Toyota Corolla (2019 year). Instruction - part 18

273

5-1. Basic Operations

5

Audi

o system

COROLLA_TMMMS_TMMC_U

Entune Audio





: If equipped



With an Entune Audio

Operations  such  as  listening  to  audio,  using  the  hands-free
phone and changing Entune Audio settings are started by using
the following buttons.



With an Entune Audio Plus

Owners  of  this  system  should  refer  to  the  “NAVIGATION  AND
MULTIMEDIA SYSTEM OWNER'S MANUAL”.

Entune Audio operation buttons

Display the “Select Audio Source”
screen or audio top screen.
(

P. 284)

Press this button to access the
Bluetooth

®

hands-free system.

(

P. 322)

Press this button to access the fuel consumption screen.
(

P. 96)

Press this button to customize the function settings. (

P. 278)

274

5-1. Basic Operations

COROLLA_TMMMS_TMMC_U

By touching the screen with your finger, you can control Entune Audio,
etc.

■

Drag

*

Touch  the  screen  with  your  finger,  and  move  the  screen  to  the
desired position.
● Scrolling the lists

■

Flick

*

Touch the screen with your finger and quickly move the screen by
flicking your finger.
● Scrolling the main screen page

*

: The above operations may not be performed on all screens.

■

Capacitive touch switches
The control panel uses capacitive touch sensors.

●

In the following cases, incorrect operation or non-response may occur.
• If the operating section is dirty or has liquid attached to it, incorrect opera-

tion or non-response may occur.

• If the operating section receives electromagnetic waves, incorrect opera-

tion or non-response may occur.

• If wearing gloves during operation, non-response may occur.
• If fingernails are used to operate the system, non-response may occur.
• If a touch pen is used to operate the system, non-response may occur.
• If the palm of your hand touches the operating section during operation,

incorrect operation may occur.

• If the palm of your hand touches the operating section, incorrect opera-

tion may occur.

• If operations are performed quickly, non-response may occur.

●

Please do not reach your hand to the part of button when Entune Audio turn
on. Because the button may become unresponsive for a while. But it will be
back to normal for a given time even if Entune Audio turned on under the
condition.

■

When using the touch screen

●

If the screen is cold, the display may be dark, or the system may seem to be
operating slightly slower than normal.

●

The  screen  may  seem  dark  and  hard  to  see  when  viewed  through  sun-
glasses. Change your angle of viewing, adjust the display on the “Display
Settings” screen (

P. 282) or remove your sunglasses.

●

Flick operations may not be performed smoothly in high altitudes.

Operating the touch screen

275

5-1. Basic Operations

5

Audi

o system

COROLLA_TMMMS_TMMC_U

NOTICE

■

To avoid damaging the touch screen

●

To prevent damaging the screen, lightly touch the screen buttons with your
finger.

●

Do not use objects other than your finger to touch the screen.

●

Wipe  off  fingerprints  using  a  glass  cleaning  cloth.  Do  not  use  chemical
cleaners to clean the screen, as they may damage the touch screen.

276

5-1. Basic Operations

COROLLA_TMMMS_TMMC_U

Basic audio operations

Basic audio operations and functions common to each mode are
explained in this section.

Operating Entune Audio

Press the “

” or “” button to

seek up or down for a radio
station, or to access a desired
track or file.

Press this knob to turn Entune Audio on and off,
and turn it to adjust the volume.

Press this button
to eject a disc

Press to pause or
resume playing music.

Insert a disc into
the disc slot

 :Select to pause music.

Turn this knob to select radio
station bands, tracks and files.
Also the knob can be used to
select items in the list display.

 :Select to resume playing music.

277

5-1. Basic Operations

5

Audi

o system

COROLLA_TMMMS_TMMC_U

Select

 to change on/off.

Select

 to change on/off.

■

Using cellular phones
Interference  may  be  heard  through  Entune  Audio’s  speakers  if  a  cellular
phone is being used inside or close to the vehicle while Entune Audio is oper-
ating.

Random playback

Repeat play

WARNING

■

Laser product
This product is a class 1 laser product.
Do not open the cover of the player or attempt to repair the unit yourself.
Refer servicing to qualified personnel.

●

Laser products
• Do not take this unit apart or attempt to make any changes yourself.

