102
2. Instrument cluster
■ Past record
If the “Trip Information” screen is displayed, select “Past Record”.
1
Resetting the past record
data
2
Best recorded fuel consump-
tion
3
Average fuel consumption (if
equipped)
4
Previous fuel consumption
record
5
Current fuel economy
6
Update the average fuel consumption data
The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.
These images are examples only.
■ Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
■ Updating the past record data
Update the average fuel consumption by selecting “Update” to measure the
current fuel consumption again.
■Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption. As a
result, the actual distance that can be driven may differ from that displayed.
103
Operation of
3
each component
3-1. Key information
3-5. Opening, closing the
Keys
104
windows and moon roof
Power windows
147
3-2. Opening, closing and
locking the doors
Back window (vehicles
with sliding type)
150
Doors
111
Power back window
151
Tailgate
118
Moon roof
153
Smart key system
123
3-3. Adjusting the seats
Front seats
131
Rear seats
133
Head restraints
136
3-4. Adjusting the steering
wheel and mirrors
Steering wheel
140
Inside rear view mirror
142
Outside rear view
mirrors
145
104
3-1. Key information
Keys
The keys
The following keys are provided with the vehicle.
Type A
1
Keys
2
Key number plate
Type B
1
Keys
2
Key number plate
Type C
1
Keys
Operating the wireless remote con-
trol function
2
Key number plate
3-1. Key information
105
Type D
1
Electronic keys
• Operating the smart key sys-
tem (P. 123)
• Operating
the
wireless
remote control function
2
Mechanical keys
3
Key
4
Key number plate
3
Wireless remote control (type C or type D)
Type C
1
Locks all the doors (P. 111)
2
Unlocks all the doors (P. 111)
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
3
Sounds the alarm (press and
hold) (P. 106)
Type D
1
Locks all the doors (P. 112)
2
Unlocks all the doors (P. 112)
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
3
Sounds the alarm (press and
hold) (P. 106)
106
3-1. Key information
Using the mechanical key (type D)
To take out the mechanical key,
push the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and reat-
tempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electronic key
battery is depleted or the entry function does not operate properly, you
will need the mechanical key. (P. 611)
■ Panic mode (type C or type D)
Type C
When
is pressed for longer than
about 1 second, an alarm will sound inter-
mittently and the vehicle lights will flash to
deter any person from trying to break into
or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.
Type D
When
is pressed for longer than
about 1 second, an alarm will sound inter-
mittently and the vehicle lights will flash to
deter any person from trying to break into
or damage your vehicle.
To stop the alarm, press any button on the
electronic key.
3-1. Key information
107
■ When required to leave the vehicle’s key with a parking attendant (type
D)
Lock the glove box as circumstances demand. (P. 445)
Remove the mechanical key for your own use and provide the attendant with
the electronic key only.
■ If you lose your keys
Type A, B and C
New genuine key can be made by your Toyota dealer using the other key and
the key number stamped on your key number plate.
Keep the plate in a safe place such as your wallet, not in the vehicle.
Type D
New genuine key can be made by your Toyota dealer.
The following are necessary when making new keys.
Mechanical key:
3
The key number for the mechanical key stamped on the number plate and the
other key.
Key:
The key number for key stamped on the key number plate.
Keep the plates in a safe place such as your wallet, not in the vehicle.
There are key number plates for the mechanical key and key respectively.
When storing them, keep them in a safe place in a manner to distinguish one
from the other (such as markings, etc.).
■ When riding in an aircraft (type C or type D)
When bringing an wireless remote control function onto an aircraft, make sure
you do not press any button on the key while inside the aircraft cabin. If you
are carrying the key in your bag, etc., ensure that the buttons are not likely to
be pressed accidentally. Pressing a button may cause the key to emit radio
waves that could interfere with the operation of the aircraft.
■ Conditions affecting operation (type C or type D)
Type C
The wireless remote control function may not operate normally in the follow-
ing situations:
● Near a TV tower, radio station, electric power plant, airport or other facility
that generates strong radio waves
● When carrying a portable radio, cellular phone or other wireless communi-
cation devices
● When multiple wireless keys are in the vicinity
● When the wireless key is in contact with, or is covered by a metallic object
● When a wireless key (that emits radio waves) is being used nearby
● When the wireless key has been left near an electrical appliance such as a
personal computer
Type D
P. 126
108
3-1. Key information
■ Key battery depletion (type C or type D)
Type C
If the wireless remote control function does not operate, the battery may be
depleted. Replace the battery when necessary. (P. 537)
Type D
● The standard battery life is 1 to 2 years.
