Toyota Matrix (2014 year). Instruction

1-3. Adjustable components (seats, mirrors, steering wheel)

MATRIX_U

Steering wheel

CAUTION

■

Caution while driving

Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident and resulting in death or serious injury.

The steering wheel can be adjusted to a comfortable position.

Hold the steering wheel and
press the lever down.

Adjust to the ideal position by
moving the steering wheel
horizontally and vertically.

After adjustment, pull the lever
up to secure the steering
wheel.

STEP

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

MATRIX_U

Anti-glare inside rear view mirror

Glare from the headlights of vehicles behind can be reduced by
using the following functions.

Manual anti-glare inside rear view mirror

Normal position
Anti-glare position

Auto anti-glare inside rear view mirror
In automatic mode, sensors are used to detect the headlights of
vehicles behind and the reflected light is automatically reduced.

Turns automatic mode on/off

The indicator comes on when
automatic mode is turned on.

The mirror will revert to the
automatic mode each time the
engine switch is turned to the
“ON” position.

1-3. Adjustable components (seats, mirrors, steering wheel)

MATRIX_U

Adjusting the height of the rear view mirror

Adjust the height of the rear view
mirror by moving it up and down.

■

To prevent sensor error

CAUTION

■

Caution while driving

Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and an accident, resulting in
death or serious injury.

To ensure that the sensors operate prop-
erly, do not touch or cover them.

1-3. Adjustable components (seats, mirrors, steering wheel)

Be
fo

riv

MATRIX_U

Outside rear view mirrors

Folding back the mirrors

Push backward to fold the mir-
rors.

Mirror angle can be adjusted using the switch.

Select a mirror to adjust.

Left
Right

Adjust the mirror.

Up
Right
Down
Left

STEP

1-3. Adjustable components (seats, mirrors, steering wheel)

MATRIX_U

■

Mirror angle can be adjusted when

The engine switch is in the “ACC” or “ON” position.

■

When the mirrors are fogged up (vehicles with outside rear view mirror
defoggers)

Turn on the mirror defoggers to defog the mirrors. (

→P. 193)

CAUTION

■

When driving the vehicle

Observe the following precautions while driving.
Failing to do so may result in loss of control of the vehicle and cause an acci-
dent, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded back.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When the mirror defoggers are operating (vehicles with outside rear
view mirror defoggers)

Do not touch the rear view mirror surfaces, as they can become very hot and
burn you.

Be
fo

riv

MATRIX_U

1-4. Opening and closing the windows and moon roof

Power windows

∗

Lock switch

Press the switch down to lock
the passenger window switches.

Use this switch to prevent chil-
dren from accidentally opening or
closing a passenger window.

The power windows can be opened and closed using the following
switches.

Closing
Opening
One-touch opening (driver’s
window only)

: To stop the window partway,

operate the switch in the oppo-
site direction.

■

The power windows can be operated when

The engine switch is in the “ON” position.

■

Operating the power windows after turning the engine OFF

The power windows can be operated for approximately 45 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. They cannot, how-
ever, be operated once either front door is opened.

∗

: If equipped

1-4. Opening and closing the windows and moon roof

MATRIX_U

CAUTION

■

Closing the windows

Observe the following precautions.
Failing to do so may result in death or serious injury.

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in
some instances, even death.

1-4. Opening and closing the windows and moon roof

Be
fo

riv

MATRIX_U

Moon roof

∗

Use the overhead switches to open, close, and tilt the moon roof up
and down.

■

Opening and closing

Opens the moon roof*

The moon roof stops slightly
before the fully open position
to reduce wind noise.

Press the switch again to fully
open the moon roof.

Closes the moon roof*

*: Lightly press either of the moon

roof switches to stop the moon
roof partway.

■

Tilt up and down

Tilts the moon roof up*
Tilts the moon roof down*

*: Lightly press either of the moon

roof switches to stop the moon
roof partway.

∗

: If equipped

1-4. Opening and closing the windows and moon roof

MATRIX_U

■

The moon roof can be operated when

The engine switch is in the “ON” position.

■

Operating the moon roof after turning the engine OFF

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.

■

Jam protection function

If an object is detected between the moon roof and the frame while closing
or tilting down, travel is stopped and the moon roof opens slightly.

