Volvo XC90 T8 Twin Engine Plug-in Hybrid (2017 year). Instruction

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

103

Use the right-side steering wheel keypad to navigate in
the trip computer (generic illustration)

Open/close the app menu

Left/right arrow keys

Up/down arrow keys

Confirm

1. Press (1) to open the app menu in the

instrument panel.

The app menu cannot be opened if there is
an a message in the instrument panel that
has not been confirmed. Press (4) to confirm.

2. The top four lines show readings from trip

odometer TM. The following four lines show
readings from trip odometer TA. Scroll up/
down in the list using (3).

3. Scroll to the selection buttons in the lines

below TA and select the trip odometer to be
displayed.

•

Current fuel consumption

•

Distance to empty

•

Odometer

•

Trip odometers TM, TA or none

•

Tourist (alternative speedometer).

•

Distance to discharged battery

Select or deselect an alternative using the
center button (4). The change will be made
immediately.

Resetting a trip odometer

Reset trip odometer TM by pressing and holding
the RESET button the left-side steering wheel
lever. Trip odometer TA resets automatically if the
ignition is switched off for more than 4 hours.

Changing the unit of measure

Change the units of measure for driven distance
and fuel consumption in the center display's Top
view by selecting

Settings

System

Units

and marking the desired unit.

NOTE

Changing these units of measure will also
change the ones used in the Volvo navigation
system

Related information

•

Displaying trip statistics (p. 104)

•

Trip computer (p. 101)

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

104

Displaying trip statistics

Trip computer statistics can be displayed graphi-
cally in the center display.

Open the

Driver performance

app in the app menu to display
trip statistics.

Each bar in the graph repre-
sents a driving distance of
1 mile, 10 miles or 100 miles

depending on the current scale; bars are added
from the right and the bar at the far right shows
the value for the current trip.

Average fuel consumption is calculated from the
most recent time at which the current trip odom-
eter was reset.

Fuel and electrical current consumption are
shown in separate graphs. The electrical current
graph shows "net" consumption, i.e., consumed
current minus regenerated current generated by
braking.

Trip statistic settings

Select

Preferences

to:

•

change the graph's scale

•

Reset data after each trip (this occurs if the
vehicle remains parked for more than 4
hours)

•

Reset data for the current trip

The illustration is generic; the layout may vary depending
on the model or due to software updates

Changing the unit of measure

Change the units of measure for driven distance
and fuel consumption in the center display's Top
view.

1. Tap

Settings

in Top view.

2. Tap

System

Units

3. Under

Units

, select:

Metric

Imperial

Related information

•

Trip computer (p. 101)

•

Displaying trip computer information (p. 102)

HomeLink

Wireless Control

System

HomeLink

can be used to open garage doors,

gates, etc.

Button 1

Button 2

Button 3

Indicator light

The HomeLink

®2

Wireless Control System pro-

vides a convenient way to replace up to three
hand-held radio-frequency (RF) transmitters used
to activate devices such as gate operators,
garage door openers, entry door locks, security

This can also be displayed in kilometers.

HomeLink and the HomeLink house are registered trademarks of Gentex Corporation.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

105

systems, even home lighting. Additional informa-
tion can be found on the Internet at,
www.homelink.com/www.youtube.com/
HomeLinkGentex or by phoning the hotline at 1–
800–355–3515.

WARNING

•

If you use HomeLink

to open a garage

door or gate, be sure no one is near the
gate or door while it is in motion.

•

When programming a garage door
opener, it is advised to park outside of the
garage.

•

Do not use HomeLink

with any garage

door opener that lacks safety stop and
reverse features as required by U.S. fed-
eral safety standards (this includes any
garage door opener model manufactured
before April 1, 1982). A garage door that
cannot detect an object - signaling the
door to stop and reverse - does not meet
current U.S. federal safety standards. For
more information, contact HomeLink at:
www.homelink.com.

Retain the original transmitter of the RF device
you are programming for use in other vehicles as
well as for future HomeLink programming. It is
also suggested that upon the sale of the vehicle,
the programmed HomeLink buttons be erased
for security purposes. See the article "Program-
ming HomeLink."