● If the battery becomes low, an alarm will sound in the cabin when the engine
stops. (P. 591)
● As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. (P. 537)
• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
● To avoid serious deterioration, do not leave the electronic key within 1 m
(3 ft.) of the following electrical appliances that produce a magnetic field:
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers
■ Replacing the battery (type C or type D)
P. 537
■Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.
■ Customization (type C or type D)
Settings (e.g. wireless remote control system) can be changed.
(Customizable features: P. 649)
3-1. Key information
109
■ Certification for wireless remote control (type C)
For vehicles sold in U.S.A. and New Caledonia
FCC ID: HYQ23AAH
FCC ID: HYQ23AAN
FCC ID: HYQ12BEL
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
3
<For 12BEL>
The FCC ID/IC Certification number is affixed inside the equipment. You can
find the ID/number when replacing the battery.
For vehicles sold in Canada
NOTE:
This device complies with Industry Canada’s licence-exempt RSSs. Opera-
tion is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
<For 12BEL>
The FCC ID/IC Certification number is affixed inside the equipment. You can
find the ID/number when replacing the battery.
NOTE:
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
<Pour 12BEL>
L’identification FCC/Ie numéro d’accréditation IC est apposé(e) à l’intérieur
de l’appareil. Cette identification/ce numéro est visible au remplacement de la
pile.
■ Certification for wireless remote control (type D)
P. 129
110
3-1. Key information
NOTICE
■ To prevent key damage
● Do not drop the keys, subject them to strong shocks or bend them.
● Do not expose the keys to high temperatures for long periods of time.
● Do not get the keys wet or wash them in an ultrasonic washer, etc.
● Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
● Do not disassemble the keys.
● Do not attach a sticker or anything else to the surface of the electronic key.
● Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems and induction cookers, or medical electrical equip-
ment, such as low-frequency therapy equipment.
■ Carrying the electronic key on your person (type D)
Carry the electronic key 10 cm (3.9 in.) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 10 cm (3.9 in.) of the electronic key may interfere with the key, caus-
ing the key to not function properly.
■ In case of a smart entry & start system malfunction or other key-related
problems (type D)
Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.
■ When an electronic key is lost (type D)
If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit your Toyota dealer immediately with all remaining electronic
keys that was provided with your vehicle.
3-2. Opening, closing and locking the doors
111
Doors
Unlocking and locking the doors from the outside
◆ Key
Vehicles without a smart key system
1
Locks all the doors
2
Unlocks all the doors
Turning the key unlocks the
driver’s door. Turning the key
again unlocks
the other doors.
3
Vehicles with a smart key system
The doors can also be locked and unlocked with the mechanical
key. (P. 611)
◆ Wireless remote control (if equipped)
Vehicles without a smart key
Vehicles with a smart key sys-
system
tem
Locks all the doors
1
Check that the door is securely locked.
Unlocks all the doors
2
Pressing the button unlocks the driver’s door. Pressing the button again
within 3 seconds unlocks the other doors.
112
3-2. Opening, closing and locking the doors
◆ Smart key system (if equipped)
Carry the electronic key to enable this function.
Grip the driver’s door handle
1
to unlock the door.
Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.
Touch the lock sensor (the indentation on the upper part or lower
2
part of the driver’s door handle) to lock the doors.
Check that the door is securely locked.
■ Operation signals (vehicles with a wireless remote control or smart key
system)
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: once; Unlocked: twice)
■ Security feature (vehicles with a wireless remote control or smart key
system)
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
■ When the door cannot be locked by the lock sensor on the upper part of
the door handle (vehicles with a smart key system)
If the door will not lock even when the top-
side sensor area is touched, try touching
both the topside and underside sensor
areas at the same time.
■ Door lock buzzer (vehicles with a smart key system)
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously for 5 seconds. Fully close the door to stop the
buzzer, and lock the vehicle once more.