This is an intricate unit that uses a laser pickup to retrieve information
from  the  surface  of  compact  discs.  The  laser  is  carefully  shielded  so
that its rays remain inside the cabinet. Therefore, never try to disassem-
ble the player or alter any of its parts since you may be exposed to laser
rays and dangerous voltages.

• This product utilizes a laser.

Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL
INCREASE EYE HAZARD.

NOTICE

■

To prevent battery discharge
Do not leave Entune Audio on longer than necessary when the engine is off.

■

To avoid damaging Entune Audio
Take care not to spill drinks or other fluids on Entune Audio.

278

COROLLA_TMMMS_TMMC_U

5-2. Setup

Press the “SETUP” button to display the “Setup” screen.

Select to adjust the settings for
operation  sounds,  screen  ani-
mation, etc. (

P. 279)

Select to set the voice settings.
(

P. 283)

Select to adjust the settings for
contrast  and  brightness  of  the
screen. (

P. 282)

Select  to  adjust  the  settings  for  registering,  removing,  connecting
and disconnecting Bluetooth

®

 devices. (

P. 319)

Select to adjust the settings for phone sound, contact, etc.
(

P. 341)

Select to set audio settings. (

P. 281)

Select to turn the screen off.
Select to set the vehicle customization (

P. 564).

Setup menu

You can adjust Entune Audio to your desired settings.

Display “Setup” screen

1

2

3

4

5

6

7

8

279

5-2. Setup

5

Audi

o system

COROLLA_TMMMS_TMMC_U

Press the “SETUP” button.
Select “General” on the “Setup”
screen.

“English”,

“Français”

or

“Español” can be selected.
On/off  can  be  selected  to
sound beeps.
Select  to  change  the  screen
color.
Select  to  change  the  key-
board layout.
Select to change the capaci-
tive touch button sensor sen-
sitivity.
The animation effect for the screen can be set to on/off.
Select to delete personal data (

P. 280)

Select  to  update  program  versions.  For  details,  contact  your
Toyota dealer.
Select to display the software information. Notices related to third
party  software  used  in  this  product  are  enlisted.  (This  includes
instructions for obtaining such software, where applicable.)

■

To return to the default volume settings
Select “Default”, and then “Yes”.

General settings

Settings  are  available  for  adjusting  the  operation  sounds,
screen animation, etc.

Screen for general settings

1

2

1

2

3

4

5

6

7

8

9

280

5-2. Setup

COROLLA_TMMMS_TMMC_U

Select “Delete Personal Data” on the “General Settings” screen.
Select “Delete”.

Check carefully beforehand, as data cannot be retrieved once deleted.

A confirmation screen will be displayed. Select “Yes”.
The following personal data will be deleted or changed to its default
settings.

• General settings
• Audio settings
• Phone settings

Delete personal data

1

2

3

281

5-2. Setup

5

Audi

o system

COROLLA_TMMMS_TMMC_U

Press the “SETUP” button.
Select “Audio” on the “Setup” screen.

Number of Radio Presets
Select  the  number  of  radio
preset stations.
Display Cover Art on/off
Automatic Sound Levelizer

Select “Automatic Sound Levelizer”.
Select “High”, “Mid”, “Low” or “Off”.

■

About Automatic Sound Leveliser (ASL)
ASL automatically adjusts the volume and tone quality according to the vehi-
cle speed.

Audio settings

Settings  are  available  for  adjusting  the  radio  operation,  cover
art, etc.

Screen for audio settings

1

2

1

2

3

Automatic sound leveliser (ASL)

1

2

282

5-2. Setup

COROLLA_TMMMS_TMMC_U

Press the “SETUP” button.
Select “Display” on the “Setup” screen.

Adjust screen contrast/bright-
ness
Adjust screen contrast/bright-
ness of the rear view monitor
camera
Changes to day mode.

Select “General” on the “Display Settings” screen.
Adjust the display as desired by selecting “+” or “-”.

When the headlights are turned on, the screen dims.
However, the screen can be switched to day mode by selecting “Day
Mode”.

The screen will stay in day mode when the headlights are turned on until
“Day Mode” is selected again.

Display settings

Settings are available for adjusting the contrast and brightness
of the screen.

Screen for display settings

1

2

1

2

3

Adjusting the screen contrast/brightness

Day mode

1

2

283

5-2. Setup

5

Audi

o system

COROLLA_TMMMS_TMMC_U

Adjust  the  voice  guidance  vol-
ume setting.
Set  the  voice  recognition
prompts “High”, “Low” or “Off”.
Set the train voice recognition.
Set  the  voice  prompt  interrupt
on/off.
Set  the  voice  recognition  tuto-
rial.

