Step Procedure Result / Action to Take 5 • Final Procedure – YES: ♦ CHECK: Engine Control Module - J623- har‐ ness connector for any damaged, pushed-out pins. ♦ REPAIR: As necessary. ⇒ “3.3.4 Diagnostic Mode 04 - Erase DTC ♦ Repair is complete. Generate Readiness Code. Refer to ⇒ “3.2 Readiness Codes”, page 19 ♦ Return vehicle to Customer. Refer to appropriate repair manual. ♦ Repair is complete. Generate Readiness Code. Refer to ⇒ “3.2 Readiness Codes”, page 19 ♦ Return vehicle to Customer. ♦ Perform the diagnostic procedure for any DTC’s. ♦ If no DTC’s return the repair is complete. 3.6.33 Vehicle Speed Signal, Checking General Description Transaxle output or Wheel Speed from the ABS System. The sig‐ nal is broadcasted over the CAN Bus. The Engine Control Module - J623- uses this information to modify engine functions such as ignition timing, AF ratio, transmission shift points, and to initiate diagnostic routines. sition is in “P”. • Vehicles with Man. Transmission, ensure Shifter Lever posi‐ tion is in “N” with Parking Brake applied. • Coolant Temperature: ≥ 80° C. GTI 2014 ➤ Generic Scan Tool - Edition 04.2015 3. Diagnosis and Testing 529 |
