Toyota Corolla (2019 year). Instruction - part 17

257

4-5. Using the driving support systems

Drivin

COROLLA_TMMMS_TMMC_U

◆

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the brakes are applied suddenly,
or if the brakes are applied while driving on a slippery road surface

◆

Brake assist

Generates an increased level of braking force after the brake pedal
is depressed when the system detects a panic stop situation

◆

VSC (Vehicle Stability Control)

Helps the driver to control skidding when swerving suddenly or
turning on slippery road surfaces

◆

TRAC

(Traction Control)

Helps to maintain drive power and prevent the drive wheels from
spinning when starting the vehicle or accelerating on slippery roads

◆

Hill-start assist control

Helps to reduce the backward movement of the vehicle when start-
ing on an uphill

◆

EPS (Electric Power Steering)

Employs an electric motor to reduce the amount of effort needed to
turn the steering wheel

Driving assist systems

To keep driving safety and performance, the following systems
operate automatically in response to various driving situations.
Be aware, however, that these systems are supplementary and
should not be relied upon too heavily when operating the vehi-
cle.

258

4-5. Using the driving support systems

COROLLA_TMMMS_TMMC_U

The slip indicator light will flash
while the TRAC/VSC systems are
operating.

If the vehicle gets stuck in mud, dirt or snow, the TRAC system may

reduce power from the engine to the wheels. Pressing

to turn the

system off may make it easier for you to rock the vehicle in order to
free it.

To turn the TRAC system off, quickly press and release

Press

again to turn the system back on.

When the TRAC/VSC systems are operating

Disabling the TRAC system



Vehicles with a monochrome
display

The “TRAC OFF” indicator light
will come on.



Vehicles with a color display

“Traction Control Turned Off” will
be shown.

259

4-5. Using the driving support systems

Drivin

COROLLA_TMMMS_TMMC_U

■

Turning off both TRAC and VSC systems
To turn the TRAC and VSC systems off, press and hold

for more than 3

seconds while the vehicle is stopped.
The “TRAC OFF” indicator light and VSC OFF indicator light will come on.

(vehicles with a monochrome display)
“Traction Control Turned Off” will be shown and VSC OFF indicator light will
come on.

(vehicles with a color display)

Press

again to turn the systems back on.

: Pre-collision brake assist and pre-collision braking will also be disabled.

The pre-collision system warning light will come on and the message will be
shown on the multi-information display. (

P. 225)

■

When the “TRAC OFF” indicator light comes on even if

has not been

pressed (vehicles with a monochrome display)
TRAC cannot be operated. Contact your Toyota dealer.

■

When “Traction Control Turned Off” is shown even if

has not been

pressed (vehicles with a color display)
TRAC cannot be operated. Contact your Toyota dealer.

■

Sounds and vibrations caused by the ABS, brake assist, VSC, TRAC and
hill-start assist control systems

●

A sound may be heard from the engine compartment when the brake pedal
is depressed repeatedly, when the engine is started or just after the vehicle
begins to move. This sound does not indicate that a malfunction has
occurred in any of these systems.

●

Any of the following conditions may occur when the above systems are
operating. None of these indicates that a malfunction has occurred.
• Vibrations may be felt through the vehicle body and steering.
• A motor sound may be heard also after the vehicle comes to a stop.
• The brake pedal may pulsate slightly after the ABS is activated.
• The brake pedal may move down slightly after the ABS is activated.

■

EPS operation sound
When the steering wheel is operated, a motor sound (whirring sound) may be
heard. This does not indicate a malfunction.

■

Automatic reactivation of TRAC and VSC systems
After turning the TRAC and VSC systems off, the systems will be automati-
cally re-enabled in the following situations:

●

Vehicles without a smart key system: When the engine switch is turned to
the “LOCK” position
Vehicles with a smart key system: When the engine switch is turned off

●

If only the TRAC system is turned off, the TRAC will turn on when vehicle
speed increases
If both the TRAC and VSC systems are turned off, automatic re-enabling will
not occur when vehicle speed increases.

260

4-5. Using the driving support systems

COROLLA_TMMMS_TMMC_U

■

Reduced effectiveness of the EPS system
The effectiveness of the EPS system is reduced to prevent the system from
overheating when there is frequent steering input over an extended period of
time. The steering wheel may feel heavy as a result. Should this occur, refrain
from excessive steering input or stop the vehicle and turn the engine off. The
EPS system should return to normal within 10 minutes.

■

Operating conditions of hill-start assist control
When the following four conditions are met, the hill-start assist control will
operate:

●

Vehicles with a continuously variable transmission: The shift lever is in a
position other than P or N (when starting off forward/backward on an upward
incline)

●

Vehicles with a manual transmission: The shift lever is in a position other
than R when starting off forward on an upward incline, or the shift lever is in
R when starting off backward on an upward incline.