■

To return to the default volume settings
Select “Default”, and then “Yes”.

Voice settings

This  screen  is  used  for  guidance  for  voice  command  systems
setting.

1

2

3

4

5

284

COROLLA_TMMMS_TMMC_U

5-3. Using Entune Audio

Press  the  “AUDIO”  button  to  display  the  audio  source  selection
screen.

If the audio source selection screen is not displayed, press the “AUDIO”
button again.

Select  the  desired  audio
source.

Select  the  desired  audio
source  then

  or

  to

reorder.

The  audio  source  changes  as  follows  each  time  the  “MODE/HOLD”
switch is pressed.

Selecting the audio source

Switching  between  audio  sources  such  as  radio  and  CD  are
explained in this section.

Changing audio source

1

2

1

Using the steering wheel switches to change audio source

285

5-3. Using Entune Audio

5

Audi

o system

COROLLA_TMMMS_TMMC_U



: Select to scroll to the next

or previous page.

: If

  appears  to  the  right  of

titles,  the  complete  titles  are
too long for the display. Select
this button to scroll the title.

Turn  the  “TUNE·SCROLL”  knob
to move the cursor box to select a
desired  item  from  the  list,  and
press  the  “TUNE·SCROLL”  knob
to  play  it.  The  track  that  is  being
played is highlighted.
To return to the top screen, select “Now Playing” on the list screen.

List screen operation

When a list screen is displayed, use the appropriate buttons to
scroll through the list.

How to scroll

286

5-3. Using Entune Audio

COROLLA_TMMMS_TMMC_U

■

Selecting a track/file/song
Press  the  “

”  or  “”  button  on  “SEEK·TRACK”  or  turn  the

“TUNE·SCROLL” knob to select the desired track/file/song number.
To fast-forward or reverse, press and hold the “

” or “” button on

“SEEK·TRACK”.

■

Selecting a track/file/song from the track/file/song list

Select “Browse” or cover art.
Select  the  desired  track/file/
song.

When an MP3/WMA/AAC disc or USB memory device is being used,
the folder can be selected. When a Bluetooth

®

 device or iPod is being

used, the album can be selected.
According to the audio device, the following is displayed.

Selecting, fast-forwarding and reversing tracks/files/songs

1

2

Audio source

List name

Audio CD

Track

MP3/WMA/AAC disc

Folder, File

Bluetooth

®

Album, Track

USB

Artists,  Albums,  Songs,  Genres,
Composers

iPod

Artists,  Albums,  Songs,  Genres,
Composers, Audiobooks, Videos

287

5-3. Using Entune Audio

5

Audi

o system

COROLLA_TMMMS_TMMC_U

Select “-” or “+” to adjust
the treble, mid or bass to
a level between -5 and 5.

Select  “Front”  or  “Rear”  to
adjust  the  front/rear  audio
balance.
Select “L” or “R” to adjust the
left/right audio balance.

■

The sound quality level is adjusted individually
The treble, mid and bass levels can be adjusted for each audio mode sepa-
rately.

Optimal use of Entune Audio

On  the  “Sound  Settings”  screen,  sound  quality  (Treble/Mid/
Bass), volume balance can be adjusted.

How to adjust the sound settings and sound quality

1

2

3

4

5

6

7

288

COROLLA_TMMMS_TMMC_U

5-4. Using the radio

Pressing the “AUDIO” button displays the audio control screen from
any screens of the selected source.

Audio  source  selection  screen
appears
Preset stations
Select  to  display  RBDS  text
messages

*

Scanning for receivable station
Select to display a list of receiv-
able stations
Setting the sound (

P. 287)

*

: FM only

Tune in to the desired station using one of the following methods.

■

Seek tuning
Press the “

” or “” button on “SEEK·TRACK”.

The radio will begin seeking up or down for a station of the nearest
frequency and will stop when a station is found.

■

Manual tuning
Turn the “TUNE·SCROLL” knob.

■

Preset stations
Select the desired preset station.

Radio operation

Select  “AM”  or  “FM”  on  the  audio  source  selection  screen  to
begin listening to the radio.

Audio control screen

1

2

3

4

5

6

Selecting a station
