Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 68

♦ Child Safety Lock Button - E318-

❑ Removing and installing. Refer to

⇒ “2.19  Power Window Control Head in Driver Door E512 , Removing and Installing”, page 270

 .

No Illustration
♦ Interior Monitoring and Vehicle Inclination Deactivation Button

- E616- . Refer to

⇒ “2.22  Interior Monitoring And Vehicle Inclination Deactiva‐

tion Button E616 , Removing and Installing”, page 272

 .

♦ Driver Door Contact Switch - F2- and Front Passenger Door

Contact Switch - F3- . Refer to

⇒ “2.23 Driver and Front Passenger Door Contact Switch F2 /

F3 , Removing and Installing”, page 273

 .

2.3

Component Location Overview - Controls in Rear Doors

1 - Driver Side Rear Power

Window Button - E711-

❑ Removing and instal‐

ling. Refer to

⇒ “2.24 Driver and Pas‐

senger Side Rear Pow‐

er Window Button

E711 / E713 , Removing

and Installing”,

page 273

 .

2 - Passenger Side Rear Pow‐

er Window Button - E713-

❑ Removing and instal‐

ling. Refer to

⇒ “2.24 Driver and Pas‐

senger Side Rear Pow‐

er Window Button

E711 / E713 , Removing

and Installing”,

page 273

 .

No Illustration
♦ Left Rear Door Contact Switch - F10- and Right Rear Door

Contact Switch - F11- . Refer to

⇒ “2.25 Left/Right Rear Door Contact Switch F10 / F11 , Re‐

moving and Installing”, page 273

 .

2.4

Component Location Overview - Controls in Center Console

1 - Start System Button - E378-

❑ Removing and instal‐

ling. Refer to

⇒ “2.26  Start System

Button E378 , Removing

and Installing”,

page 273

 .

2 - Center Console Switch

Module 2 - EX30-
♦ Parking Aid Button - E266-
♦ Parallel Parking Assistance

Button - E581-

❑ The individual buttons

are installed in the

switch module and can‐

not be replaced sepa‐

rately.

❑ Removing and instal‐

ling. Refer to

⇒ “2.14 Center Console

Switch Module 1 and 2

EX23 / EX30 , Remov‐

ing and Installing”, page

267

 .

3 - Center Console Switch

Module 1 - EX23-
♦ ASR/ESP Button - E256-
♦ Driving Program Button -

E598-

♦ Start/Stop Mode Button -

E693-

❑ The individual buttons

are installed in the

switch module and can‐

not be replaced sepa‐

rately.

❑ Removing and installing. Refer to

⇒ “2.14 Center Console Switch Module 1 and 2 EX23 / EX30 , Removing and Installing”, page 267

 .

2.5

Component Location Overview - Controls in Luggage Compartment

1 - Rear Lid Contact Switch

❑ Rear Lid Alarm Switch -

F123-

❑ Removing and instal‐

ling. Refer to

⇒ “2.27 Rear Lid Con‐

tact Switch, Removing

and Installing”,

page 274

 .

2.6

Component Location Overview - Controls in Roof Trim Panel

1 - Driver Vanity Mirror Lamp

Contact Switch - F147-

❑ Cannot be replaced

separately if faulty.

❑ Removing and instal‐

ling. Refer to

⇒ “2.28 Driver and Front

Passenger Vanity Mirror

Lamp Contact Switch

F147 / F148 , Removing

and Installing”,

page 274

 .

2 - Rear Interior Lamp - W43-

Button

❑ In the Rear Interior

Lamp - WX2-

❑ Removing and instal‐

ling. Refer to

⇒ “2.31 Rear Interior

Lamp/Reading Lamp,

Removing and Instal‐

ling”, page 275

 .

3 - Front Passenger Vanity Mir‐

ror Lamp Contact Switch -

F148-

❑ Cannot be replaced

separately if faulty.

❑ Removing and instal‐

ling. Refer to

⇒ “2.28 Driver and Front

Passenger Vanity Mirror

Lamp Contact Switch

F147 / F148 , Removing

and Installing”,

page 274

 .

4 - Rear Interior Lamp - W43-

Button

❑ In the Front Interior Lamp - WX1-
❑ Removing and installing. Refer to

⇒ “2.30 Front Interior Lamp/Reading Lamp, Removing and Installing”, page 275

 .

5 - Right Front Reading Lamp Button - E634-

❑ In the Front Interior Lamp - WX1-
❑ Removing and installing. Refer to

⇒ “2.32 Left/Right Front Reading Lamp Button E633 / E634 , Removing and Installing”, page 277

 .

6 - Left Front Reading Lamp Button - E633-

❑ In the Front Interior Lamp - WX1-
❑ Removing and installing. Refer to

⇒ “2.32 Left/Right Front Reading Lamp Button E633 / E634 , Removing and Installing”, page 277

 .

7 - Front Interior Lamp - W1- Button

❑ In the Front Interior Lamp - WX1-
❑ Removing and installing. Refer to

⇒ “2.30 Front Interior Lamp/Reading Lamp, Removing and Installing”, page 275

 .

8 - Sunroof Button - E325-

❑ Bolt: 1 Nm
❑ In the Front Interior Lamp - WX1-
