Toyota Sequoia (2018 year). Instruction - part 5

Fo
r

SEQUOIA_OM_USA_OM0C011U

Fully extend the shoulder belt
and then allow it to retract
slightly in order to activate
the ALR lock mode.

Lock mode allows the seat belt
to retract only.

While pushing the child
restraint system down into
the rear seat, allow the
shoulder belt to retract until
the child restraint system is
securely in place.

After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.

1-1. For safe use

SEQUOIA_OM_USA_OM0C011U

■

Forward-facing

⎯ Convertible seat

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt
and then allow it to retract
slightly in order to activate
the ALR lock mode.

Lock mode allows the seat belt
to retract only.

While pushing the child
restraint system into the rear
seat, allow the shoulder belt
to retract until the child
restraint system is securely
in place.

After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.

1-1. For safe use

Fo
r

safety and securi

SEQUOIA_OM_USA_OM0C011U

If the child restraint has a top tether strap, the top tether strap
should be latched onto the top tether strap anchor. (

→P. 68)

■

Booster seat

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

Sit the child in the child
restraint system. Fit the seat
belt to the child restraint sys-
tem according to the manu-
facturer’s instructions and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Check that the shoulder belt is correctly positioned over the child’s
shoulder and that the lap belt is as low as possible. (

→P. 28)

1-1. For safe use

SEQUOIA_OM_USA_OM0C011U

Push the buckle release button
and fully retract the seat belt.



Second seat

Secure the child restraint sys-
tem using the seat belt or
LATCH anchors, and adjust the
head restraint to the upmost
position.

Latch the hook onto the anchor
bracket and tighten the top
tether strap

Make sure the top strap is securely
latched.

Hook

Top tether strap

Anchor bracket

Adjust the head restraint to the
downmost position.

Removing a child restraint installed with a seat belt

Child restraint systems with a top tether strap

1-1. For safe use

Fo
r

safety and securi

SEQUOIA_OM_USA_OM0C011U



Third center seat

Secure the child restraint sys-
tem using the seat belt, and
adjust the head restraint to the
upmost position.

Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top
tether strap.

Make sure the top tether strap is
securely latched.

Hook

Top tether strap

Anchor bracket

Adjust the head restraint to the
downmost position.

■

Laws and regulations pertaining to anchorages
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifica-
tions can be used.
This vehicle is designed to conform to the SAE J1819.

1-1. For safe use

SEQUOIA_OM_USA_OM0C011U

WARNING

■

When installing a booster seat
To prevent the belt from going into ALR lock mode, do not fully extend the
shoulder belt. ALR mode causes the belt to tighten only. This could cause
injury or discomfort to the child. (

→P. 32)

■

When installing a child restraint system
Follow the directions given in the child restraint system installation manual
and fix the child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other
passengers may be seriously injured or even killed in the event of a sudden
braking or an accident.

●

Vehicles with bench type second seats: When installing a child restraint
system on the second seat, adjust both seat cushions to the same position
and align both seatbacks at the same angle. The seatbacks must be
adjusted to the same angle. Otherwise, the child restraint system cannot
be securely restrained and this may cause death or serious injuries in the
event of sudden braking, sudden swerving or an accident.

●

If the driver’s seat interferes with the
child restraint system and prevents it
from being attached correctly, attach the
child restraint system to the right-hand
rear seat.

●

Adjust the front passenger seat so that
it does not interfere with the child
restraint system.

●

Only put a forward-facing child restraint
system on the front seat when unavoid-
able. When installing a forward-facing
child restraint system on the front pas-
senger seat, move the seat as far back
as possible even if the “AIR BAG OFF”
indicator light is illuminated. Failure to
do so may result in death or serious
injury if the airbags deploy (inflate).

1-1. For safe use

Fo
r

safety and securi

SEQUOIA_OM_USA_OM0C011U

WARNING

●

When installing a child restraint system on the third center seat, adjust
both seatbacks at the same angle. The seatbacks must be adjusted to the
same angle. Otherwise, the child restraint system cannot be securely
restrained and this may cause death or serious injuries in the event of sud-
den braking, sudden swerving or an accident.

■

When installing a child restraint system

●

When a booster seat is installed, always ensure that the shoulder belt is
positioned across the center of the child’s shoulder. The belt should be
kept away from the child’s neck, but not so that it could fall off the child’s
shoulder. Failing to do so may result in death or serious injury in the event
of an accident or a sudden braking.

●

Ensure that the belt and plate are securely locked and the seat belt is not
twisted.

●

Shake the child restraint system left and right, and forward and backward
to ensure that it has been securely installed.

●

After securing a child restraint system, never adjust the seat.

●

Follow all installation instructions provided by the child restraint system
manufacturer.

●

When securing some types of child restraint systems in second or third
seats, it may not be possible to properly use the seat belts in positions
next to the child restraint without interfering with it or affecting seat belt
effectiveness. Be sure your seat belt fits snugly across your shoulder and
low on your hips. If it does not, or if it interferes with the child restraint,
move to a different position.

■

When installing a child restraint system (vehicles with bench type sec-
ond seat)
Observe the following precautions.
Failure to do so may cause death or serious injury to the child or other pas-
sengers in the event of a sudden stop or accident.

●

When installing the child restraint system onto the second center seat,
secure it so as not interfere with the front console box.

●

Do not change the posture and position of the outside second seat once
the child restraint system has been secured to the second center seat.

