Toyota Matrix (2014 year). Instruction - part 16

246

3-2. Using the audio system

MATRIX_U

Using the AUX port

This port can be used to connect a portable audio device and listen
to it through the vehicle’s speakers.

Type A

Open the cover and connect
the portable audio device.

Press .

Type B

Open the cover and connect
the portable audio device.

STEP

247

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

■

Operating portable audio devices connected to the audio system

The volume can be adjusted using the vehicle's audio controls. All other
adjustments must be made on the portable audio device itself.

■

When using a portable audio device connected to the power outlet

Noise may occur during playback. Use the power source of the portable
audio device.

Press .

STEP

248

3-2. Using the audio system

MATRIX_U

Using the steering wheel audio switches

Turning on the power

Press

when the audio system is turned off.

The audio system can be turned off by holding

down until you hear a

beep.

Some audio features can be controlled using the switches on the
steering wheel.

Operation may differ and usage may not be possible with audio/nav-
igation systems that are not compatible with the steering switches in
this vehicle.

Volume
Radio mode: Selects radio
stations
CD mode: Selects tracks,
files (MP3 and WMA) and
discs
iPod mode: Selects songs

USB memory mode:

Selects files and fold-
ers

Bluetooth

audio mode:

Selects tracks and
albums

Turns the power on, selects
audio source

249

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Changing the audio source

Press

when the audio system is turned on. The audio source

changes each time

is pressed. If a mode cannot be used, it will

be skipped.

Adjusting the volume

Press “+” on

to increase the volume and “-” to decrease the vol-

ume.

Press and hold

to continue increasing or decreasing the volume.

Selecting a radio station

Press

to select the radio mode.

Press

to select a preset station.

To scan for receivable stations, press and hold

until you hear a

beep.

STEP

250

3-2. Using the audio system

MATRIX_U

Selecting a track/file or song

Press

to select CD, iPod, USB memory or Bluetooth

audio mode.

Press “

∧” or “∨” on

to select the desired track/file or song.

Selecting a folder or album

Press

to select CD, USB memory or Bluetooth

audio

mode.

Press and hold “

∧” or “∨” on

until you hear a beep.

Selecting a disc in the CD player (CD player with changer only)

Press

to select CD mode.

Press and hold “

∧” or “∨” on

until you hear a beep.

CAUTION

■

To reduce the risk of an accident

Exercise care when operating the audio switches on the steering wheel.

STEP

251

Inte
rior fea

tures

MATRIX_U

3-3. Using the Bluetooth

audio system

Bluetooth

audio/phone

∗

■

Conditions affecting operation

The Bluetooth

audio/phone may not operate normally in the following situa-

tions:

●

The portable player does not support Bluetooth

●

The cellular phone is located outside the service area

●

The Bluetooth

device is switched off

●

The Bluetooth

device has a low battery

●

The Bluetooth

device is not connected to the system

●

The Bluetooth

device is behind the seat or in the glove box or console

box, or metal material covers or touches the device

■

Bluetooth

audio

The Bluetooth

audio system enables you to enjoy music played

on a portable digital audio player (portable player) from the vehi-
cle speakers via wireless communication.

This audio system supports Bluetooth

, a wireless data system

capable of playing portable audio music without cables. If your
portable player does not support Bluetooth

, the Bluetooth

audio system will not function.

■

Bluetooth

phone (hands-free phone system)

This system supports Bluetooth

, which allows you to make or

receive calls without using cables to connect a cellular phone
and the system, and without operating the cellular phone.

∗

: If equipped

252

3-3. Using the Bluetooth

audio system

MATRIX_U

■

When transferring ownership of the vehicle

Be sure to initialize the system to prevent personal data from being improp-
erly accessed. (

→P. 272)

■

About Bluetooth

■

Compatible models

●

Bluetooth

specifications:

Ver. 1.1, or higher (recommended: Ver. 2.1 + EDR or higher)

●

Following Profiles:

• A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (recom-

mended: Ver. 1.2 or higher)

• AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher (rec-

ommended: Ver. 1.3 or higher)

Portable players must correspond to the above specifications in order to be
connected to the Bluetooth

audio system. However, please note that some

functions may be limited depending on the type of portable player.

●

Cellular phone

• HFP (Hands Free Profile) Ver. 1.0 or higher (recommended: Ver. 1.5)
• OPP (Object Push Profile) Ver. 1.1
• PBAP (Phone Book Access Profile) Ver. 1.0

Bluetooth is a registered trademark of
Bluetooth SIG. Inc.

253

3-3. Using the Bluetooth

audio system

Inte
rior fea

tures

MATRIX_U

CAUTION

■

Caution while driving

●

Do not use a cellular phone.

●

Do not connect Bluetooth

device or operate the controls.

■

Caution regarding interference with electronic devices

●

Your audio unit is fitted with Bluetooth

antennas. People with implanted

pacemakers or cardiac defibrillators should maintain a reasonable dis-
tance between themselves and the Bluetooth

antennas. The radio waves

may affect the operation of such devices.