●

The vehicle is stopped

●

The accelerator pedal is not depressed

●

The parking brake is not engaged

■

Automatic system cancelation of hill-start assist control
The hill-start assist control will turn off in any of the following situations:

●

Vehicles with a continuously variable transmission: The shift lever is shifted
to P or N

●

Vehicles with a manual transmission: The shift lever is shifted to R when
starting off forward on an upward incline, or the shift lever is shifted to other
than R when starting off backward on an upward incline.

●

The accelerator pedal is depressed

●

The parking brake is engaged

●

2 seconds at maximum elapsed after the brake pedal is released

261

4-5. Using the driving support systems

Drivin

COROLLA_TMMMS_TMMC_U

WARNING

■

The ABS does not operate effectively when

●

The limits of tire gripping performance have been exceeded (such as
excessively worn tires on a snow covered road).

●

The vehicle hydroplanes while driving at high speed on wet or slick roads.

■

Stopping distance when the ABS is operating may exceed that of nor-
mal conditions
The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you, especially in the
following situations:

●

When driving on dirt, gravel or snow-covered roads

●

When driving with tire chains

●

When driving over bumps in the road

●

When driving over roads with potholes or uneven surfaces

■

TRAC/VSC may not operate effectively when
Directional control and power may not be achievable while driving on slip-
pery road surfaces, even if the TRAC/VSC system is operating.
Drive the vehicle carefully in conditions where stability and power may be
lost.

■

Hill-start assist control does not operate effectively when

●

Do not overly rely on hill-start assist control. Hill-start assist control may
not operate effectively on steep inclines and roads covered with ice.

●

Unlike the parking brake, hill-start assist control is not intended to hold the
vehicle stationary for an extended period of time. Do not attempt to use
hill-start assist control to hold the vehicle on an incline, as doing so may
lead to an accident.

■

When the TRAC/VSC is activated
The slip indicator light flashes. Always drive carefully. Reckless driving may
cause an accident. Exercise particular care when the indicator light flashes.

■

When the TRAC/VSC systems are turned off
Be especially careful and drive at a speed appropriate to the road condi-
tions. As these are the systems to help ensure vehicle stability and driving
force, do not turn the TRAC/VSC systems off unless necessary.

262

4-5. Using the driving support systems

COROLLA_TMMMS_TMMC_U

WARNING

■

Replacing tires
Make sure that all tires are of the specified size, brand, tread pattern and
total load capacity. In addition, make sure that the tires are inflated to the
recommended tire inflation pressure level.
The ABS, TRAC and VSC systems will not function correctly if different tires
are installed on the vehicle.
Contact your Toyota dealer for further information when replacing tires or
wheels.

■

Handling of tires and the suspension
Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause a system to malfunction.

263

Drivin

COROLLA_TMMMS_TMMC_U

4-6. Driving tips

● Use fluids that are appropriate to the prevailing outside tempera-

tures.

• Engine oil
• Engine coolant
• Washer fluid

● Have a service technician inspect the condition of the battery.
● Have the vehicle fitted with four snow tires or purchase a set of tire

chains for the front tires.

Ensure that all tires are the same size and brand, and that chains match
the size of the tires.

Perform the following according to the driving conditions:
● Do not try to forcibly open a window or move a wiper that is frozen.

Pour warm water over the frozen area to melt the ice. Wipe away
the water immediately to prevent it from freezing.

● To ensure proper operation of the climate control system fan,

remove any snow that has accumulated on the air inlet vents in
front of the windshield.

● Check for and remove any excess ice or snow that may have accu-

mulated on the exterior lights, vehicle’s roof, chassis, around the
tires or on the brakes.

● Remove any snow or mud from the bottom of your shoes before

getting in the vehicle.

Winter driving tips

Carry out the necessary preparations and inspections before
driving the vehicle in winter. Always drive the vehicle in a man-
ner appropriate to the prevailing weather conditions.

Preparation for winter

Before driving the vehicle

264

4-6. Driving tips

COROLLA_TMMMS_TMMC_U

Accelerate the vehicle slowly, keep a safe distance between you and
the vehicle ahead, and drive at a reduced speed suitable to road con-
ditions.

● Park the vehicle and move the shift lever to P (continuously variable

transmission), 1 or R (manual transmission) without setting the
parking brake. The parking brake may freeze up, preventing it from
being released. If the vehicle is parked without setting the parking
brake, make sure to block the wheels.
Failure to do so may be dangerous because it may cause the vehi-
cle to move unexpectedly, possibly leading to an accident.

● Vehicles with a continuously variable transmission: If the vehicle is

parked without setting the parking brake, confirm that the shift lever
cannot be moved out of P

: The shift lever will be locked if it is attempted to be shifted from P to any

other position without depressing the brake pedal. If the shift lever can be
shifted from P, there may be a problem with the shift lock system. Have the
vehicle inspected by your Toyota dealer immediately

When driving the vehicle

When parking the vehicle

265

4-6. Driving tips

Drivin

COROLLA_TMMMS_TMMC_U



Vehicles with 15-inch tires

Use the tire chains of correct size and type.

Use SAE Class “S” type radial tire chains except radial cable chains or
V-bar type chains.