Related information

•

Programming the HomeLink

Wireless Con-

trol System

* (p. 105)

Programming the HomeLink

Wireless Control System

NOTE

Some vehicles may require the ignition to be
switched on or be in the “accessories” posi-
tion for programming and/or operation of
HomeLink. It is also recommended that a new
battery be placed in the hand-held transmitter
of the device being programmed to Home-
Link for quicker training and accurate trans-
mission of the radio-frequency signal. The
HomeLink buttons must be reset first. When
this has been completed, Homelink is in
learning mode so that you can perform pro-
gramming.

To program HomeLink

1. Press the HomeLink

button to be pro-

grammed. The HomeLink

indicator will

begin flashing yellow once a second. You do
not need to continue holding the button.

2. Point the hand-held transmitter toward the

HomeLink

button to be programmed and

hold it approx. 6–12 inches (15–30 cm)
away from the HomeLink

button. Do not

obstruct the HomeLink

indicator light.

INSTRUMENTS AND CONTROLS

106

3. Press and hold the button on the original

remote control that is to be programmed on
HomeLink

and observe the HomeLink

indicator light. Hold the button until the indi-
cator light has changed from flashing yellow
once a second to either flashing green 10
times a second or by glowing steadily green.
When the HomeLink

indicator light flashes

or glows steadily green, the button on the
original remote control can be released.
Note: for certain remote controls, the
instructions listed under "Gate operators/
Canadian programming" at the end of this
article should be used instead of step 3.

4. Press the programmed HomeLink

button

and check the indicator light.

Indicator light glows steadily green: pro-
gramming has been completed. The garage
door, gate, etc., should now be activated
when the programmed button is pressed.

Indicator light flashes 10 times a second:
press the HomeLink

button that is being

programmed. Hold it for 2 seconds and
release it. Repeat the “press/hold/release”
sequence a second time, and, depending on
the brand of the garage door opener, repeat
this sequence a third time to complete the
programming process. Programming should
now be completed and the garage door,
gate, etc., should now be activated when the
programmed button is pressed.

If the garage door, etc. still does not
react: continue with steps 6-8 to complete
programming.

5. Locate the "training" button on the garage

door opener, etc. The designation and color
of the button may vary, depending on the
manufacturer. It is usually located near the
antenna attachment on the device.

6. Press the device's "training" button. When

this has been done, step 8 must be comple-
ted within 30 seconds.

7. Press and hold the HomeLink

button being

programmed for 2 seconds and release it.
Repeat the “press/hold/release” sequence a
second time, and, depending on the brand of
the garage door opener, repeat this
sequence a third time to complete the pro-
gramming process. Programming should now
be completed and the garage door, gate, etc.,
should now be activated when the pro-
grammed button is pressed.

INSTRUMENTS AND CONTROLS

}}

107

Gate Operator/Canadian Programming

Canadian radio-frequency laws require transmit-
ter signals to “time-out” (or quit) after several
seconds of transmission – which may not be long
enough for HomeLink to pick up the signal dur-
ing programming. Similar to this Canadian law,
some U.S. gate operators are designed to “time-
out” in the same manner.

If you live in Canada or you are having difficulties
programming a gate operator or garage door
opener by using the “Programming” procedures,
replace “Programming HomeLink” step 3
with the following:

•

Continue to press and hold the HomeLink
button while you press and release - every
two seconds (“cycle”) your hand-held trans-
mitter until the HomeLink indicator light
changes from a slow to a rapidly blinking
light. Now you may release both the Home-
Link and hand-held transmitter buttons.

Proceed with “Programming” step 4 to complete.

Using HomeLink

When programming has been completed,
HomeLink

can be used instead of the original

remote controls.

To operate, press and hold the programmed
HomeLink

button until the trained device begins

to operate

(this may take several seconds). The

indicator light will glow steadily or flash when the
button has been pressed. Activation will now
occur for the trained device (i.e., garage door
opener, gate operator, security system, entry door
lock, home/office lighting, etc.).

NOTE

If the ignition is switched off, HomeLink will
function for 30 minutes after the driver's door
has been opened.

