94-6
Installing
CAUTION!
Do not touch glass portion of bulb
with bare hands. Even the
smallest amount of moisture
and/or contaminants from fingers
that evaporates on the bulb
during operation can cause the
glass to cloud over.
- Disconnect electrical connector -
1- from bulb.
- Push retaining clip -2- over the
lugs -3- and release.
- Pull bulb -4- out of reflector.
- Insert new bulb so lugs on bulb
plate align with cut-outs in
reflector.
- Connect electrical connector -1-.
- Install sealing cover.
- Check headlight (bulb) function.
Headlights - Golf
13/2/2005