■

To reduce moon roof wind noise

When the moon roof is opened automatically, it will stop slightly before the
fully open position. Driving with the moon roof in this position can help
reduce wind noise.

■

Sunshade

The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

1-4. Opening and closing the windows and moon roof

Be
fo

riv

MATRIX_U

CAUTION

■

Opening the moon roof

Observe the following precautions.
Failing to do so may cause death or serious injury.

●

Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.

●

Do not sit on top of the moon roof.

■

Closing the moon roof

Observe the following precautions.
Failing to do so may result in death or serious injury.

●

Check to make sure that all passengers do not have any part of their bod-
ies in a position where it could be caught when the moon roof is being
operated.

●

Do not allow children to operate the moon roof.
Closing the moon roof on someone can cause death or serious injury.

■

Jam protection function

●

Never try jamming any part of your body to activate the jam protection
function intentionally.

●

The jam protection function may not work if something gets caught just
before the moon roof fully closes.

MATRIX_U

1-5. Refueling

Opening the fuel tank cap

Perform the following steps to open the fuel tank cap.

■

Before refueling the vehicle
Turn the engine switch OFF and ensure that all the doors and
windows are closed.

■

Opening the fuel tank cap

Pull up the fuel filler door
opener.

Turn the fuel tank cap slowly
to open.

Hang the fuel tank cap on the
back of the fuel filler door.

STEP

1-5. Refueling

Be
fo

riv

MATRIX_U

Closing the fuel tank cap

When replacing the fuel tank
cap, turn it until a clicking sound
is heard.

After releasing your hand, the cap
will turn slightly to the opposite
direction.

■

Fuel type

Unleaded gasoline (Octane rating 87 [Research Octane Number 91] or
higher)

■

Fuel tank capacity

13.2 gal. (50 L, 10.9 Imp. gal.)

1-5. Refueling

MATRIX_U

CAUTION

■

Refueling the vehicle

Observe the following precautions while refueling the vehicle.
Failure to do so may result in death or serious injury.

●

Touch the vehicle or some other metal surface to discharge any static
electricity.
Sparks resulting from discharging static electricity may cause the fuel
vapors to ignite.

●

Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened.
Wait until the sound cannot be heard before fully removing the cap.
In hot weather, pressurized fuel may spray out of the filler neck and cause
injury.

●

Do not allow anyone that has not discharged static electricity from their
bodies to come close to an open fuel tank.

●

Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.

●

Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.

●

Do not return to the vehicle or touch any person or object that is statically
charged.
This may cause static electricity to build up, resulting in a possible ignition
hazard.

■

When replacing the fuel cap

Do not use anything but a genuine Toyota fuel tank cap designed for your
vehicle. Doing so may cause a fire or other incident which may result in
death or serious injury.

1-5. Refueling

Be
fo

riv

MATRIX_U

NOTICE

■

Refueling

Do not spill fuel during refueling.
Doing so may damage the vehicle, such as causing the exhaust systems to
operate abnormally or damaging fuel system components or the vehicle's
painted surface.

MATRIX_U

1-6. Theft deterrent system

Engine immobilizer system

■

System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■

Conditions that may cause the system to malfunction

●

If the key is in contact with a metallic object

●

If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle

■

Certifications for the engine immobilizer system (for vehicles sold in
U.S.A.)

FCC ID: WRKRI-34BTY

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

The vehicle's keys have built-in transponder chips that prevent the
engine from starting if the key has not been previously registered in
the vehicle's on-board computer.

Never leave the keys inside the vehicle when you leave the vehicle.

The indicator light flashes after
the key has been removed
from the engine switch to indi-
cate that the system is operat-
ing.

The indicator light stops flash-
ing after the registered key
has been inserted into the
engine switch to indicate that
the system has been can-
celed.

1-6. Theft deterrent system

Be
fo

riv

MATRIX_U

■

Certifications for the engine immobilizer system (for vehicles sold in
Canada)

This device complies with Industry Canada licence-exempt RSS stan-
dard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interfer-
ence, including interference that may cause undesired operation of the
device.

CAUTION

Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

NOTICE

■

To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

Toyota Matrix (2014 year). Instruction - part 4