●

Before using Bluetooth

devices, users of any electrical medical device

other than implanted pacemakers and implanted cardiac defibrillators
should consult the manufacturer of the device for information about its
operation under the influence of radio waves. Radio waves could have
unexpected effects on the operation of such medical devices.

NOTICE

■

To prevent damage to Bluetooth

device

Do not leave Bluetooth

device in the vehicle. The temperature inside the

vehicle may become high, resulting in damage to the device.

254

3-3. Using the Bluetooth

audio system

MATRIX_U

Using the Bluetooth

audio/phone

■

Audio unit

Bluetooth

connection con-

dition

If “BT” is not displayed, the
Bluetooth

audio/phone

cannot be used.

Display
A message, name, number,
etc. is displayed.

Lower-case characters and
special characters cannot
be displayed.

Displays the set up menu
Selects items such as menu
and number
Turn: Selects an item
Press: Inputs the selected
item
Displays information that is
too long to be displayed at
one time on the display
(press and hold)
Selects speed dials
On-hook switch
Turns the hands-free sys-
tem off/ends a call/refuses a
call
Off-hook switch
Turns the hands-free sys-
tem on/starts a call

255

3-3. Using the Bluetooth

audio system

Inte
rior fea

tures

MATRIX_U

■

Steering wheel switches
→P. 248

■

Microphone
Vehicles with moon roof

Vehicles without moon roof

256

3-3. Using the Bluetooth

audio system

MATRIX_U

Using the Bluetooth

audio/phone for the first time

Before using the Bluetooth

audio/phone, it is necessary to register a

Bluetooth

device in the system. Follow the procedure below to reg-

ister (pair) a device:

Press

and select “Bluetooth” using

Press

and select “Pairing” using

A passkey will be displayed.

SSP (Secure Simple Pairing) incompatible Bluetooth

devices: Input the passkey into the device.
SSP (Secure Simple Pairing) compatible Bluetooth

devices:

Select “Yes” to register the device. Depending on the type of
device, it may register automatically.

If a Bluetooth

device has both music player and cellular phone func-

tions, both functions will be registered at the same time. When delet-
ing the device, both functions will be deleted at the same time.

If the off-hook switch is pressed and the “PHONE” mode is entered
when no phones have been registered, the registration screen will be
automatically displayed.

STEP

257

3-3. Using the Bluetooth

audio system

Inte
rior fea

tures

MATRIX_U

Menu list of the Bluetooth

audio/phone

First menu

Second menu

Third menu

Operation details

“Bluetooth”

“BT Pairing”

Registering a
Bluetooth

device

“List Phone”

Listing the registered
cellular phones

“List Audio”

Listing the registered
portable players

“Passkey”

Changing the passkey

“BT Power”

Setting automatic
connection of the device
on or off

“Bluetooth info”

“Device Name”
“Device
Address”

Displaying the device
status

“Display
Setting”

Setting the automatic
connection confirmation
display to on or off

“Initialize”

Initializing the settings

258

3-3. Using the Bluetooth

audio system

MATRIX_U

“Phone”

“Phonebook”

“Add contacts”

Adding a new number

“Add SD”

Registering a speed
dial

“Delete Call
History”

Deleting a number
stored in the call history

“Delete
contacts”

Deleting a number
stored in the
phonebook

“Delete other
PB”

Deleting a phonebook’s
data

“HF Sound
Setting”

“Call volume”

Setting call volume

“Ringtone
volume”

Setting ringtone volume

“Ringtone”

Setting the ringtone

“Transfer
Histories”

Transferring the call
histories

■

Bluetooth

audio/phone system functions

Depending on the Bluetooth

device, certain functions may not be available.

First menu

Second menu

Third menu

Operation details

259

3-3. Using the Bluetooth

audio system

Inte
rior fea

tures

MATRIX_U

Operating a Bluetooth

enabled portable player

Selecting an album

Press

(

) or

(

) to select the desired album.

Scanning an album

Press and hold

until you hear a beep.

The first 10 seconds of the first track in the each album will be
played.

When the desired album is reached, press

again.

Selecting tracks

Press “

∧” or “∨” on

to select the desired track.

Random playback

Repeat play

Playback

Playback/Pause

Displays text message

Volume

Power

Selecting items

Selecting an album, fast-forwarding and rewinding

Search playback

Selecting a
track

STEP

260

3-3. Using the Bluetooth

audio system

MATRIX_U

Scanning tracks

Press .

The first 10 seconds of all tracks in the album will be played.

When the desired track is reached, press

again.

Playing and pausing tracks

Press

(

) to play or pause a track.

Fast-forwarding and reversing tracks

→P. 229

Random playback

Pressing

(RDM) changes modes in the following order:

Album random

→ All track random → Off

Repeat play

Pressing

(RPT) changes modes in the following order:

Track repeat

→ Album repeat* → Off

*: Available except when RDM (random playback) is selected

Switching the display

Press .

Track title and Artist name are displayed on the display.

To return to the previous display, press

(BACK).

STEP

261

3-3. Using the Bluetooth

audio system

Inte
rior fea

tures

MATRIX_U

■

Bluetooth

audio system functions

Depending on the portable player that is connected to the system, certain
functions may not be available.

Content .. 14 15 16 17 ..