■Alarm (if equipped)
Locking the doors will set the alarm system. (P. 79)
3-2. Opening, closing and locking the doors
113
■ If the smart key system or the wireless remote control does not operate
properly (if equipped)
Use the mechanical key to lock and unlock the doors. (P. 611)
Replace the battery with a new one if it is depleted. (P. 537)
Unlocking and locking the doors from the inside
◆ Door lock switches
1
Locks all the doors
2
Unlocks all the doors
3
◆ Inside lock buttons
1
Locks the door
2
Unlocks the door
The front doors can be opened
by pulling the inside handle
even if the lock buttons are in
the lock position.
114
3-2. Opening, closing and locking the doors
Locking the front doors from the outside without a key
1
Move the inside lock button to the lock position.
2
Close the door.
Vehicles without a smart key system
The door cannot be locked if either of the front doors is open and the
key is in the engine switch.
Vehicles with a smart key system
The door cannot be locked if the engine switch is in ACCESSORY or
IGNITION ON mode, or the electronic key is left inside the vehicle.
The key may not be detected correctly and the door may be locked.
Access doors (Access Cab models only)
The access door (rear door) can be opened using the inside handle.
1
Open the front door widely
2
Pull
(from the outside) or
push
(from the inside) the
inside handle of the access
door.
Open the access door
3
You can open and close the
access door only when the front
door is widely opened.
3-2. Opening, closing and locking the doors
115
Rear door child-protector lock (Double Cab models only)
The door cannot be opened from
inside the vehicle when the lock is
set.
1
Unlock
2
Lock
These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.
3
Automatic door locking and unlocking systems (vehicles with an
automatic transmission)
The following functions can be set or canceled:
Function
Operation
Shift position linked door locking
Shifting the shift lever out of P locks
function
all the doors.
Shift position linked door unlocking
Shifting the shift lever to P unlocks
function
all the doors.
All the doors are locked when the
Speed linked door locking function
vehicle speed is approximately 12 mph
(20 km/h) or higher.
Vehicles without a smart key system
All the doors are unlocked when the
driver’s door is opened within 10 sec-
onds after turning the engine switch to
Driver’s door linked door unlocking
the “LOCK” position.
function
Vehicles with a smart key system
All the doors are unlocked when the
driver’s door is opened within
10 seconds after turning the engine
switch off.
116
3-2. Opening, closing and locking the doors
■ Setting and canceling the functions
The automatic door locking and unlocking functions can be set or
canceled on the Entune Audio system screen (P. 649) or by fol-
lowing the procedure below.
1
Vehicles without a smart key system: Close all the doors and turn
the engine switch to the “ON” position. (Perform step
2
within
10 seconds.)
Vehicles with a smart key system: Close all the doors and turn
the engine switch to IGNITION ON mode. (Perform step
2
within 10 seconds.)
Shift the shift lever to P or N,
2
and press and hold the
driver's door lock switch
(
or
)
for
approximately 5 seconds and
then release.
The shift lever and switch posi-
tions corresponding to the
desired function to be set are
shown as follows.
Use the same procedure to cancel the function.
Shift lever
Driver’s door lock
Function
position
switch position
Shift position linked door lock-
ing function
P
Shift position linked door
unlocking function
Speed linked door locking func-
tion
N
Driver’s door linked door
unlocking function
When the setting or canceling operation is complete, all doors are
locked and then unlocked.
3-2. Opening, closing and locking the doors
117
■ Customization that can be configured at Toyota dealer
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features: P. 649)
WARNING
■ To prevent an accident
Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant throwing out
of the vehicle, resulting in death or serious injury.
● Ensure that all doors are properly closed and locked.
● Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened even
if the inside lock buttons are in locked position.
3
● Double Cab models only: Set the rear door child-protector locks when chil-
dren are seated in the rear seats.
NOTICE
■ When opening or closing the front door and access door (Access Cab
models only)
The front door and access door could be damaged if they hit each other
when being opened or closed.
118
3-2. Opening, closing and locking the doors
Tailgate
The tailgate can be opened using the tailgate handle. The tail-
gate can be locked/unlocked using a key.
Locking/unlocking the tailgate
1
Unlock the tailgate
2
Lock the tailgate
Opening/closing the tailgate
1
Pull the handle
2
Open the tailgate slowly
Tailgate will open slowly due to
damper.
The support cables will hold the
tailgate horizontal.
Lift and closing the tailgate
3
After closing the tailgate, try pulling
it toward you to make sure it is
securely locked.
