SPECIFICATIONS

413

Fuel tank - volume

Fuel tank volume for each respective engine
alternative can be read in the table.

Engine

Volume (litres)

Prescribed grade

Petrol engine

approx 67

Fuel - petrol (p. 306)

Diesel engine

approx 67

Fuel - diesel (p. 307)

Related information

•

Filling up with fuel (p. 304)

•

Engine specifications (p. 406)

SPECIFICATIONS

414

Specifications for air conditioning

The climate control system in the car uses a
refrigerant, either R1234yf or R134a, depend-
ing on market. Information about which refriger-
ant the car's climate control system uses can be
seen on a decal, located on the inside of the
bonnet.

Prescribed grades and volumes of fluids and
lubricants in the air conditioning system can be
read in the tables below.

A/C decal

Decal for R134a

The label is fitted on the inside of the bonnet.

Decal for R1234yf

The label is fitted on the inside of the bonnet.

Symbol explanation R1234yf

Symbol

Meaning

Caution

Mobile air conditioning system
(MAC)

Lubricant type

Symbol

Meaning

A trained and certified technician is
required in order to service the
mobile air conditioning system
(MAC)

Flammable refrigerants

Refrigerant

Cars with refrigerant R134a

Engine

Weight

Prescribed grade

5-cylinder diesel

720 g

R134a

other

800 g

WARNING

The air conditioning system contains pressur-

ised refrigerant R134a. This system must only

be serviced and repaired by an authorised

workshop.

SPECIFICATIONS

415

Cars with refrigerant R1234yf

Weight

Prescribed grade

750 g

R1234yf

WARNING

The air conditioning system contains pressur-

ised refrigerant R1234yf. In accordance with

SAE J2845 (Technician Training for Safe

Service and Containment of Refrigerants

Used in Mobile A/C System), service and

repair of the refrigerant system must only be

performed by trained and certified technicians

in order to ensure the safety of the system.

Compressor oil

Engine

Volume

Prescribed grade

4-cylinder

60 ml

PAG SP-A2

5-cylinder

110 ml

PAG SP-A2

Evaporator

IMPORTANT

The A/C system's evaporator must never be
repaired or replaced with a previously used
evaporator. A new evaporator must be certi-
fied and labelled in accordance with SAE
J2842.

Related information

•

Climate control system - fault tracing and
repair (p. 359)

•

Type designations (p. 400)

SPECIFICATIONS

416

Fuel consumption and CO2

emissions

Fuel consumption in a vehicle is measured in
litres per 100 km and CO2 emissions in grams
CO2 per km.

Explanation

gram CO

/km

litre/100 km

Urban driving

Extra-urban driving

Combined driving

manual gearbox

Automatic gearbox

NOTE

If the consumption and emission data is miss-
ing then it is included in the enclosed supple-
ment.

NOTE

Not all engines are available in all markets.

S60CC

T5 AWD (B4204T11)

223

9.8

136

6.0

168

7.4

D3 (D4204T4)

120

4.6

106

4.0

111

4.2

D3 (D4204T4)

137

5.3

110

4.2

120

4.6

(D4204T14)

120

4.6

106

4.0

111

4.2

(D4204T14)

119

4.6

105

4.0

110

4.2

SPECIFICATIONS

}}

417

S60CC

D4 (D4204T14)

137

5.3

110

4.2

120

4.6

D4 AWD (D5244T21)

178

6.8

132

5.1

149

5.7

S60 Cross Country

Does not apply to the low-emissions variant.

This only applies to the low-emissions variant.

Fuel consumption and emission values in the
table above are based on specific EU driving
cycles (see below), that apply to cars with kerb
weight in the basic version and without extra
equipment. The car's weight may increase
depending on equipment. This, as well as how
heavily the car is loaded, increases fuel consump-
tion and carbon dioxide emissions.

There are several reasons for increased fuel con-
sumption compared with the table's values.
Examples of this are:

•

If the car is equipped with extra equipment
that affects the car's weight.

•

The driver's driving style.

•

If the customer chooses wheels other than
those fitted as standard on the model's basic
version then rolling resistance may increase.

•

High speed results in increased wind resis-
tance.

•

Fuel quality, road and traffic conditions,
weather and the condition of the car.

A combination of the above-mentioned examples
can result in significantly increased consumption.

Large deviations in fuel consumption may arise in
a comparison with the EU driving cycles (see
below) which are used in the certification of the
car and on which the consumption figures in the
table are based. For further information, please
refer to the regulations referred to.

NOTE

Extreme weather conditions, driving with a
trailer or driving at high altitudes in combina-
tion with fuel quality are factors that consider-
ably increase the car's fuel consumption.

