What to do if... (Troubleshooting)

COROLLA_TMMMS_TMMC_U

●

The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (

P. 177)

●

The seat belt reminder light is flashing
Are the driver and the passenger wearing the seat belts? (

P. 481)

●

The brake system warning light is on
Is the parking brake released? (

P. 192)

Depending on the situation, other types of warning buzzer may also sound.

(

P. 480, 489)

●

Is the electronic key left inside the vehicle?
Check the message on the multi-information display. (

P. 489)

●

Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (

P. 69)



Vehicles without a smart key system
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.



Vehicles with a smart key system
To stop the alarm, turn the engine switch to IGNITION ON mode or start
the engine.

●

When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 480, 489.

The engine switch is turned off automatically
(vehicles with a smart key system)

A warning buzzer sounds during driving

A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)

An alarm is activated and the horn sounds
(vehicles with an alarm)

A warning light turns on or a warning message or indicator
is displayed

595

COROLLA_TMMMS_TMMC_U

Alphabetical index
