Toyota Tacoma (2018 year). Instruction - part 9

136

3-3. Adjusting the seats

Head restraints

Head restraints are provided for all seats.

Front seats

Vertical adjustment

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while

pressing the lock release button.

Lock release button

Rear seats

 Access Cab models

Folding the head restraints

1

To use

Lift up the head restraint until it

locks.

2

To fold

Pull the head restraint lock release

lever to fold the head restraint.

3-3. Adjusting the seats

137

 Double Cab models

Folding the head restrains (outer head restraints)

1

To use

Lift up and push down the head

restraint to the lowest lock position.

2

To fold

Pull the head restraint up while

pressing the lock release buttons.

Lock release button

Vertical adjustment (center head restraint)

3

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while

pressing the lock release button.

Lock release button

138

3-3. Adjusting the seats

■ Removing the head restraints

Front seats

Pull the head restraint up while pressing

the lock release button.

Lock release button

 Rear seats (Double Cab models only)

Outer head restraints: Pull the head

restraint up while pressing the both lock

release buttons.

Center head restraints: Pull the head

restraint up while pressing the lock

release button.

Lock release button

■ Installing the head restraints

Front seats

Align the head restraint with the installa-

tion holes and push it down to the lock

position.

Rear center head restraint: Press and

hold the lock release button when low-

ering the head restraint.

Lock release button

 Rear seats (Double Cab models only)

Align the head restraint with the installa-

tion holes and push it down to the lock

position.

Rear center head restraint: Press and

hold the lock release button when low-

ering the head restraint.

Lock release button

3-3. Adjusting the seats

139

■Adjusting the height of the head restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

■ Adjusting the rear center seat head restraint (Double Cab models only)

Always raise the head restraint one level from the stowed position when

using.

WARNING

3

■ Head restraint precautions

Observe the following precautions regarding the head restraints.

Failure to do so may result in death or serious injury.

● Use the head restraints designed for each respective seat.

● Adjust the head restraints to the correct position at all times.

● After adjusting the head restraints, push down on them and make sure

they are locked in position.

● Do not drive with the head restraints removed.

140

3-4. Adjusting the steering wheel and mirrors

Steering wheel

Adjustment procedure

Hold the steering wheel and

1

push the lever down.

Adjust to the ideal position by

2

moving the steering wheel hori-

zontally and vertically.

After adjustment, pull the lever up

to secure the steering wheel.

Horn

To sound the horn, press on or

close to the

mark.

■ After adjusting the steering wheel

Make sure that the steering wheel is securely locked.

The horn may not sound if the steering wheel is not securely locked.

142

3-4. Adjusting the steering wheel and mirrors

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable suffi-

cient confirmation of the rear view.

Adjusting the height of rear view mirror

The height of the rear view mirror can be adjusted to suit your driving

posture.

Adjust the height of the rear view

mirror by moving it up and down.

Anti-glare function

 Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced

by operating the lever.

1

Normal position

2

Anti-glare position

3-4. Adjusting the steering wheel and mirrors

143

 Auto anti-glare inside rear view mirror

Responding to the level of brightness of the headlights of vehicles

behind, the reflected light is automatically reduced.

 Type A

 Type B

3

Changing automatic anti-glare function mode

On/off

When the automatic anti-glare function is in on mode, the indicator illumi-

nates.

Vehicles without a smart key system:

The function will set to on mode each time the engine switch is turned to

the “ON” position.

Pressing the button turns the function to off mode. (The indicator also turns

off.)

Vehicles with a smart key system:

The function will set to on mode each time the engine switch is turned to

IGNITION ON mode.

Pressing the button turns the function to off mode. (The indicator also turns

off.)

144

3-4. Adjusting the steering wheel and mirrors

■ To prevent sensor error (vehicles with auto anti-glare inside rear view

mirror)

To ensure that the sensors operate prop-

erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and cause an accident,

resulting in death or serious injury.

3-4. Adjusting the steering wheel and mirrors

145

Outside rear view mirrors

Adjustment procedure

1

To select a mirror to adjust, turn

the switch.

1

Left

2

Right

3

2

To adjust the mirror, press the

switch.

1

Up

2

Right

3

Down

4

Left

Folding the mirrors

Push the mirror back in the direc-

tion of the vehicle’s rear.

146

3-4. Adjusting the steering wheel and mirrors

■ Mirror angle can be adjusted when

 Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.

 Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

■ When the mirrors are fogged up

Turn on the mirror defoggers to defog the mirrors. (P. 428, 435)

WARNING

■ Important points while driving

Observe the following precautions while driving.

Failure to do so may result in loss of control of the vehicle and cause an

accident, resulting in death or serious injury.

● Do not adjust the mirrors while driving.

● Do not drive with the mirrors folded.