For convenience, the hand-held transmitter of the
device may also be used at any time.

In the event that there are still programming diffi-
culties or questions, contact HomeLink at:
www.HomeLink.com, www.youtube.com/
HomeLinkGentex or by phoning the hotline at 1–
800–355–3515.

Resetting HomeLink

buttons

Use the following procedure to reset (erase pro-
gramming) from the three HomeLink

buttons

(individual buttons cannot be reset but can be
“reprogrammed” as outlined in the following sec-
tion):

1. Press and hold HomeLink

buttons 1 and 3

for approx. 10 seconds until the indicator
light begins to flash green.

2. Release both buttons.

> HomeLink

is now in the training (or

learning) mode and can be programmed
at any time beginning with “To program
HomeLink

" above.

Reprogramming a single HomeLink

button

To reprogram an individual HomeLink

button:

1. Press and hold the desired HomeLink

but-

ton. DO NOT release the button.

2. The yellow indicator light will begin to flash

after 20 seconds. Without releasing the
HomeLink button, proceed with “To program
HomeLink

" step 1 above.

For questions or comments, contact HomeLink
at: www.HomeLink.com, www.youtube.com/
HomeLinkGentex or by phoning the hotline at 1–
800–355–3515.

FCC (USA) and IC (Canada)

This device complies with FCC rules part 15 and
Industry Canada RSS-210. Operation is subject
to the following two conditions: (1) This device
may not cause harmful interference, and (2) This
device must accept any interference that may be
received including interference that may cause
undesired operation. WARNING: The transmitter
has been tested and complies with FCC and IC

Do not hold the button for more than 20 seconds as this will clear the programming of the button.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

108

rules. Changes or modifications not expressly
approved by the party are prohibited.

NOTE

The transmitter has been tested and complies
with FCC and IC rules. Changes or modifica-
tions not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the device.

Related information

•

HomeLink

Wireless Control System

(p. 104)

Adjusting the power door mirrors

The control on the driver's door is used to adjust
the position of the door mirrors.

Door mirror controls

Adjusting

1. Press the L button for the left door mirror or

the R button for the right door mirror. The
light in the button comes on.

2. Adjust the position with the joystick in the

center.

3. Press the L or R button again. The light

should no longer be on.

WARNING

Objects seen in the mirrors may appear fur-
ther away than they actually are.

Storing the position

The mirror positions are stored in the key mem-
ory

* when the vehicle has been locked with the

remote key. When the vehicle is unlocked with
the same remote key, the mirrors and the driver's
seat adopt the stored positions when the driver's
door is opened. The mirrors' position can also be
stored in the power seat's

* memory.

Tilting the door mirrors when parking

The door mirrors can be tilted down to help give
the driver a better view along the sides of the
vehicle, for example when parallel parking.

–

To activate this function, select reverse gear
and press the L or R mirror control button to
tilt the mirror down.

The door mirror will reset to its normal position:

•

after 10 seconds when reverse is disen-
gaged

•

immediately if you press the corresponding L
or R button again.

The term “IC:” before the certification/registration number only signifies that Industry Canada technical specifications were met.

Only on models equipped with a power driver's seat.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

109

NOTE

Only one mirror can be tilted down at a time.

Automatically tilting the door mirrors
when parking

This function can be activated/deactivated in the
center display.

1. Tap

Settings

in Top view.

2. Tap

My Car

Mirrors

3. Under

Tilt Mirror In Reverse

, select

Off

Driver

Passenger

Both

to activate/

deactivate and select which mirror to tilt.

Folding mirrors

When parking in a limited space, the mirrors can
be folded in:

1. Press the L and R buttons at the same time

(the ignition must be in at least mode I).

2. Release the buttons after approx. 1 second.

The mirrors will stop automatically when they
are completely folded in.

Fold out the mirrors by pressing the L and R at
the same time. The mirrors will stop automatically
when they return to their original positions.

Automatic folding when the vehicle is
locked

The mirrors can be folded in/out automatically
when the vehicle is locked/unlocked.

This function can be activated/deactivated in the
center display.

1. Tap

Settings

in Top view.

2. Tap

My Car

Mirrors

3. Select

Fold Mirrors When Locking

to acti-

vate/deactivate.

