road Sign Information (RSI)

DRIVER SUPPORT

* Option/accessory.

369

Road Sign Information and sign

displays

Road Sign Information (RSI

) displays road

signs in different ways depending on the sign
and situation.

Example

of registered speed information.

When RSI has registered a speed limit sign, the
sign will be displayed as a symbol in the instru-
ment panel and a colored marking will be shown
in the speedometer's speed scale.

If the vehicle is equipped with Sensus
Navigation*, speed-related information will also
be retrieved from map data, which means that the
instrument panel can display or change informa-
tion about speed limits even if the vehicle has not
passed a speed-related sign.

Signs for "School" and "Children
playing"

If the warning sign

"School"

or "Children playing" is
included in the satellite naviga-
tor's map data

, a symbol of

this type will be displayed in the
instrument panel.

Related information

•

Road Sign Information* (p. 367)

•

Activating/deactivating Road Sign Informa-
tion (p. 368)

•

Road Sign Information with Speed Warning
and Settings (p. 370)

Road Sign Information and Sensus

Navigation

If the vehicle is equipped with Sensus Navigation,
speed-related information will be provided in the
following situations:

•

In cases where the speed limit is given indi-
rectly, e.g. signs for highways or other major
roads.

•

If a previously detected speed sign is
deemed to be no longer valid and no new
sign has been passed.

NOTE

In certain markets, the Road Sign Information
function (RSI) is only available in combination
with Sensus Navigation*.

NOTE

If a downloaded third-party app is used for
navigation, there is no support for speed-rela-
ted information.

Related information

•

Road Sign Information* (p. 367)

Road Sign Information

Road signs differ according to market

‒ the illustrations shown here are just examples.

Only vehicles with Sensus Navigation*.

DRIVER SUPPORT

* Option/accessory.

370

Road Sign Information with Speed

Warning and Settings

The

Speed Limit Warning

sub-function for

RSI

can be switched On or Off.

Speed Limit Warning

warns the driver if the

vehicle's speed has exceeded the applicable
speed limit or the preset Speed Limiter speed.
The warning will be repeated once after
about 1 minute in that speed limit area if the
driver does not slow down.

A new warning and message indicating that the
speed limit has been exceeded will be provided
only when the vehicle has entered a new/differ-
ent speed limit area.

When Speed Warning is acti-
vated, the symbol for the cur-
rent speed limit in the instru-
ment panel

will flash tempo-

rarily if that speed is exceeded.

The driver can be alerted if the
vehicle is exceeding a detected
speed limit and is approaching
a speed camera.

Settings

Adjusting the Speed Warning limit

The driver can adjust the settings to be alerted at
a higher speed than the posted speed limit.

To adjust the Speed Warning limit:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the center

display's Top view.

2. Mark

Speed Limit Warning

> The function is activated and a speed limit

selector is displayed.

3. Tap the up/down arrows on the screen to

adjust the speed at which the Speed Warn-
ing will be given.

Please note that the set warn-
ing limit will not be used when
a speed camera symbol is dis-
played in the instrument panel.

Audible alert On/Off

An audible alert can also be given along with the
Speed Warning.

To adjust the audible alert settings:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the center

display's Top view.

2. Select/deselect

Road Sign Audio Warning

to activate/deactivate the audible alert.

When

Road Sign Audio Warning

is activated,

the driver will also be alerted if the vehicle is
approaching a one-way/"no-entry" road or
entrance.

Speed camera warning On/Off

If the vehicle is equipped with
Sensus Navigation* and map
data contains information on
speed cameras, the driver can
choose to receive an audible
alert if the vehicle is approach-
ing a speed camera.

To adjust the audible alert settings:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the center

display's Top view.

2. Select/deselect

Speed Camera Audio

Warning

to activate/deactivate the speed

camera audible alert.

Road Sign Information

Road signs differ according to market

‒ the illustration shown here is just an example.

DRIVER SUPPORT

}}

* Option/accessory.

371

Related information

•

Road Sign Information* (p. 367)

•

Road Sign Information with speed camera
information (p. 371)

Activating/deactivating Speed

Warning in Road Sign Information

To activate the

Speed Limit Warning

sub-func-

tion:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the center

display's Top view.

2. Mark

Speed Limit Warning

> The function is activated and a speed limit

selector is displayed.

(See description for “Adjusting the Speed
Warning limit” in section “Road Sign Infor-
mation with Speed Warning and Set-
tings.”)

Related information

•

Road Sign Information* (p. 367)

•

Road Sign Information with Speed Warning
and Settings (p. 370)

Road Sign Information with speed

camera information

Vehicles equipped with RSI

and Sensus

Navigation* can provide information on upcom-
ing speed cameras in the instrument panel.

Speed camera information in the instrument panel

100

If the vehicle exceeds a
detected speed limit with the

Speed Limit Warning

func-

tion activated, the driver is
given a speed warning when
the vehicle is approaching a
speed camera if the navigation

map for the vehicle's current location contains
information on speed cameras.

Road Sign Information

100

Note: This illustration is general and details may vary depending on model and market/region.

Content .. 19 20 21 22 ..
