Manually operated front seats

The front seats can be adjusted in a number of
ways to help provide the most comfortable seat-
ing position.

Raise/lower the front edge of seat cushion
by pumping up/down
Move the seat forward/rearward by pulling
the bar upward and moving the seat.
Change lumbar support by pressing the but-
ton

Raise/lower the seat by moving the control
up/down
Change backrest tilt by turning the wheel

WARNING

•

Do not adjust the seat while driving. The
seat should be adjusted so that the brake
pedal can be depressed fully. In addition,
position the seat as far rearward as com-
fort and control allow.

•

Check that the seat is securely locked
into position after adjusting.

Related information

•

•

•

•

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

168

Power front seats

The power front seats offer a number of adjust-
ment possibilities to help maximize comfort and
ergonomics.

The power seats have an overload protector that
activates if a seat is blocked by any object. If this
occurs, put the ignition in mode I or 0 and wait
for a short period before operating the seat
again.

The power seat(s) can be adjusted for a short
period after unlocking the door with the remote
key without switching the ignition on. Seat adjust-
ment can always be made when the engine is
running.

Related information

•

Adjusting power front seats

•

Using the power seat memory function

•

(p. 169)

•

Manually operated front seats (p. 167)

•

Turning front seat ventilation

•

* on and off

(p. 211)

•

Easy access to and from the driver seat
(p. 174)

Adjusting power front seats

The power front seat(s) can be adjusted to many
positions to help improve comfort and ergonom-
ics.

Adjust lumbar support by pressing the con-
trol up/down/forward/rearward
Raise/lower the front edge of the seat cush-
ion by moving the control up/down
Raise/lower the seat by moving the control
up/down
Move the seat forward/rearward by moving
the control forward/rearward
Change backrest tilt by moving the control
forward/rearward

Only one of the power seat's controls can be
used at the same time.

The front seat backrests can be folded down
completely.

Related information

•

Using the power seat memory function

•

(p. 169)

•

•

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

169

Adjusting the passenger's seat from

the driver's seat

Using the controls on the side of the driver's
seat, the driver can adjust the position of the
front passenger's seat.

Activating the function in the center
display

From the center display, the function can be acti-
vated in two ways.

After activating the function, adjust the passeng-
er's seat within 10 seconds. If no adjustments
are made in that time span, the function deacti-
vates automatically.

Activating from Function view

1. Go to the center display's Function view.

2. Activate the function by tapping

Adjust

passenger seat

Activating from Settings
–

In the center display, select

Settings

Car

Seats

Adjust Passenger Seat

From Driver Position

Power seat controls

Move the passenger's seat forward/rearward
by moving the control forward/rearward.
Change the passenger seat's backrest tilt by
moving the control forward/rearward.

Related information

•

Adjusting power front seats

•

•

Adjusting power front seats

Using the power seat memory

function

The memory function can be used to store the
settings (positions) of the power front seats

door mirrors and the head-up display

Three different settings can be stored using this
function. Memory controls are found on one or
both of the front doors

Button for storing a position

M (memory) button

Storing a position

1. Adjust the seat, door mirrors and head-up

display to the desired positions.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

170

2. Press and release the M button. The indica-

tor light in the button will illuminate.

3. Press button 1, 2 or 3 within 3 seconds to

store the current position of the seat/
mirrors/head-up display in the selected but-
ton.
> When the position has been stored in the

selected button, an audible signal will
sound and the indicator light in the M but-
ton will go out.

If none of the buttons (1, 2 or 3) are pressed
within 3 seconds, the indicator light in the M but-
ton will go out and the position will not be stored.

The seat/mirrors/head-up display must be
moved before new settings can be stored.

Using a stored position

A stored position can be used when one of the
front doors is opened or closed:

Front door open
–

Press one of the bottons (1–3) briefly. The
seat, door mirrors and head-up display will
move to the positions stored in that button.

Front door closed
–

Press and hold one of the buttons (1–3) until
the seat, door mirrors and head-up display
have moved to the positions stored in that
button.

