Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 165





DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

P2177

System

Too

Lean Off

Idle

Bank 1

Fuel Sys‐

tem Di‐

rect Fuel

Injection

System

Too Lean

• Adaptive value

>= 28.0 %

• MAF > 60.0 mg/

rev

• ECT @ cylinder

head > 20° C

• IAT @ manifold >

-48° C

• AAT > -48° C
• Lambda set point

0.95 – 1.05 [-]

• Lambda control

closed loop

• Integrated MAF

>= 600.0 –

10,000.0 g

• Fuel mass 15.01

– 50.00 mg/rev

• Engine speed

1,024 – 3,744

rpm

• Low dynamic

conditions:

• Diff. engine

speed vs. aver‐

aged engine

speed for engine

speed dynamic

detection < 60 –

130 rpm

• Diff. air mass vs.

averaged air

mass for load dy‐

namic detection <

16.00 – 30.01 mg/

rev

• Diff. between ref‐

erence and ac‐

tual fuel pres‐

sure, high side <=

2000.10 kPa

• Integrated air

mass > 5.0 – 25.0

g

• And
• Evap purge valve

closed or canister

load <= 1.20 [-]

• Evap purge flow

at max. value

• Or
• Dependence on

canister purge

min:

• 5.0 s
• Con‐

tinu‐

ous

• 2

DCY

– Check the intake

and vacuum ho‐

ses visually for

leaks. Check the

Positive Crank‐

case Ventilation

visually. Also

make sure the

oil dipstick is

properly se‐

cured.

– Listen to and vis‐

ually inspect the

exhaust system

to insure there

are no leaks.

– Check the Oxy‐

gen Sensor 1

Before Catalytic

Converter -

GX10- . Refer to

⇒ “3.6.28  Oxy‐

gen Sensor 1

Before Catalytic

Converter

GX10 , Check‐

ing”, page 516

 .

– Check the Oxy‐

gen Sensor 1 Af‐

ter Catalytic

Converter -

GX7- . Refer to

⇒ “3.6.27  Oxy‐

gen Sensor 1 Af‐

ter Catalytic

Converter GX7 ,

Checking”, page

513

 .

– Check the In‐

take Manifold

Sensor - GX9- .

Refer to

⇒ “3.6.23  Intake

Manifold Sensor

GX9 , Check‐

ing”, page 505

 .

– Check the EVAP

Canister Purge

Regulator Valve

1 - N80- . Refer

to

⇒ “3.6.13  EVAP

Canister Purge

Regulator Valve

1 N80 , Check‐

ing”, page 484

 .

– Check the Fuel

Injectors . Refer

to

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

333

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Lower limit of

lambda controller

output n.a.

• Or
• Upper limit of

lambda controller

output n.a.

• And
• Evap purge flow

at min. value

⇒ “3.6.15  Fuel

Injectors ,

Checking”, page

487

 .

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

334

     Rep. Gr. ST - Generic Scan Tool

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

P2178

System

Too

Rich Off

Idle

Bank 1

Fuel Sys‐

tem Di‐

rect Fuel

Injection

System

Too Rich

• Adaptive value

<= -30.0 %

• Air mass > 60.00

mg/rev

• ECT @ cylinder

head > 20° C

• IAT @ manifold >

-48 ° C

• AAT > -48 ° C
• Lambda setpoint

0.97 – 1.05 [-]

• Lambda control

closed loop

• Integrated air

mass >= 600.0 –

10,000.0 g

• Fuel mass 15.01

– 50.00 mg/rev

• Engine speed

1,024 – 3,744

rpm

• Low dynamic

conditions:

• Diff. engine

speed vs. aver‐

aged engine

speed for engine

speed dynamic

detection < 60 –

130 rpm

• Diff. air mass vs.

averaged air

mass for load dy‐

namic detection <

16.00 - 30.01 mg/

rev

• Diff. between ref‐

erence and ac‐

tual fuel pres‐

sure, high side <=

2,000.10 kPa

• Integrated air

mass > 5.0 – 25.0

g

• And
• Evap purge valve

closed

• Or
• Canister load <=

1.20 [-]

• Evap purge flow

at max. value

• Or

• 5.0 s
• Con‐

tinu‐

ous

• 2

DCY

– Check the Evap‐

orative Emission

(EVAP) System

visually for con‐

tamination.

– Check the Oxy‐

gen Sensor 1

Before Catalytic

Converter -

GX10- . Refer to

⇒ “3.6.28  Oxy‐

gen Sensor 1

Before Catalytic

Converter

GX10 , Check‐

ing”, page 516

 .

– Check the Oxy‐

gen Sensor 1 Af‐

ter Catalytic

Converter -

GX7- . Refer to

⇒ “3.6.27  Oxy‐

gen Sensor 1 Af‐

ter Catalytic

Converter GX7 ,

Checking”, page

513

 .

– Check the In‐

take Manifold

Sensor - GX9- .

Refer to

⇒ “3.6.23  Intake

Manifold Sensor

GX9 , Check‐

ing”, page 505

 .

– Check the Fuel

Injectors . Refer

to

⇒ “3.6.15  Fuel

Injectors ,

Checking”, page

487

 .

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

335

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitor‐

ing Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Dependence on

canister purge

min:

• Lower limit of

lambda controller

output n.a.

• Or
• Upper limit of

lambda controller

output n.a.

• And
• Evap purge flow

at min. value

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

336

     Rep. Gr. ST - Generic Scan Tool