Resetting the mirrors' position

A mirror that has been moved manually (e.g.,
bumped into in a parking lot, etc.) has to be
returned to its normal position electrically before
automatic folding will function correctly.

1. Fold in the mirrors with the L and R buttons.

2. Fold out the mirrors with the L and R buttons.

The mirrors have now been reset to their original
positions.

Auto-dim

Settings can be made for the auto-dim function
in the rearview and door mirrors.

The auto-dim function is always active while the
vehicle is being driven except when the reverse
gear has been selected. The level of sensitivity

for this function can be set to three levels, which
affect the rearview mirror and door mirrors.

NOTE

When the level of sensitivity is changed, this
change will not be noticeable immediately but
will take effect after a short period of time.

The level of sensitivity is set from the center dis-
play:

1. Tap

Settings

in Top view.

2. Tap

My Car

Mirrors

3. Under

Auto Dim Mirrors

, select

Normal

Dark

Light

Related information

•

Using the power seat memory function

(p. 169)

•

Rearview mirror (p. 114)

Only on models equipped with a power driver's seat.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

110

Laminated panoramic roof

The laminated panoramic roof is divided into two
sections and only the front section can be
opened; it can be slid horizontally to the open or
closed positions or its rear edge can be raised
and lowered to allow ventilation.

The laminated panoramic roof also has a sun
shade made of perforated fabric that is located
below the sections of glass. This shade can be
opened or closed, for example when driving in
bright sunlight.

The laminated panoramic roof also has a wind
blocker that folds up when the roof is open.

CAUTION

The optional panoramic roof should not be
opened while load carriers are installed on
the vehicle.

The laminated panoramic roof and the sun shade
are operated using the controls in the ceiling
console, near the rear-view mirror. The controls
are activated when the vehicle's ignition is in
mode I or II.

CAUTION

•

Remove ice and snow before opening the
laminated panoramic roof.

•

Do not operate the laminated panoramic
roof if it is frozen closed.

•

Never place heavy objects on the lamina-
ted panoramic roof.

Wind blocker

The laminated panoramic roof is equipped with a
wind blocker that folds up when the roof is open.

Related information

•

Operating the laminated panoramic roof

(p. 111)

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

111

Operating the laminated panoramic

roof

When opened automatically, the sun shade and
roof open first to the "comfort" position that
helps reduce wind noise and then open com-
pletely.

In the tilt (ventilation) position, the rear edge of
the front section of the roof is raised.

Operation

WARNING

•

During manual closing, if the laminated
panoramic roof is obstructed, immediately
open it again.

•

Never open or close the laminated panor-
amic roof if it is obstructed in any way.

•

Never allow a child to operate the lamina-
ted panoramic roof.

•

Never leave a child alone in a vehicle.

•

When leaving the vehicle, ensure that the
ignition is in mode 0. Never leave a
remote key in the vehicle.

•

Never extend any object or body part
though the open laminated panoramic
roof, even if the vehicle's ignition is com-
pletely switched off.

CAUTION

The optional panoramic roof should not be
opened while load carriers are installed on
the vehicle.

Manual open (arrow points toward the rear of
the vehicle)
Auto open

Manual close

Auto close

The laminated panoramic roof and sun shade can
be operated when the ignition is in at least
mode I.

Manual operation

1. Opening the sun shade: Pull the control

back to the first stop (the manual open posi-
tion) and hold it until the sun shade has
opened to the position of your choice.

2. Opening the laminated panoramic roof:

Pulling the control back to the first stop (the
manual open position) and holding it a sec-
ond time will open the laminated panoramic
roof to the "comfort" position that helps
reduce wind noise while driving. Pull the con-
trol a third time to open the roof completely.

Perform this procedure in reverse order to close
the laminated panoramic roof and/or sun shade.

Movement of the laminated panoramic roof will
stop if the control is released while it is in the
manual open position.

NOTE

For manual opening, the sun shade must first
be fully open before it will be possible to open
the laminated panoramic roof. When closing,
the laminated panoramic roof must be fully
closed before the sun shade can be closed.