The seat, door mirrors and head-up display will
stop automatically if the button is released before
the they have reached the stored positions.

WARNING

•

Because the driver's seat can be adjusted
with the ignition off, children should never
be left unattended in the vehicle.

•

Movement of the seat can be STOPPED
at any time by pressing any button on the
power seat control panel.

•

Do not adjust the seat while driving. The
seat should be adjusted so that the brake
pedal can be depressed fully. In addition,
position the seat as far rearward as com-
fort and control allow.

•

The seat rails on the floor must not be
obstructed in any way when the seat is in
motion.

Related information

•

•

Multifunctional front seats

In addition to the adjustment settings offered by
the power seat controls, the multifunction control
provides additional possibilities for convenience
and comfort.

Multifunction control on the side of the seat

The multifunction control can be used to adjust
lumbar support

*, the backrest's side bolsters*, the

length of the seat cushion and the massage
function

*. The adjustment settings made with the

control are shown in the center display

* and cer-

tain settings can be made directly from the cen-
ter display.

Center display

The adjustment settings for the driver and pas-
senger seats made using the multifunction con-
trol are shown in the center display. If only one
seat is adjusted, the settings are shown in the

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

171

center of the display. If both seats are adjusted,
the settings for the driver seat are shown on the
upper half of the screen and the ones made for
the passenger seat are on the lower half.

Press the Home button on the center console to
exit the seat adjustment setting view.

Related information

•

Adjusting function settings in the multifunc-
tional front seats

•

* (p. 171)

•

Adjusting function settings in the

multifunctional front seats

The multifunction controls on the side of the seat
as well as the center display can be used to
make seat adjustments. The adjustment settings
are shown in the center display

Multifunction control on the side of the seat

Turn the control up or down to activate.

Front seat massage settings

The front seat backrests have a massage func-
tion. Air-filled cushions provide the massaging
action and a number of settings are available.

The massage function can only be used when
the engine is running.

Massage view in the center display

1. Activate the multifunction control by turning

it up or down. Seat settings will be displayed
in the center display.

2. Tap

Massage

in the seat settings view.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

172

3. Select massage settings by tapping the cen-

ter display or by moving the cursor up/down
using the multifunction control's upper/lower
buttons. Change a setting in the selected
function by tapping the arrows on the center
display or by using the multifunction control's
front/rear buttons.

Massage settings

The following massage settings are available:

•

Off

•

Program 1-5

: There are 5 preset massage

programs. Select

Swell

Tread

Advanced

Lumbar

Shoulder

•

Intensity

: Select

Low

Normal

High

•

Speed

: Select

Slow

Normal

Fast

Restarting the massage function

Massage restart button in the center display

The massage function switches off automatically
after 20 minutes and must be restarted manually
for continued use.

Tap

Restart

in the center display to restart the

selected massage program.

Adjusting the side bolsters in the front
seats

The side bolsters in the front seat backrests can
be inflated/deflated to adjust the amount of sup-
port provided.

Side bolster view in the center display

1. Activate the multifunction control on the side

of the seat by moving it up/down. The seat
settings view will appear in the center dis-
play.

2. Select

Side bolsters

in the seat settings

view.

•

Tap the front button to increase bolster
support.

•

Tap the rear button to decrease bolster
support.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

173

Adjusting front seat lumbar support

Lumbar support can be adjusted up/down/front/
rear.

Lumbar support view in the center display

1. Activate the multifunction control on the side

of the seat by moving it up/down. The seat
settings view will appear in the center dis-
play.

2. Select

Lumbar

in the seat settings view.

•

Tap the button up/down to move lumbar
support up/down.

•

Tap the front button to make lumbar sup-
port firmer.

•

Tap the rear button to make lumbar sup-
port softer.

Extending the seat cushion

The seat cushion can be extended/retracted
using the multifunction control.

Seat cushion extension view in the center display

1. Activate the multifunction control on the side

of the seat by moving it up/down. The seat
settings view will appear in the center dis-
play.

2. Select

Cushion extension

in the seat set-

tings view.

•

Tap the front button to extend the cush-
ion.