Vehicles with 16-inch and 17-inch tires

Use the correct tire chain size when mounting the snow chains.
Chain size is regulated for each tire size.
Side chain:

0.12 in. (3 mm) in diameter
0.39 in. (10 mm) in width
1.18 in. (30 mm) in length

Cross chain:

0.16 in. (4 mm) in diameter
0.55 in. (14 mm) in width
0.98 in. (25 mm) in length

Regulations regarding the use of tire chains vary depending on loca-
tion and type of road. Always check local regulations before installing
chains.

■

Tire chain installation
Observe the following precautions when installing and removing chains:

●

Install and remove tire chains in a safe location.

●

Install tire chains on the front tires. Do not install tire chains on the rear tires.

●

Install tire chains on front tires as tightly as possible. Retighten chains after
driving 1/4

 1/2 mile (0.5  1.0 km).

●

Install tire chains following the instructions provided with the tire chains.

Selecting tire chains

Regulations on the use of tire chains

266

4-6. Driving tips

COROLLA_TMMMS_TMMC_U

WARNING

■

Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
serious injury.

●

Use tires of the size specified.

●

Maintain the recommended level of air pressure.

●

Do not drive in excess of 75 mph (120 km/h), regardless of the type of
snow tires being used.

●

Use snow tires on all, not just some wheels.

■

Driving with tire chains
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.

●

Do not drive in excess of the speed limit specified for the tire chains being
used, or 30 mph (50 km/h), whichever is lower.

●

Avoid driving on bumpy road surfaces or over potholes.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.

●

Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.

●

Do not use LDA (Lane Departure Alert with steering control) system.

NOTICE

■

Repairing or replacing snow tires (vehicles with a tire pressure

warning system)
Request repairs or replacement of snow tires from Toyota dealers or

legitimate tire retailers.

This is because the removal and attachment of snow tires affects the

operation of the tire pressure warning valves and transmitters.

■

Fitting tire chains (vehicles with a tire pressure warning system)
The tire pressure warning valves and transmitters may not function cor-

rectly when tire chains are fitted.

267

4-6. Driving tips

Drivin

COROLLA_TMMMS_TMMC_U

269

Audio system

COROLLA_TMMMS_TMMC_U

5-6. Using an external

device

Listening to an iPod .......... 296
Listening to a USB

memory device................ 301

Using the AUX port ........... 305

5-7. Connecting Bluetooth

Preparations to use

wireless
communication................ 306

Registering a Bluetooth

audio player for the
first time .......................... 310

Registering a Bluetooth

phone for the first time .... 311

Registering a Bluetooth

device.............................. 312

Connecting a Bluetooth

device.............................. 315

Displaying a Bluetooth

device details .................. 318

Detailed Bluetooth

system settings ............... 319

5-8. Bluetooth

Audio

Listening to Bluetooth

Audio............................... 320

5-9. Bluetooth

phone

Using a Bluetooth

Phone ............................. 322

Making a call ..................... 325
Receiving a call................. 328
Speaking on the phone ..... 329
Bluetooth

phone

message function............ 333

Using the steering wheel

switches .......................... 338

Bluetooth

phone

settings ........................... 339

Contact/

Call History Settings ....... 341

What to do if...

(Troubleshooting)............ 351

5-10. Bluetooth

Bluetooth

......................... 355

5-11. Using the voice

command system

Voice command system.... 359

270

COROLLA_TMMMS_TMMC_U

5-1. Basic Operations



Entune Audio

P. 273



Entune Audio Plus or Entune Premium Audio

Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

Audio system types

271

5-1. Basic Operations

Audi

o system

COROLLA_TMMMS_TMMC_U

Volume switch

• Increases/decreases volume
• Press and hold: Continuously increases/decreases volume

Cursor switch

• Selects (radio stations/radio presets/tracks/files/songs)
• Moves cursor
• Press and hold: Seeks up/down (radio stations)
• Fast up/down (tracks/files)

“MODE/HOLD” switch:

• Changes audio source
• Press and hold: Mutes or pauses the current operation.

To cancel the mute or pause, press and hold again.

Steering wheel audio switches

Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of audio system or
navigation system. For details, refer to the manual provided with
the audio system or navigation system.

Operating the audio system using the steering wheel switches



Type A



Type B

WARNING

■

To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.

272

5-1. Basic Operations

COROLLA_TMMMS_TMMC_U

■

iPod
Open the cover and connect an
iPod using an iPod cable.

Turn on the power of the iPod if
it is not turned on.

■

USB memory
Open the cover and connect a USB memory device.

Turn on the power of the USB memory device if it is not turned on.

■

Portable audio player
Open the cover and connect a portable audio player.

Turn on the power of the portable audio player if it is not turned on.

■

AUX port
The AUX port only supports audio input.

AUX port/USB port

Connect an iPod, USB memory device or portable audio player
to the AUX port/USB port as indicated below. Select “iPod”,
“USB” or “AUX” on the audio source selection screen and the
device can be operated via audio system.

Connecting using the AUX port/USB port

WARNING

■

While driving
Do not connect a device or operate the device controls.

Content .. 15 16 17 18 ..
