Toyota RAV4 (2018 year). Instruction - part 22

5-5. Using an external device

357

Using a USB memory

■ Selecting folders one at a time

Press

(<FOLDER) or

(FOLDER>) to select the desired

folder.

Press

(MORE>) to display the commands.

■ Selecting a folder and file from folder list

1

Press the “TUNE•SCROLL” knob.

The folder list will be displayed.

2

Turn and press the knob to select a folder and file.

To return to the previous display, press

(BACK).

■ Returning to the first folder

Press and hold

(<FOLDER) until you hear a beep.

■ Scanning a folder

1

Press and hold the “SCAN” button until you hear a beep.

The first 10 seconds of the first file in each folder will be played.

To cancel, press the button again.

5

2

When the desired folder is reached, press the button again.

■ Selecting a file

Turn the “TUNE•SCROLL” knob or press “∧” or “∨” on the “SEEK/

TRACK” button to select the desired file.

■ Scanning the files in a folder

Press the “SCAN” button.

1

The first 10 seconds of each file will be played.

To cancel, press the button again.

2

When the desired file is reached, press the button again.

■ Fast-forwarding and rewinding files

Press

(

) or

(

).

Press

(<BACK) to display the commands.

RAV4_OM_OM0R012U_(U)

358

5-5. Using an external device

■ Random play

Pressing

(RDM) changes modes in the following order:

Folder random→All folder random→Off

Press

(MORE>) to display the command.

■ Repeat play

Pressing

(RPT) changes modes in the following order:

File repeat→Folder repeat*→Off

*: Available except when RDM (random play) is selected

Press

(MORE>) to display the command.

■ Playing and pausing tracks

Press

(

).

Press

(<BACK) to display the command.

■ Switching the display

Press the “TEXT” button to display or hide the album title.

If there are continuing texts,

is displayed.

Press and hold the button to display the remaining texts.

■ USB memory functions

● Depending on the USB memory that is connected to the system, the device

itself may not be operable and certain functions may not be available. If the

device is inoperable or a function is unavailable due to a malfunction (as

opposed to a system specification), disconnecting the device and recon-

necting it once again may resolve the problem.

● If the USB memory still does not begin operation after being disconnected

and reconnected, format the memory.

■ Display

→P. 344

■Error messages

If an error message is displayed, refer to the following table and take the

appropriate measures. If the problem is not rectified, take the vehicle to your

Toyota dealer.

Message

Cause/Correction procedures

This indicates a problem in the USB memory

“ERROR”

or its connection.

This indicates that no MP3/WMA files are

“NO MUSIC”

included in the USB memory.

RAV4_OM_OM0R012U_(U)

5-5. Using an external device

361

WARNING

■While driving

Do not connect USB memory or operate the controls. Doing so may cause

an accident, resulting in death or serious injury.

NOTICE

■ To prevent damage to USB memory

● Do not leave USB memory in the vehicle. The temperature inside the vehi-

cle may become high, resulting in damage to the USB memory.

● Do not push down on or apply unnecessary pressure to the USB memory

while it is connected as this may damage the USB memory or its terminal.

● Do not insert foreign objects into the port as this may damage the USB

memory or its terminal.

5

RAV4_OM_OM0R012U_(U)

362

5-5. Using an external device

Using the AUX port

This port can be used to connect a portable audio device and lis-

ten to it using the vehicle’s speakers.

Connecting a portable player

→P. 334

■ Operating portable audio devices connected to the audio system

The volume can be adjusted using the vehicle’ audio controls. All other

adjustments must be made on the portable audio device itself.

■ When using a portable audio device connected to the power outlet

Noise may occur during playback. Use the power source of the portable

audio device.

RAV4_OM_OM0R012U_(U)

5-6. Using Bluetooth® devices

363

Bluetooth® audio/phone∗

The following can be performed using Bluetooth® wireless com-

munication:

■ Bluetooth® audio

The Bluetooth® audio system enables you to enjoy music played on

a portable digital audio player (portable player) from the vehicle

speakers via wireless communication.

This audio system supports Bluetooth®, a wireless data system

capable of playing portable audio music without cables. If your por-

table player does not support Bluetooth®, the Bluetooth® audio sys-

tem will not function.

■ Bluetooth® phone (hands-free phone system)

This system supports Bluetooth®, which allows you to make or

receive calls without using cables to connect a cellular phone and

5

the system, and without operating the cellular phone.