1-1. For safe use

SEQUOIA_OM_USA_OM0C011U

WARNING

■

Do not use a seat belt extender
If a seat belt extender is used when installing a child restraint system, the
seat belt will not securely hold the child restraint system, which could cause
death or serious injury to the child or other passengers in the event of a sud-
den braking, sudden swerving or an accident.

■

To correctly attach a child restraint system to the anchors
When using the LATCH anchors, be sure that there are no foreign objects
around the anchors and that the seat belt is not caught behind the child
restraint system. Make sure the child restraint system is securely attached,
or it may cause death or serious injury to the child or other passengers in
the event of a sudden braking or an accident.

1-1. For safe use

Fo
r

safety and securi

SEQUOIA_OM_USA_OM0C011U

Exhaust gas precautions

Harmful substance to the human body is included in exhaust
gases if inhaled.

WARNING

Exhaust gases contain harmful carbon monoxide (CO), which is colorless and
odorless. Observe the following precautions.
Failure to do so may cause exhaust gases to enter the vehicle and may lead
to an accident caused by light-headedness, or may lead to death or a serious
health hazard.

■

Important points while driving

●

Keep the back door closed.

●

If you smell exhaust gases in the vehicle even when the back door is
closed, open the windows and have the vehicle inspected at your Toyota
dealer as soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated area or a closed area, such as a
garage, stop the engine.

●

Do not leave the vehicle with the engine on for a long time.
If such a situation cannot be avoided, park the vehicle in an open space
and ensure that exhaust fumes do not enter the vehicle interior.

●

Do not leave the engine running in an area with snow build-up, or where it
is snowing. If snowbanks build up around the vehicle while the engine is
running, exhaust gases may collect and enter the vehicle.

■

Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or
crack caused by corrosion, damage to a joint or abnormal exhaust noise, be
sure to have the vehicle inspected and repaired by your Toyota dealer.

1-2. Theft deterrent system

SEQUOIA_OM_USA_OM0C011U

Engine immobilizer system

The indicator light flashes after
the key has been removed from
the engine switch to indicate that
the system is operating.

The indicator light stops flashing
after the registered key has been
inserted into the engine switch to
indicate that the system has been
canceled.

■

System maintenance
The vehicle has a maintenance-free type engine immobilizer system.

■

Conditions that may cause the system to malfunction

●

If the grip portion of the key is in contact with a metallic object

●

If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle

The vehicle’s keys have built-in transponder chips that prevent
the engine from starting if a key has not been previously regis-
tered in the vehicle’s on-board computer.

Never leave the keys inside the vehicle when you leave the vehi-
cle.

This system is designed to help prevent vehicle theft but does
not guarantee absolute security against all vehicle thefts.

1-2. Theft deterrent system

Fo
r

safety and securi

SEQUOIA_OM_USA_OM0C011U

■

Certifications for the engine immobilizer system



For vehicles sold in the U.S.A.

FCC ID: MOZRI-42BTY

This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

FCC WARNING:

Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.

WARNING

■

Certifications for the engine immobilizer system
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

NOTICE

■

To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

1-2. Theft deterrent system

SEQUOIA_OM_USA_OM0C011U

Alarm

The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the alarm is
set:
● A locked door is unlocked or opened in any way other than using

the key or, wireless remote control. (The doors will lock again auto-
matically.)

● The hood is opened.
● Vehicles with the glass breakage sensor: The side windows are

tapped or broken.

● The battery is reconnected.

Close the doors and hood, and
lock all the doors. The system will
be set automatically after 30 sec-
onds.

The indicator light changes from
being on to flashing when the sys-
tem is set.

Do one of the following to deactivate or stop the alarms:
● Unlock the doors.
● Start the engine. (The alarm will be deactivated or stopped after a

few seconds.)

The alarm

Setting the alarm system

Deactivating or stopping the alarm

1-2. Theft deterrent system

Fo
r

safety and securi

SEQUOIA_OM_USA_OM0C011U

■

System maintenance
The vehicle has a maintenance-free type alarm system.

■

Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of
the following:

●

Nobody is in the vehicle.

●

The windows and moon roof are closed before the alarm is set.

●

No valuables or other personal items are left in the vehicle.

■

Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)

●

A person inside the vehicle opens a door
or the hood.

●

The battery is recharged or replaced
when the vehicle is locked.

1-2. Theft deterrent system

SEQUOIA_OM_USA_OM0C011U

■

Alarm-operated door lock
In the following cases, depending on the situation, the door may automatically
lock to prevent improper entry into the vehicle:

●

When a person remaining in the vehicle locks the door and the alarm is acti-
vated.

●

When the alarm is activated and a person remaining in the vehicle unlocks
the door.

●

When recharging or replacing the battery.

NOTICE

■

To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

Instrument cluster

SEQUOIA_OM_USA_OM0C011U

2. Instrument

cluster

Warning lights and

indicators .......................... 80

Gauges and meters ............ 86

Multi-information display ..... 90

Fuel consumption

information ........................ 96

2. Instrument cluster

SEQUOIA_OM_USA_OM0C011U

Warning lights and indicators

The units used on the speedometer and some indicators may differ
depending on where the vehicle is sold.

The warning lights and indicators on the instrument cluster and
center panel inform the driver of the status of the vehicle’s vari-
ous systems.
For the purpose of explanation, the following illustration dis-
plays all warning lights and indicators illuminated.

Content .. 3 4 5 6 ..
