DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitoring

Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

P0204

Cylinder

4 Injec‐

tor "A"

Circuit

Injection

Valves

Electrical

Error

• Indeterminate

fault pattern via

power stage di‐

agnosis detec‐

ted and injector

low side volt‐

age < 2.0 V

• Injector low

side switch cur‐

rent > 25.0 A

• Or
• Injector low

side voltage <

2.0 V

• Injector high

side switch cur‐

rent > 25.0 A

• Or
• Injector low

side voltage <

2.0 V

• Injector low

side switch cur‐

rent (hardware

values) > 9.0 –

14.0 A

• Or
• Injector voltage

< 2.0 V

• Injector low

side switch cur‐

rent > 25.0 A

• Or
• Injector voltage

< 2.0 V

• Injector low

side switch cur‐

rent (hardware

values) > 9.0 –

14.0 A

• Or
• Injector load re‐

sistance to

ground and

battery > 20.0

Ohm

• Injector low

side switch cur‐

rent > 25.0 A

• Or

• Engine running
• ECT @ cylinder

head >= -30° C

• Engine speed <

7,000 RPM

• Injection time >=

0.0 s

• 8,640.0°

CRK

• Contin‐

uous

• 2

DCY

– Check the Fuel

Injectors . Refer

to

⇒ “3.6.15  Fuel

Injectors ,

Checking”, page

487

 .

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

89

DTC /

Descrip‐

tion

Monitor

Strategy

Descrip‐

tion

Malfunction Crite‐

ria and Threshold

Value

Secondary Parame‐

ters with Enable

Conditions

Monitoring

Time

Length

MIL Il‐

lum.

Component Diag‐

nostic Procedure

• Injector load re‐

sistance to

ground and

battery > 20.0

Ohm

• Injector high

side switch cur‐

rent > 25.0 A

• Or
• Power stage

temperature >

150° C

• Or
• Fault pattern

for short circuit

via power

stage diagno‐

sis detected

• Injector current

rise time during

peak phase <

0.064 ms

Injection

Valves

Electrical

Error

Open Cir‐

cuit

• Fault pattern

for open circuit

via power

stage diagno‐

sis detected

• Injector low

side voltage <

2.0 V

• Engine stop not

active

• ECT @ cylinder

head >= -30° C

• Engine speed <

7,000 RPM

• Injection time >=

0.0 s

Injection

Valves

Electrical

Error

Short Cir‐

cuit

• Fault pattern

for short circuit

via power

stage diagno‐

sis detected

• Injector current

rise time during

peak phase <

0.064 ms

P0221

Throttle/

Pedal

Position

Sensor/

Switch

"B" Cir‐

cuit

Range/

Per‐

for‐

mance

Throttle

Position

Sensor 2

Rationali‐

ty Check

• Normalized dif‐

ference be‐

tween meas‐

ured and mod‐

eled value of

mass air flow

from TPS 2 >=

1.0 [-]

• Throttle adaption

not active

• 0.01 s
• Contin‐

uous

• 2

DCY

– Check the Throt‐

tle Valve Control

Module - GX3- .

Refer to

⇒ “3.6.31  Throt‐

tle Valve Control

Module GX3 ,

Checking”, page

524

 .