● Both the driver and passenger side mirrors must be extended and properly

adjusted before driving.

■ When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your

hand caught by the moving mirror.

■ When the mirror defoggers are operating

Do not touch the rear view mirror surfaces, as they can become very hot

and burn you.

3-5. Opening, closing the windows and moon roof

147

Power windows

Opening and closing procedures

The power windows can be opened and closed using the switches.

Operating the switch moves the windows as follows:

 Type A

1

Closing

2

Opening

3

One-touch opening*

(driver’s

window only)

3

*: To stop the window partway, oper-

ate the switch in the opposite direc-

tion.

 Type B

1

Closing

2

One-touch closing* (front seat

windows)

3

Opening

4

One-touch opening* (front seat

windows)

*: To stop the window partway, oper-

ate the switch in the opposite direc-

tion.

Window lock switch

Press the switch down to lock the

passenger window switches.

Use this switch to prevent children

from accidentally opening or clos-

ing a passenger window.

148

3-5. Opening, closing the windows and moon roof

■The power windows can be operated when

 Vehicles without a smart key system

The engine switch is in the “ON” position.

 Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■ Operating the power windows after turning the engine off

 Vehicles without a smart key system

The power windows can be operated for approximately 45 seconds even

after the engine switch is turned to the “ACC” or “LOCK” position. They can-

not, however, be operated once either front door is opened.

 Vehicles with a smart key system

The power windows can be operated for approximately 45 seconds even

after the engine switch is turned to ACCESSORY mode or turned off. They

cannot, however, be operated once either front door is opened.

■ Jam protection function (type B only)

If an object becomes caught between the window and the window frame, win-

dow travel is stopped and the window is opened slightly.

■ When the power window does not close normally (type B only)

If the jam protection function is operating abnormally and a window cannot be

closed, perform the following operations using the power window switch on

the relevant door.

● After stopping the vehicle, the window can be closed by holding the power

window switch in the one-touch closing position while the engine switch is

turned to IGNITION ON mode.

● If the window still cannot be closed even by carrying out the operation as

explained above, initialize the function by performing the following proce-

dure.

1

Hold the power window switch in the one-touch closing position. Continue

holding the switch for a further 4 seconds after the window has closed.

If jam detection occurs during step

1

, repeat step

1

within 4 seconds of

jam occurrence.

Hold the power window switch in the one-touch opening position. Con-

2

tinue holding the switch for more than 1 second after the window has

opened completely.

Hold the power window switch in the one-touch closing position once

3

again. Continue holding the switch for more than 1 second after the win-

dow has closed.

If you release the switch while the window is moving, start again from the

beginning.

If the window continues to close but then re-open slightly even after perform-

ing the above procedure correctly, have the vehicle inspected by your Toyota

dealer.

3-5. Opening, closing the windows and moon roof

149

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■Closing the windows

● The driver is responsible for all the power window operations, including the

operation for the passengers. In order to prevent accidental operation,

especially by a child, do not let a child operate the power windows. It is

possible for children and other passengers to have body parts caught in

the power window. Also, when riding with a child, it is recommended to use

the window lock switch. (P. 147)

● Check to make sure that all passengers do not have any part of their body

in a position where it could be caught when a window is being operated.

3

● When exiting the vehicle, turn the engine switch to the “LOCK” position

(vehicles without a smart key system) or off (vehicles with a smart key sys-

tem), carry the key and exit the vehicle along with the child. There may be

accidental operation, due to mischief, etc., that may possibly lead to an

accident.

■ Jam protection function (type B only)

● Never use any part of your body to intentionally activate the jam protection

function.

● The jam protection function may not work if something gets caught just

before the window fully closes.

150

3-5. Opening, closing the windows and moon roof

Back window (vehicles with sliding type)

Opening and closing

Open/close

Push the lock release lever and

slide the back window.

■ Closing the back window

Make sure that the back window is securely closed after closing it.

WARNING

■Caution while driving

Keep the back window closed.

This not only keeps personal belongings from being thrown out, but also

prevents exhaust gases from entering the vehicle.

3-5. Opening, closing the windows and moon roof

151

Power back window

Opening and closing

1

Opening

2

Closing

3

■The power back window can be operated when

 Vehicles without a smart key system

The engine switch is in the “ON” position.

 Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■ Operating the power back window after turning the engine off

 Vehicles without a smart key system

The power back window can be operated for approximately 43 seconds even

after the engine switch is turned to the “ACC” or “LOCK” position. They can-

not, however, be operated once either front door is opened.

 Vehicles with a smart key system

The power back window can be operated for approximately 43 seconds even

after the engine switch is turned to ACCESSORY mode or turned off. It can-

not, however, be operated once either front door is opened.

: If equipped

Content   ..  7  8  9  10   ..