•

Tap the rear button to retract the cushion.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

174

Related information

•

Easy access to and from the driver

seat

The

Easy Ingress & Egress

function can be

used to make getting into and out of the driver's
seat easier.

Easy egress

To make getting out of the driver's seat easier,
the seat is lowered, the side bolster deflates and
the seat cushion retracts at the same time.

The easy egress function must be activated in
the center display.

–

Switch off the engine and open the driver's
door.
> The seat, side bolsters and seat cushion

all move at the same time to a position
that makes it easier to leave the seat.

Easy ingress

The seat remains in the easy egress position
when the driver leaves the vehicle. When the
driver returns to the vehicle, the seat is in a posi-
tion to make sitting down easier. When the driver
is seated, has buckled the seat belt and has put
the ignition in at least mode 1, the seat will return
to the driver's preferred position.

Activating/deactivating the function

1. In the center display, select

Settings

Car

Seats

2. Activate/deactivate the function by select-

ing/deselecting the

Easy Ingress & Egress

box.

Related information

•

•

Ignition modes (p. 400)

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

175

Rear seats

Your vehicle has three rows of seats. The sec-
ond row of seats has three individual seating
positions and the third row of seats has two indi-
vidual seating positions.

Related information

•

Adjusting the second row head restraints
(p. 175)

•

•

Folding the third row backrests (p. 180)

•

•

Getting into and out of the third row of seats
(p. 179)

•

Moving the second row seats forward/rear-
ward (p. 176)

•

Adjusting the second row head

restraints

The center head restraint in the second row of
seats can be adjusted to suit the height of the
seat's occupant. The outboard head restraints
can be folded down

* for a better rear view.

Adjusting the center head restraint

The center head restraint should be adjusted up
or down according to the passenger's height. The
restraint should be carefully adjusted to support
the occupant's head.

The center rear seat head restraint should only
be in its lowest position when this seat is NOT
occupied. When the center seat is occupied, the
head restraint must be correctly adjusted to the
passenger’s height so that, if possible, the whole
of the back of the head is covered.

WARNING

The center rear seat head restraint should
only be in its lowest position when this seat is
NOT occupied. When the center seat is occu-
pied, the head restraint must be correctly
adjusted to the passenger’s height so that, if
possible, the entire back of the head is cov-
ered.

Center head restraint button

To lower the head restraint, press and hold the
button (see the illustration) and push the head
restraint down carefully.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

176

Electrically folding down the rear seat’s
outboard head restraints

The outboard head restraints can be folded down
in two ways from the center display.

From Function view

1. Go to the center display's Function view.

2. Tap the

Headrest fold

button.

Via settings

The ignition has to be in at least mode II.

1. In the center display's Top view, tap

Settings

2. Tap

My Car

Seats

3. Select

Fold Headrest On Second Row

Seats

to fold down the outboard head

restraints.

The head restraints must be returned to the
upright position manually until they click into
position.

WARNING

For safety reasons, the outboard head
restraints in the rear seats must be in the
upright (fixed) position if these seating posi-
tions are occupied or if the third row seats are
occupied.

The head restraint must be locked in the
upright position after it has been folded up.

Related information

•

Center display overview (p. 33)

•

Moving the second row seats

forward/rearward

The second row seats can be moved forward/
rearward individually to help optimize legroom for
the passengers.

Lift the handle located under the seat.

Move the seat forward/rearward to the
desired position.

3. Release the handle and move the seat so

that it locks in the new position.

WARNING

Be careful when moving the seat to avoid
injuries to your hands/fingers.

Check that the seat is securely locked in posi-
tion after being moved.

INSTRUMENTS AND CONTROLS

}}

177

Related information

•

Getting into and out of the third row of seats
(p. 179)

•

Adjusting the second row backrest

tilt

Backrest tilt can be adjusted separately for each
of the second row seats.

Center seat

1. Pull the strap on the center seat's right side.

2. Adjust backrest tilt forward/rearward by

decreasing/increasing pressure on it.