EU driving cycles

Official fuel consumption figures are based on
two standardised driving cycles in a laboratory
environment ("EU driving cycles") all in accord-
ance with EU Regulation no 692/2008 and
715/2007 (Euro 5 / Euro 6) and UN ECE
Regulation no 101. Since the driving cycles are
also used for quality control, there are significant
requirements for repeatability of the tests. For
this reason the tests are carried out under close
scrutiny and only with the car's basic functions
(e.g. air conditioning, radio, etc. switched off). As
a consequence of this the results from the official
figures are not obviously representative of what
the customer sees during actual usage.

The regulations cover the driving cycles for
"Urban driving" and "Extra-urban driving":

SPECIFICATIONS

418

•

Urban driving - the measurement starts with
cold starting the engine. The driving is simu-
lated.

•

Extra-urban driving - the car is accelerated
and braked at speeds between 0-120 km/h
(0-75 mph). The driving is simulated.

Cars with manual gearbox are started in 2nd
gear.

The official value for combined driving, which is
reported in the table, is a combination of the
results from the "Urban driving" and "Extra-urban
driving" driving cycles, in accordance with legal
requirements.

The exhaust gases are collected in order to
extrapolate the carbon dioxide emissions (CO

emissions) during the two driving cycles. These
are then analysed and give the value for CO

emissions.

Related information

•

Economical driving (p. 310)

•

Weights (p. 404)

SPECIFICATIONS

419

Wheels and tyres - approved

dimensions

In certain countries not all approved dimensions
are indicated by the registration document or
other documents. The following table shows all
approved combinations of wheel rims and tyres.

Information on engine, front-wheel drive (FWD)
or all-wheel drive (AWD) and the type of trans-
mission is needed to read the table. For informa-
tion with respect to these details, see Type des-
ignations (p. 400).

For information on the minimum permitted load
index (LI) and the minimum permitted speed rat-
ing (SS), see Load index and speed rating
(p. 420).
✓ = Approved

S60CC

Engine

man/

aut

215/65R16

7Jx16x50

235/55R17

7.5Jx17x55

235/50R18

7.5Jx18x55

235/45R19

8Jx19x55

T5 AWD (B4204T11)

aut

✓

D3 (D4204T4)

man/aut

✓

D4 (D4204T14)

man/aut

✓

D4 AWD (D5244T21)

aut

✓

S60 Cross Country

Related information

•

Tyres - dimensions (p. 328)

•

Wheel and wheel rim dimensions (p. 328)

SPECIFICATIONS

420

Load index and speed rating

The table below shows the minimum permitted
load index (LI) and speed rating (SS). Informa-

tion on engine, front-wheel drive (FWD) or all-
wheel drive (AWD) and the type of transmission
is needed to read the table. For information with

respect to these details, see Type designations
(p. 400).

S60CC

Engine

man/

aut

Minimum permitted load index (LI)

Minimum permitted speed rating (SS)

T5 AWD

B4204T11

aut

D4204T4

man/aut

D4204T14

man/aut

D4 AWD

D5244T21

aut

S60 Cross Country

The tyre's load index must be at least equal to or greater than indicated in the table.

The tyre's speed rating must be at least equal to or greater than indicated in the table.

Related information

•

Wheels and tyres - approved dimensions
(p. 419)

•

Tyres - approved tyre pressures (p. 421)

•

Tyres - dimensions (p. 328)

•

Wheel and wheel rim dimensions (p. 328)

•

Tyres - load index (p. 329)

•

Tyres - speed ratings (p. 329)

SPECIFICATIONS

421

Tyres - approved tyre pressures

Approved tyre pressures for each respective
engine alternative can be read in the table.

NOTE

All engines, tyres or combinations of these
are not always available in all markets.

S60CC

Engine

Tyre size

Speed

(km/h)

Load, 1-3 persons

Max. load

ECO pressure

Front

(kPa)

Rear

(kPa)

Front

(kPa)

Rear

(kPa)

Front/rear

(kPa)

All engines

215/65 R 16

235/55 R 17

235/50 R 18

235/45 R 19

0 - 160

230

260

160+

240

280

Temporary Spare Tyre

max. 80

420

S60 Cross Country

Economical driving.

In certain countries there is the "bar" unit beside the SI unit "Pascal": 1 bar = 100 kPa.

0 - 100 mph

100+ mph

max 50 mph

Related information

•

Wheels and tyres - approved dimensions
(p. 419)

•

Tyres - dimensions (p. 328)

•

Tyres - air pressure (p. 326)

•

Type designations (p. 400)
