Toyota Matrix (2014 year). Instruction

MATRIX_U

CAUTION

■

General precautions while driving

Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.

Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.

Driver distraction: Always give your full attention to driving. Anything that dis-
tracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.

■

General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to
have or use the key.

Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the cigarette lighter, the windows, or other features of the vehicle. In addi-
tion, heat build-up or extremely cold temperatures inside the vehicle can be
fatal to children.

MATRIX_U

Symbols used throughout this manual

Cautions & Notices

Symbols used in illustrations

CAUTION

This is a warning against anything which may cause death or injury to people if
the warning is ignored. You are informed about what you must or must not do
in order to reduce the risk of injury to yourself and others.

NOTICE

This is a warning against anything which may cause damage to the vehicle or
its equipment if the warning is ignored. You are informed about what you must
or must not do in order to avoid or reduce the risk of damage to your Toyota
and its equipment.

Safety symbol

The symbol of a circle with a slash through means “Do not”, “Do not
do this”, or “Do not let this happen”.

Arrows indicating operations

Indicates the action (pushing, turning,
etc.) used to operate switches and other
devices.

Indicates the outcome of an operation
(e.g. a lid opens).

Before driving

MATRIX_U

1-1. Key information

Keys ................................... 26

1-2. Opening, closing and

locking the doors

Wireless remote control .....  28
Doors .................................  31
Back door...........................  36

1-3. Adjustable components

(seats, mirrors,
steering wheel)

Front seats .........................  40
Rear seats..........................  44
Head restraints...................  46
Seat belts ...........................  48
Steering wheel ...................  54
Anti-glare inside rear

view mirror ....................... 55

Outside rear view

mirrors.............................. 57

1-4. Opening and closing the

windows and moon roof

Power windows .................. 59
Moon roof........................... 61

1-5. Refueling

Opening the fuel tank

cap ................................... 64

1-6. Theft deterrent system

Engine immobilizer

system ............................. 68

Theft prevention labels....... 70

1-7. Safety information

Correct driving posture....... 71
SRS airbags....................... 73
Front passenger occupant

classification system ........ 85

Child restraint systems....... 90
Installing child restraints..... 94

MATRIX_U

1-1. Key information

Keys

■

Key number plate

Keep the plate in a safe place such as your wallet, not in the vehicle. In the
event that a key is lost, a new key can be made by your Toyota dealer using
the key number plate. (

→P. 424)

■

When riding in an aircraft

When bringing a wireless remote control key onto an aircraft, make sure you
do not press any buttons on the wireless remote control key while inside the
aircraft cabin. If you are carrying the wireless remote control key in your bag
etc, ensure that the buttons are not likely to be pressed accidentally. Press-
ing a button may cause the wireless remote control key to emit radio waves
that could interfere with the operation of the aircraft.

The following keys are provided with the vehicle.

Vehicles without wireless remote control

Keys
Key number plate

Vehicles with wireless remote control

Keys

Operating the wireless remote
control function (

→P. 28)

Key number plate

1-1. Key information

Be
fo

riv

MATRIX_U

NOTICE

■

To prevent key damage

●

Do not subject the keys to strong shocks, expose them to high tempera-
tures by placing them in direct sunlight, or get them wet.

●

Do not expose the keys to electromagnetic materials or attach any mate-
rial that blocks electromagnetic waves to the key surface.

●

Do not disassemble the key.

MATRIX_U

1-2. Opening, closing and locking the doors

Wireless remote control

∗

■

Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)

■

Door lock buzzer

If a door is not fully closed, a buzzer sounds continuously for 10 seconds if
an attempt to lock the door is made. Fully close the door to stop the buzzer,
and lock the vehicle once more.

■

Panic mode

The wireless remote control can be used to lock and unlock the vehi-
cle from outside the vehicle.

Locks all doors
Sounds an alarm
(press and hold)
Unlocks doors

Pressing the button unlocks
the driver’s door. Pressing the
button again within 3 seconds
unlocks the other doors.

When

is pressed for longer

than about one second, an alarm will
sound intermittently and the vehicle
lights will flash to deter any person from
trying to break into or damage your
vehicle.

To stop the alarm, press any button on
the wireless remote control.

∗

: If equipped

1-2. Opening, closing and locking the doors

Be
fo

riv

MATRIX_U

■

Key battery depletion

If the wireless remote control function does not operate, the battery may be
depleted. Replace the battery when necessary. (

→P. 367)

■

Security feature

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.

■

Conditions affecting operation

The wireless remote control function may not operate normally in the follow-
ing situations.

●

Near a TV tower, radio station, electric power plant, airport or other facil-
ity that generates strong radio waves

●

When carrying a portable radio, cellular phone or other wireless commu-
nication devices

●

When multiple wireless keys are in the vicinity

●

When the wireless key has come into contact with, or is covered by, a
metallic object

●

When a wireless key (that emits radio waves) is being used nearby

●

When the wireless key has been left near an electrical appliance such as
a personal computer

●

When the wireless key battery is depleted

●

If window tint with a metallic content or metallic objects are attached to
the rear window

■

Customization that can be configured at Toyota dealer

Settings (e.g. operation signal) can be changed.
(Customizable features

→P. 469)

1-2. Opening, closing and locking the doors

MATRIX_U

■

Certification for wireless remote control

For vehicles sold in the U.S.A.

NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

For vehicles sold in Canada

NOTE:
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.

1-2. Opening, closing and locking the doors

Be
fo

riv

MATRIX_U

Doors

The vehicle can be locked and unlocked using the wireless remote
control, key or door lock switch.

■

Wireless remote control (if equipped)
→P. 28

■

Key

Locks the door
Unlocks the door

Vehicles with power door lock
system: Turning the key locks
and unlocks all doors. In the
driver’s door lock, turning the
key once unlocks the driver’s
door. Turning the key again
within 3 seconds unlocks the
other doors.

■

Door lock switch (if equipped)

Locks all doors
Unlocks all doors

1-2. Opening, closing and locking the doors

MATRIX_U

Rear door child-protector lock

The door cannot be opened from
inside the vehicle when the locks
are set.

Unlock
Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear
doors.

■

Inside lock button

Unlocks the door
Locks the door

The front doors can be opened
by pulling the inside handle
even if the lock buttons are in
the lock position.

1-2. Opening, closing and locking the doors

Be
fo

riv

MATRIX_U

Automatic door locking and unlocking systems (vehicles with
power door lock system)

The following functions can be set or cancelled:

: Vehicles with an automatic transmission only

The shift position linked door locking function works when all doors
are closed.

Function

Operation

Shift position linked
door locking function

Shifting the shift lever out of P locks all
doors.

Shift position linked
door unlocking func-
tion

Shifting the shift lever to P unlocks all doors.

Driver's door linked door
unlocking function

All doors are unlocked when the driver's door
is opened within 10 seconds after turning the
engine switch to “ACC” or “LOCK”.

1-2. Opening, closing and locking the doors

MATRIX_U

■

Setting and canceling the functions
To switch between set and canceled, follow the procedure below:

Close all the doors and switch the engine switch to the “ON”
position. (Perform step 2 within 10 seconds.)

Shift the shift lever to P or N, and
press and hold the driver's door
lock switch (

) for

approximately 5 seconds and
then release.

The shift lever and switch posi-
tions corresponding to the
desired function to be set are
shown as follows.

Use the same procedure to can-
cel the function.

: Vehicles with an automatic transmission only

When the setting or canceling operation is complete, all doors are
locked and then unlocked.

STEP

Function

Shift lever

position

Switch position

Shift position linked door lock-
ing function

Shift position linked door
unlocking function

Driver's door linked door unlock-
ing function

1-2. Opening, closing and locking the doors

Be
fo

riv

MATRIX_U

■

When all the doors are locked with the wireless remote control or key

The doors cannot be unlocked with the door lock switch.

The door lock switch can be reset by unlocking all the doors with the wire-
less remote control or key.

■

The doors cannot be locked when

The key is in the engine switch and either of the front door is open.

■

Customization that can be configured at Toyota dealer

Settings (e.g. unlocking function using a key) can be changed.
(Customizable features

→P. 469)

CAUTION

■

To prevent an accident

Observe the following precautions while driving the vehicle.
Failing to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.

●

Always use a seat belt.

●

Always lock the doors.

●

Ensure that all doors are properly closed.

●

Do not pull the inside handle of the doors while driving.
The doors may be opened and the passengers are thrown out of the vehi-
cle and it may result in serious injury or death.

Be especially careful for the front doors, as the doors may be opened even
if the inside lock buttons are in locked position.

●

Set the rear door child protector locks when children are seated in the rear
seat.

1-2. Opening, closing and locking the doors

MATRIX_U

Back door

■

Back door handle

The back door can be locked and unlocked using the wireless
remote control or key.

Wireless remote control (if equipped)
→

P. 28

Key

Locks the back door
Unlocks the back door
Opens the back door

Use the back door handle when closing.

1-2. Opening, closing and locking the doors

Be
fo

riv

MATRIX_U

CAUTION

■

Caution while driving

●

Keep the back door closed while driving.
If the back door is left open, it may hit nearby objects while driving or lug-
gage may be unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a seri-
ous health hazard. Make sure to close the back door before driving.

●

Before driving the vehicle, make sure that the back door is fully closed. If
the back door is not fully closed, it may open unexpectedly while driving,
causing an accident.

●

Never let anyone sit in the luggage compartment. In the event of sudden
braking or a collision, they are susceptible to death or serious injury.

■

When children are in the vehicle

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Do not allow children to play in the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could
have heat exhaustion or other injuries.

●

Do not allow a child to open or close the back door.
Doing so may cause the back door to operate unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door, which
may result in death or serious injury of the child.

■

Operating the back door

Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.

●

Remove any heavy loads, such as snow and ice, from the back door
before opening it. Failure to do so may cause the back door to suddenly
shut again after it is opened.

Toyota Matrix (2014 year). Instruction - part 2