3. Release the strap to lock the backrest in the

new position and press the backrest until its
lock engages.

Outboard seats

1. Pull the handle on the side of the seat

upward.

2. Adjust backrest tilt forward/rearward by

decreasing/increasing pressure on it.

3. Release the handle to lock the backrest in

the new position and press the backrest until
its lock engages.

WARNING

Check that all backrests are securely locked
in place after changing the tilt angle.

Related information

•

Moving the second row seats forward/rear-
ward (p. 176)

•

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

178

•

•

Folding the second row backrests

The second row of seats has three individual
seating positions whose backrests can be
folded down separately.

CAUTION

•

To help avoid damage to the seat uphols-
tery, before a rear seat backrest is folded
down, remove any objects from the seat
and ensure that the seat belts are not
buckled.

•

The integrated booster cushion

* in the

center position must be stowed (folded
down) before the backrest is folded
down.

•

The center seating position armrest must
be folded up before the backrest is
folded down.

NOTE

•

It may be necessary to adjust the front
seat backrests and/or move these seats
forward in order to fold down the rear
seat backrests completely.

•

It may also be necessary to move the
second row of seats rearward.

WARNING

Adjust the seat and be sure it is locked in the
new position before driving.

Center seat

To fold down the backrest:

1. Fold down the head restraint manually.

2. Pull the strap on the center seat's right side.

3. Fold the backrest down until it locks in posi-

tion. The seat cushion will move downward/
forward as the backrest is folded down to
create a flat surface.

To return the backrest to the upright position:

1. Pull the strap.

2. Fold the backrest and release the strap.

Push it into position until its lock engages.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

179

3. Adjust the head restraint if necessary.

Outboard seats

To fold down the backrest:

1. Pull up and hold the handle on the side of

the seat while the backrest is being folded
down.

2. Be sure that the backrest and head restraint

do not come in contact with the front seats
while they are being folded down. Fold down
until the backrest locks in place.
> The seat cushion will move downward/

forward as the backrest is folded down to
create a flat surface. The head restraint
folds down automatically when the back-
rest is folded down.

WARNING

After being folded down, be sure the back-
rests are securely locked in place.

To return the backrest to the upright position:

1. Pull up and hold the handle on the side of

the seat while the backrest is being folded
up.

2. Be sure that the backrest and head restraint

do not come in contact with the front seats
while they are being folded up. Fold up the
backrest and release the handle.

3. Press the backrest until its lock engages.

4. Fold up the head restraint manually.

WARNING

Be sure the backrest and head restraint are
securely locked in position after they have
been folded up.

Related information

•

•

Folding the third row backrests (p. 180)

•

•

Adjusting the second row head restraints
(p. 175)

Getting into and out of the third row

of seats

The second row seats can be moved for easier
access to the third row of seats

Getting into and out of a third row seat

To fold down the backrest:

1. Pull the handle on the upper side of one of

the outboard second row seats upward/
forward.

2. Fold the backrest forward and move the

entire seat forward.

To return the backrest to the upright position:

–

Move the seat back and fold up the backrest
until it locks in position.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

180

WARNING

Be sure the backrest and head restraint are
securely locked in position after they have
been folded up.

Related information

•

Moving the second row seats forward/rear-
ward (p. 176)

•

•

Folding the third row backrests

The third row of seats has two individual seating
positions that can be folded down manually or
electrically

NOTE

Before folding down the third row seats, it
may be necessary to change the position/tilt
of the seats in the second row.

1. Pull the handle on the upper side of the

backrest upward/forward.

2. Be sure that the backrest and head restraint

do not come in contact with the seat ahead
while they are being folded down. Fold the
backrest down.
> The seat cushion will move downward/

forward as the backrest is folded down to
create a flat surface. The head restraint
folds down automatically when the back-
rest is folded down.

To return the backrest to the upright position,
fold the backrest up until it locks in position. The
head restraint has to be folded up manually.

WARNING

Be sure the backrest and head restraint are
securely locked in position after they have
been folded up.

Related information

•

Adjusting the second row head restraints
(p. 175)

•

•