∗: If equipped

RAV4_OM_OM0R012U_(U)

364

5-6. Using Bluetooth® devices

Device registration/connection flow

1. Register the Bluetooth® device to be used with audio

system (→P. 369)

2. Connect the registered Bluetooth® device to be used

(→P. 370)

3. Set automatic connection of the device

(→P. 373)

4. Check Bluetooth® connection condition

(→P. 365)

To be used for audio

To be used for hands-free phone

5. Use Bluetooth® audio

5. Use Bluetooth® phone

(→P. 380)

(→P. 383)

RAV4_OM_OM0R012U_(U)

5-6. Using Bluetooth® devices

365

Audio unit

1

Bluetooth® connection condi-

tion

If

“BT” is not displayed, the

Bluetooth® audio/phone cannot be

used.

2

Displays set up menu

3

Selects items such as menu

and number

Turn: Selects an item

Press: Inputs the selected item

4

Off-hook switch

Turns the hands-free system on/starts a call

5

On-hook switch

Turns the hands-free system off/ends a call/refuses a call

6

Selects speed dials

7

Displays information that is too long to be displayed at one time on

5

the display (press and hold)

8

Display

A message, name, number, etc. is displayed.

Lower-case characters and special characters cannot be displayed.

■ Microphone

You can use the microphone

when talking on the phone.

The person you are speaking to

can be heard from the speak-

ers.

To use the hands-free system,

you must register your Blue-

tooth® phone in the system.

(→P. 369)

RAV4_OM_OM0R012U_(U)

366

5-6. Using Bluetooth® devices

Menu list of the Bluetooth® audio/phone

First menu

Second menu

Third menu

Operation details

Registering

a

“BT pairing”

-

Bluetooth® device

Listing the registered

“List phone”

-

cellular phones

Listing the registered

“List audio”

-

portable players

Changing the pass-

“Passkey”

-

key

Setting

automatic

“Bluetooth*”

“BT power”

-

connection of the

device on or off

“Device name”

Displaying the device

“Bluetooth* info”

“Device address”

status

Setting the auto-

matic

connection

“Display setting”

-

confirmation display

to on or off

Initializing the set-

“Initialize”

-

tings

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

RAV4_OM_OM0R012U_(U)

5-6. Using Bluetooth® devices

367

First menu

Second menu

Third menu

Operation details

Adding a new num-

“Add contacts”

ber

Registering a speed

“Add SD”

dial

Deleting a number

“Delete call

stored in the call his-

“Phonebook”

history”

tory

Deleting a number

“Delete contacts”

stored in the phone-

book

Deleting a phone-

“PHONE”

“Delete other PB”

book’s data

Setting

automatic

“Auto transfer”

-

transferring of the

phonebook on or off

“Call volume”

Setting call volume

5

“HF sound

“Ringtone

Setting ring tone vol-

setting”

volume”

ume

“Ringtone”

Setting the ring tone

“Transfer

Transferring the call

-

histories”

histories

■Bluetooth® audio/phone system functions

Depending on the Bluetooth® device, certain functions may not be available.

RAV4_OM_OM0R012U_(U)

368

5-6. Using Bluetooth® devices

Using the steering wheel switches

The steering wheel switches can be used to operate a connected

cellular phone, or portable digital audio player (portable player).

Operating Bluetooth® phone using the steering wheel switches

1

Volume

The voice guidance volume

cannot be adjusted using this

button.

2

Off-hook switch

Turns the hands-free system

on/start a call

3

On-hook switch

Turns the hands-free system

off/ends a call/refuse a call

RAV4_OM_OM0R012U_(U)

5-6. Using Bluetooth® devices

369

Register a Bluetooth® device

Before using the Bluetooth® audio/phone, it is necessary to reg-

ister a Bluetooth® device in the system. Follow the procedure

below to register (pair) a device:

How to register a Bluetooth® device

1

Press the

“SETUP” button and select

“Bluetooth*” using the

“TUNE•SCROLL” knob.

2

Press the knob and select “BT pairing” using the knob.

A passkey will be displayed.

3

SSP (Secure Simple Pairing) incompatible Bluetooth® devices:

Input the passkey into the device.

SSP (Secure Simple Pairing) compatible Bluetooth® devices:

Select

“Yes” to register the device. Depending on the type of

device, it may register automatically.

5

If a Bluetooth® device has both music player and cellular phone func-

tions, both functions will be registered at the same time. When delet-

ing the device, both functions will be deleted at the same time.

