SPECIFICATIONS

396

Fuel tank - volume

Fuel tank volume for each respective engine
alternative can be read in the table.

V40CC

A

Engine

Volume (litres)

Prescribed grade

T4 AWD

T5 AWD

approx. 57

Fuel - petrol (p. 299)

Other petrol engines

approx. 62

Diesel engines

approx. 62

Fuel - diesel (p. 300)

A

V40 CROSS COUNTRY

Related information

•

Filling up with fuel (p. 298)

•

Engine specifications (p. 389)

SPECIFICATIONS

}}

397

Air conditioning, fluid - volume and

grade

The climate control system in the car uses a
refrigerant, either R1234yf or R134a, depend-
ing on market. Information about which refriger-
ant the car's climate control system uses can be
seen on a decal, located on the inside of the
bonnet.

Prescribed grades and volumes of fluids and
lubricants in the air conditioning system can be
read in the tables below.

A/C decal

Decal for R134a

The label is fitted on the inside of the bonnet.

Decal for R1234yf

The label is fitted on the inside of the bonnet.

Symbol explanation R1234yf

Symbol

Meaning

Caution

Mobile air conditioning system
(MAC)

Lubricant type

Symbol

Meaning

A trained and certified technician is
required in order to service the
mobile air conditioning system
(MAC)

Flammable refrigerants

Refrigerant

Cars with refrigerant R134a

Weight

Prescribed grade

625 g

R134a

WARNING

The air conditioning system contains pressur-

ised refrigerant R134a. This system must only

be serviced and repaired by an authorised

workshop.

||

SPECIFICATIONS

398

Cars with refrigerant R1234yf

Weight

Prescribed grade

575 g

R1234yf

WARNING

The air conditioning system contains pressur-

ised refrigerant R1234yf. In accordance with

SAE J2845 (Technician Training for Safe

Service and Containment of Refrigerants

Used in Mobile A/C System), service and

repair of the refrigerant system must only be

performed by trained and certified technicians

in order to ensure the safety of the system.

Compressor oil

Volume

Prescribed grade

60 ml

PAG oil

Evaporator

IMPORTANT

The A/C system's evaporator must never be
repaired or replaced with a previously used
evaporator. A new evaporator must be certi-
fied and labelled in accordance with SAE
J2842.

Related information

•

Climate control system - fault tracing and
repair (p. 349)

Fuel consumption and CO2

emissions

Fuel consumption and CO2 emissions can be
affected negatively by several causes.

Examples of reasons for increased fuel consump-
tion are as follows:

•

If the car is equipped with extra equipment
that affects the car's weight.

•

The driver's driving style.

•

If the customer has specified wheels larger
than those fitted as standard on the model's
basic version then rolling resistance increa-
ses.

•

High speed results in increased wind resis-
tance.

•

Fuel quality, road and traffic conditions,
weather and the condition of the car.

A combination of the above-mentioned examples
can result in significantly increased consumption.

Consumption is higher and power output lower
for fuel with an octane rating of 91 RON.

NOTE

Extreme weather conditions, driving with a
trailer or driving at high altitudes in combina-
tion with fuel quality are factors that consider-
ably increase the car's fuel consumption.

SPECIFICATIONS

399

Related information

•

Economical driving (p. 302)

•

Fuel - petrol (p. 299)

•

Fuel - diesel (p. 300)

•

Weights (p. 386)

SPECIFICATIONS

400

Tyres - approved tyre pressures

Approved tyre pressures for each respective
engine alternative can be read in the table.

V40CC

A

Engine

Tyre size

Speed

(km/h)

Load, 1-3 persons

Max. load

ECO pressure

B

Front

(kPa)

C

Rear

(kPa)

Front

(kPa)

Rear

(kPa)

Front/rear

(kPa)

All engines

205/60 R16

225/50 R17

225/45 R18

225/40 R19

0 - 160

D

240

230

260

260

260

160+

E

260

240

280

280

-

Temporary Spare Tyre

max. 80

F

420

420

420

420

-

A

V40 CROSS COUNTRY

B

Economical driving.

C

In certain countries there is the "bar" unit beside the SI unit "Pascal": 1 bar = 100 kPa.

D

0 - 100 mph

E

100+ mph

F

max 50 mph

NOTE

All engines, tyres or combinations of these
are not always available in all markets.

Related information

•

Tyres - dimensions (p. 319)

•

Tyres - air pressure (p. 318)

•

Type designations (p. 382)

SPECIFICATIONS

401

Performance

Top speed can be read in the table below.

Engine

Engine code

A

Top speed

(km/h)

(mph)

T3

B4154T4

210

130

T4

B4204T19

210

130

T4 AWD

B4204T21

210

130

T5 AWD

B4204T11

210

130

D3

D4204T9

210

130

A

Engine code, component and serial number can be read on the engine.

NOTE

If there are no performance data then they
are available in the accompanying supple-
ment.
