– Remove the headlamp. Refer to ⇒ “1.2 Headlamp, Removing and Installing”, page 101 . – Remove the screws -2-. from the headlamp. – Push the release buttons -4 and 6-. the following: Caution Make sure the seal fits correctly when installing the HID head‐ lamp control module. Water getting in the headlamp will cause damage. – Make sure the seal between the control module and the head‐ lamp is not damaged. Tightening Specifications ⇒ “1.1 Overview - Headlamp”, page 92 1.18 Left/Right Headlamp Power Output Stage -J667- / -J668- , Removing and Installing The removal and installation is described for the left side. Re‐ moving and installing on the right side is identical. Power Output Stage - J668- is only installed with HID headlamps with cornering lamps. WARNING High voltage poses a life-endangering risk, injury risk and en‐ vironmental hazard. ♦ Pay attention to usage and safety information for HID headlamps. Refer to ⇒ “1.3 HID Headlamps Usage and Safety Precautions”, ♦ It is necessary to disconnect the battery wire strap before working on HID headlamp components. These parts are marked with yellow high voltage symbols. Removing ⇒ “1.2 Headlamp, Removing and Installing”, page 101 . – Remove the screws -2-. from the headlamp. |