Automatic operation

1. Opening the sun shade: Pull the control as

far back as possible (to the auto open posi-
tion) and release it.

INSTRUMENTS AND CONTROLS

112

2. Opening the laminated panoramic roof:

Pull the control as far back as possible a
second time (to the auto open position) and
release it to open the laminated panoramic
roof to the "comfort" position that helps
reduce wind noise while driving. Pull the con-
trol a third time (to the auto open position)
and release it to open the roof completely.

Perform this procedure in reverse order to close
the laminated panoramic roof/sun shade. The
roof will not stop at the "comfort" position if it is
closed from the fully open position.

The laminated panoramic roof will stop when it
reaches the "comfort" position, the fully open
position or the closed position. Movement will
also stop if the control is moved in the opposite
direction to the movement of the roof.

The roof will not stop at the "comfort" position if
it is closed from the fully open position.

Quick open/close

The laminated panoramic roof and the sun shade
can be opened/closed at the same time:

•

Open: pull the control back (to the auto
open position) twice in quick succession and
release it.

•

Close: push the control forward (to the auto
close position) twice in quick succession and
release it.

The laminated panoramic roof will stop when it
reaches the "comfort" position or the closed
position. Movement will also stop if the control is
moved in the opposite direction to the movement
of the roof.

The roof will not stop at the "comfort" position if
it is closed from the fully open position. The sun
shade never stops when the roof reaches the
"comfort" position.

Tilt (ventilation) position

Tilt position, raised at the rear edge

Open (raise the rear edge of the front glass
section) by pressing the rear edge of the
control upward.
Close by pulling the rear edge of the control
downward/forward and holding it until the

laminated panoramic roof has closed com-
pletely.

If the sun shade is completely closed, it will open
approximately 2 inches (5 cm) when the lamina-
ted panoramic roof is opened to the tilt position.

Automatically closing the sun shade

When the vehicle is parked in sunny/warm
weather, the sun shade can be closed automati-
cally 15 minutes after the vehicle has been
locked to help keep the temperature in the pas-
senger compartment down and to protect the
upholstery from the sun.

This function is deactivated by default and can be
activated/deactivated:

1. Tap

Settings

in the center display's Top

view.

2. Tap

My Car

Locking

Select

Auto Close Sun Curtain

to acti-

vate/deactivate.

Closing using an outside door handle

To close the panoramic roof when locking the
vehicle, hold the pressure sensitive surface on
the outside of a door handle until the panoramic
roof has closed completely. The panoramic roof
will stop if the button is released before it is fully
closed. (This also applies to the windows).

Not available in all markets

Vehicles with the optional keyless Passive Entry system only.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory, for more information, see Introduction.

113

Auto-stop

The laminated panoramic roof has an auto-stop
feature that is triggered if the glass section of the
roof or the sun shade is blocked in any way when
being closed. In this case, the laminated panor-
amic roof or sun shade will stop and reverse
automatically approximately 2 in. (5 cm) from the
point at which it was blocked (or will open fully to
the tilt position).

The auto-stop feature also functions when the
laminated panoramic roof or sun shade is being
opened.

WARNING

For 10 minutes after the auto-stop function
has been triggered, it will not function again
the first time the control is moved in the same
direction as when the auto-stop function was
triggered.

The auto-stop feature can be overridden if the
closing procedure has been interrupted (e.g., due
to ice around the moonroof) by pressing and
holding the control forward/down until the moon-
roof is closed.

Power windows

All power windows can be operated using the
control panel in the driver's door. The control
panels in the other doors only operate the win-
dow in the respective doors.

Driver's door control panel

Switch for power child safety locks

* and dis-

engaging rear power window buttons
Rear window controls

Front window controls

Related information

•

Operating the power windows (p. 113)

•

Child safety locks (p. 257)

Operating the power windows

WARNING

•

Always put the ignition in mode 0 and
remove the ignition key from the vehicle
when the vehicle is unattended

•

Never leave children unattended in the
vehicle.

•

Make sure that the windows are com-
pletely unobstructed before they are
operated.

Operating

Operating the power windows

Manual up/down

Auto up/down.

