47-26
Note:
Pre-bleeding brake caliper
- Screw piston into housing by
turning knurled wheel clockwise.
Use special tool 3272/1 to help
screw in.
If the piston is pushed back with
a piston resetting tool or by
operating the foot brake the
automatic adjustment in the
brake caliper is destroyed.
- Install brake pads.
Note:
Position brake caliper as illustrated
to pre-bleed.
- Open bleed valve (arrow -A-) and
using a standard bleeder bottle,
with brake fluid until bubble-free
brake fluid flows from the
threaded hole (arrow -B-) (brake
hose connection).
- Close bleed valve.
Rear brake caliper, servicing