If the off-hook switch is pressed and the “PHONE” mode is entered

when no phones have been registered, the registration screen will be

automatically displayed.

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

RAV4_OM_OM0R012U_(U)

370

5-7. “SETUP” menu

Using the “SETUP” menu (“Bluetooth*”

menu)∗

Registering a Bluetooth® device in the system allows the system

to function. The following functions can be used for registered

devices:

■ Functions and operation procedures

1

Press the “SETUP” button and select “Bluetooth*” using the

“TUNE•SCROLL” knob.

2

Press the knob and select one of the following functions using

the knob.

● Registering a Bluetooth® device

“BT pairing”

● Listing the registered cellular phones

“List phone”

● Listing the registered portable players

“List audio”

● Changing the passkey

“Passkey”

● Setting automatic connection of the device on or off

“BT power”

● Displaying the device status

“Bluetooth* info”

● Setting the automatic connection confirmation display to on or off

“Display setting”

● Initialization

“Initialize”

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

∗: If equipped

RAV4_OM_OM0R012U_(U)

5-7. “SETUP” menu

371

Registering a Bluetooth® device

Select “BT pairing” using the “TUNE•SCROLL” knob.

● If a Bluetooth® device is not connected currently

Perform the procedure for registering a Bluetooth® device from step

. (→P. 369)

3

● If other Bluetooth® device is connected currently

The Bluetooth® device needs to be disconnected.

After disconnecting, perform the procedure for registering a

Bluetooth® device from step

. (→P. 369)

2

● If device list is full

Select the Bluetooth® device to be deleted using the

“TUNE•SCROLL” knob and press

(YES).

Listing the registered cellular phones

Select “List phone” using the “TUNE•SCROLL” knob. The list of regis-

tered cellular phones will be displayed.

● Connecting the registered cellular phone to the audio system

5

1

Select the name of the cellular phone to be connected using the

“TUNE•SCROLL” knob.

2

Select “Select” using the knob.

● Deleting a registered cellular phone

1

Select the name of the cellular phone to be deleted using the

“TUNE•SCROLL” knob.

2

Select “Delete” using the knob.

3

Press

(YES).

● Disconnecting the registered cellular phone from the audio system

1

Select the name of the cellular phone to be disconnected using

the “TUNE•SCROLL” knob.

2

Select “Disconnect” using the knob.

3

Press

(YES).

RAV4_OM_OM0R012U_(U)

372

5-7. “SETUP” menu

Listing the registered portable players

Select “List audio” using the “TUNE•SCROLL” knob. The list of regis-

tered portable players will be displayed.

● Connecting the registered portable player to the audio system

1

Select the name of the portable player to be connected using the

“TUNE•SCROLL” knob.

2

Select “Select” using the knob.

● Deleting the registered portable player

1

Select the name of the portable player to be deleted using the

“TUNE•SCROLL” knob.

2

Select “Delete” using the knob.

3

Press

(YES).

● Disconnecting the registered portable player from the audio system

1

Select the name of the portable player to be disconnected using

the “TUNE•SCROLL” knob.

2

Select “Disconnect” using the knob.

3

Press

(YES).

● Selecting the connection method

1

Select the name of the desired portable player using the

“TUNE•SCROLL” knob.

2

Select “Connection Method” using the knob.

3

Select “From vehicle” or “From audio” using the knob.

RAV4_OM_OM0R012U_(U)

5-7. “SETUP” menu

373

Changing the passkey

1

Select “Passkey” using the “TUNE•SCROLL” knob.

2

Select a 4 to 8-digit passkey using the knob.

Input the number 1 digit at a time.

3

When the entire number to be registered as a passkey has been

input, press

(ENTER).

If the passkey to be registered has 8 digits, pressing

(ENTER) is not

necessary.

Setting automatic connection of the device on or off

If

“BT power” is set to on, the registered device will be connected

automatically when the engine switch is turned to the “ACC” position

(vehicles without smart key system) or ACCESSORY mode (vehicles

with smart key system).

1

Select “BT Power” using the “TUNE•SCROLL” knob.

2

Select “ON” or “OFF” using the knob.

5

Displaying the device status

Select “Bluetooth* info” using the “TUNE•SCROLL” knob.

● Displaying the device name

Select “Device name” using the “TUNE•SCROLL” knob.

● Displaying the device address

Select “Device address” using the “TUNE•SCROLL” knob.

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

RAV4_OM_OM0R012U_(U)

Content   ..  20  21  22  23   ..