For the power windows to function, the ignition
must be in at least mode I. When the vehicle has

INSTRUMENTS AND CONTROLS

114

been running, the power windows can be oper-
ated for several minutes after the ignition has
been switched off, or until a door has been
opened.

NOTE

•

Movement of the windows will stop if they
are obstructed in any way. If this happens
twice in succession, the automatic func-
tion will not work for several minutes and
the window can be closed by holding the
button up.

•

To reduce buffeting wind noise if the rear
windows are opened, also open the front
windows slightly.

Manual up/down
–

Move one of the controls up/down slightly.
> The power windows move up/down as

long as the control is held in position.

Auto up/down
–

Move one of the controls up/down as far as
possible and release it.
> The window will open or close completely.

Resetting

If the battery has been disconnected, the auto
open function must be reset so that it will work
properly

1. Gently raise the front section of the button to

close the window and hold it for one second.

2. Release the button briefly.

3. Raise the front section of the button again

for one second.

Related information

•

Child safety locks (p. 257)

Rearview mirror

The interior rearview mirror has an auto-dim
function that helps reduce glare from following
vehicle's headlights.

Auto-dim function

The auto-dim function is controlled by two sen-
sors: one pointing forward (located on the for-
ward-facing side of the mirror, which monitors the
amount of ambient light) and one pointing rear-
ward (located on the side of the mirror facing the
driver at the upper edge, which senses the
strength of following vehicles' headlights), and
work together to help eliminate glare.

NOTE

Obstructing the forward sensor with e.g.,
parking stickers, transponders, etc., or the rear
sensor by loading the cargo area or the rear
seat in such a way that light is prevented from
reaching the sensor will reduce the auto-dim
function in the interior rearview mirror and
optional auto-dim function in the door mirrors.

The auto-dim function is always active while the
vehicle is being driven except when the reverse
gear has been selected. The level of sensitivity
for this function can be set to three levels, which
affect the rearview mirror and door mirrors.

INSTRUMENTS AND CONTROLS

}}

115

NOTE

When the level of sensitivity is changed, this
change will not be noticeable immediately but
will take effect after a short period of time.

The level of sensitivity is set from the center dis-
play:

1. Tap

Settings

in Top view.

2. Tap

My Car

Mirrors

3. Under

Auto Dim Mirrors

, select

Normal

Dark

Light

Related information

•

Adjusting the power door mirrors (p. 108)

Using sun shades

Both rear doors have integrated sun shades.

Rear doors

Hook and locking mechanism

1. Pull up the sun shade and hook it to the

upper section of the door frame.

2. Lock the sun shade by moving the locking

mechanism upward.

The window can be opened/closed when the sun
shade is being used.

Related information

•

Power windows (p. 113)

Settings view

The center display's Settings view is used to
make many of the vehicle's function settings and
to display vehicle-related information.

Opening Settings view

Top view with the Settings button

1. Pull down the tab on the upper edge of the

center display to open Top view.

2. Tap

Settings

3. Tap one of the categories displayed and nav-

igate to sub-categories and settings by tap-
ping again.

4. Tap

Back

to go back in Settings view.

Tap

to close Settings view.

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

116

Changing a setting

A sub-category in Settings view with various possible
settings

1. Tap the category/sub-category to navigate to

the desired setting.

2. Change the setting(s).

> The changes are saved immediately.

Types of settings

Type of
setting

Description

Trigger
function

Starts an app or a separate view
for more advanced settings. Tap
the text to e.g., connect a
Bluetooth device.

Radio
button

Select one of the possible set-
tings by tapping the desired radio
button to e.g., change the system
language.

Type of
setting

Description

Multi-
selection
button

Select a level for a particular set-
ting by pressing the desired part
of the button e.g., to set the
desired level for City Safety.

Check
box

Tap to activate/deactivate a func-
tion e.g., to select automatic start
for steering wheel heating.

Slider

Select a level for a function by
pressing and dragging the slider
control e.g., to set a volume level.

Informa-
tion dis-
play

This is not an actual setting but
displays information such as the
vehicle's VIN number.

Related information

•

Center display overview (p. 33)

•

Navigating in the center display's views
(p. 43)

•

Using the center display (p. 50)

•

Changing system settings in Settings view
(p. 118)

•

Categories in Settings view (p. 116)

Categories in Settings view

Settings view consists of a number of main cate-
gories and sub-categories that contain settings
and information for many of the vehicle's fea-
tures and functions.

The main categories in Settings view are:

Car

Sound

Navigation

Media

Communication

Climate

and

System

Each main category, in turn, contains several sub-
categories with possible settings. The table
shows the first level of sub-categories. The possi-
ble settings for a function or area are described
in greater detail in their respective articles in the
owner's manual. For system settings not descri-
bed in the respective articles, see "Changing sys-
tem settings in Settings view."

My Car

Sub-categories

Type of setting

Displays

Personal

IntelliSafe

Combination

Park Assist

Global

Drive Mode

Individual

Drive Mode

Combination

Lights

Combination

Mirrors

Personal

Locking

Combination

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

117

Sub-categories

Type of setting

Electric Parking Brake

Combination

Seats

Combination

Wipers

Combination

Suspension

Global

Sound

Sub-categories

Type of setting

Sound Experience

Personal

Tone

Personal

Balance

Personal

System Volumes

Combination

Navigation

Sub-categories

Type of setting

Map

Personal

Route

Personal

Traffic

Personal

Guidance

Personal

System

Personal

Media

Sub-categories

Type of setting

AM/FM Radio

Personal

SiriusXM

Personal

Gracenote

Personal

Video

Personal

AM radio is not available in hybrid models.

Communication

Sub-categories

Type of setting

Phone

–

Text Messages

–

Bluetooth

–

Wi-Fi

Global

Vehicle Wi-Fi Hotspot

Global

Vehicle Modem Internet

Global

Volvo On Call

–

Volvo Service Networks

Global

Climate

The main category

Climate

has no sub-catego-

ries.

System

Sub-categories

Type of setting

Driver Profile

Personal

Date & Time

–

Language

Personal

Keyboard Layouts

Global

Voice Control

Personal

Units

Personal

Storage

–

Software Updates

–

Global Reset

–

Services

–

Related information

•

Settings view (p. 115)

•

Changing system settings in Settings view
(p. 118)

INSTRUMENTS AND CONTROLS

* Option/accessory, for more information, see Introduction.

118

Changing system settings in

Settings view

Settings view's main category

System

contains

general settings and information, such as lan-
guage, units of measure, etc.

The system settings under

Driver Profile

Date

& Time

Keyboard Layouts

Voice Control

Software Updates

Factory reset

and

Services

are described in their respective arti-

cles in the owner's manual.

Changing system languages

1. Pull down the center display's Top view and

tap

Settings

2. Tap

System

Language

3. Select a new system language. Languages

that can be used for voice commands are
indicated by a voice control symbol.
> This change affects the language used in

the instrument panel, center display and
the head-up display

Changing units of measure

Changing length and volume units

1. Pull down the center display's Top view and

tap

Settings

2. Tap

System

Units

3. Select one of the following measurement

standards:

•

Metric

: kilometers, liters and degrees Cel-

sius.

•

Imperial

: miles, gallons and degrees Cel-

sius.

•

: miles, gallons and degrees Fahren-

heit.

> This change affects the units of measure

used in the instrument panel, center dis-
play and the head-up display

Changing tire inflation pressure units

1. Pull down the center display's Top view and

tap

Settings

2. Tap

System

Units

Tire Pressure

3. Select a unit of measure for tire pressure.

> This changes the tire inflation pressure

units used in the

Car status

app in the

center display.

Viewing storage information

1. Pull down the center display's Top view and

tap

Settings

2. Tap

System

Storage

> Storage information for the vehicle's hard

drive will be displayed, including total
capacity, available capacity and the
amount of storage space used by the
apps that have been installed.

Viewing the VIN (Vehicle Identification
Number)

1. Pull down the center display's Top view and

tap

Settings

2. Tap

System

Vehicle Identification

Number

> The vehicle's VIN will be displayed.

Volvo XC90 T8 Twin Engine Plug-in Hybrid (2017 year). Instruction - part 6
