Toyota Corolla (2020 year). Owner's manual - part 28





438

7-3. Do-it-yourself maintenance

2

Holding a rag under the end,
pull the dipstick out.

1.8 L 4-cylinder (2ZR-FAE)
engine

2.0 L 4-cylinder (M20A-FKS)
engine

3

Wipe the dipstick clean.

4

Reinsert the dipstick fully.

5

Holding a rag under the end,
pull the dipstick out and
check the oil level.

Low

Normal
Excessive

The shape of the dipstick may differ

depending on the type of vehicle or

engine.

6

Wipe the dipstick and reinsert
it fully.

Checking the oil type and
preparing the item needed

Make sure to check the oil type
and prepare the items needed
before adding oil.

Engine oil selection
P.526, 527

Oil quantity (Low  Full)
1.6 qt. (1.5 L, 1.3 Imp. qt.)

Item
Clean funnel

Adding engine oil

If the oil level is below or near
the low level mark, add engine
oil of the same type as that
already in the engine.

1.8 L 4-cylinder (2ZR-FAE)
engine

-------------------------------------------------------------------------------------------------------------------------------------------------------------

439

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

2.0 L 4-cylinder (M20A-FKS)
engine

1

Remove the oil filler cap by
turning it counterclockwise.

2

Add engine oil slowly, check-
ing the dipstick.

3

Install the oil filler cap by
turning it clockwise.

Engine oil consumption

A certain amount of engine oil will

be consumed while driving. In the

following situations, oil consump-

tion may increase, and engine oil

may need to be refilled in between

oil maintenance intervals.

When the engine is new, for

example directly after purchasing

the vehicle or after replacing the

engine

If low quality oil or oil of an inap-

propriate viscosity is used

When driving at high engine

speeds or with a heavy load, or

when driving while accelerating or

decelerating frequently

When leaving the engine idling for

a long time, or when driving fre-

quently through heavy traffic

WARNING

Used engine oil

Used engine oil contains poten-

tially harmful contaminants

which may cause skin disorders

such as inflammation and skin

cancer, so care should be taken

to avoid prolonged and

repeated contact. To remove

used engine oil from your skin,

wash thoroughly with soap and

water.

Dispose of used oil and filters

only in a safe and acceptable

manner. Do not dispose of used

oil and filters in household trash,

in sewers or onto the ground.

Call your Toyota dealer, service

station or auto parts store for

information concerning recy-

cling or disposal.

Do not leave used engine oil

within the reach of children.

NOTICE

To prevent serious engine

damage

Check the oil level on a regular

basis.

When replacing the engine oil

Be careful not to spill engine oil

on the vehicle components.

Avoid overfilling, or the engine

could be damaged.

Check the oil level on the dip-

stick every time you refill the

vehicle.

Be sure the engine oil filler cap

is properly tightened.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

440

7-3. Do-it-yourself maintenance

The coolant level is satisfactory
if it is between the “FULL” and
“LOW” lines on the reservoir
when the engine is cold.

Reservoir cap
“FULL” line
“LOW” line

If the level is on or below the “LOW”
line, add coolant up to the “FULL”
line. (P.519)

Coolant selection

Only use “Toyota Super Long Life

Coolant” or a similar high quality

ethylene glycol based non-silicate,

non-amine, non-nitrite, and

non-borate coolant with long-life

hybrid organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is

a mixture of 50% coolant and 50%

deionized water. (Minimum tem-

perature: -31°F [-35°C])
Canada:
“Toyota Super Long Life Coolant” is

a mixture of 55% coolant and 45%

deionized water. (Minimum tem-

perature: -44°F [-42°C])
For more details about coolant, con-

tact your Toyota dealer.

If the coolant level drops within

a short time of replenishing

Visually check the radiator, hoses,

engine coolant reservoir caps, drain

cock and water pump.

If you cannot find a leak, have your

Toyota dealer test the cap and

check for leaks in the cooling sys-

tem.

Check the radiator and con-
denser and clear away any for-
eign objects. If either of the
above parts is extremely dirty or
you are not sure of their condi-
tion, have your vehicle
inspected by your Toyota dealer.

Checking the engine cool-
ant

WARNING

When the engine is hot

Do not remove the engine coolant

reservoir cap.
The cooling system may be under

pressure and may spray hot cool-

ant if the cap is removed, causing

serious injuries, such as burns.

NOTICE

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct

mixture of water and antifreeze

must be used to provide proper

lubrication, corrosion protection

and cooling. Be sure to read the

antifreeze or coolant label.

If you spill coolant

Be sure to wash it off with water to

prevent it from damaging parts or

paint.

Checking the radiator and
condenser

-------------------------------------------------------------------------------------------------------------------------------------------------------------

441

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

Checking fluid level

The brake fluid level should be
between the “MAX” and “MIN”
lines on the tank.

Adding fluid

1

Slide and lift up the rubber
strip to partly remove it as
shown.

2

Disconnect the claws and
remove the service cover.

3

Remove the reservoir cap.

4

Add brake fluid slowly while
checking the fluid level.

Make sure to check the fluid
type and prepare the necessary
item.

Fluid type

FMVSS No.116 DOT 3 or SAE
J1703 brake fluid
FMVSS No.116 DOT 4 or SAE
J1704 brake fluid

Item

Clean funnel

Brake fluid can absorb moisture

from the air

Excess moisture in the brake fluid

can cause a dangerous loss of brak-

ing efficiency. Use only newly

opened brake fluid.

WARNING

When the engine is hot

Do not touch the radiator or con-

denser as they may be hot and

cause serious injuries, such as

burns.

Checking and adding the
brake fluid

-------------------------------------------------------------------------------------------------------------------------------------------------------------

442

7-3. Do-it-yourself maintenance

Check the battery as follows.

Battery exterior

Make sure that the battery termi-
nals are not corroded and that
there are no loose connections,
cracks, or loose clamps.

Terminals
Hold-down clamp

Before recharging

When recharging, the battery pro-

duces hydrogen gas which is flam-

mable and explosive. Therefore,

observe the following precautions

before recharging:

If recharging with the battery

installed on the vehicle, be sure to

disconnect the ground cable.

Make sure the engine switch on

the charger is off when connecting

and disconnecting the charger

cables to the battery.

After recharging/reconnecting

the battery (vehicles with a

smart key system)

Unlocking the doors using the

smart key system may not be pos-

sible immediately after reconnect-

ing the battery. If this happens,

use the wireless remote control or

the mechanical key to lock/unlock

the doors.

Start the engine with the engine

switch in ACC. The engine may

not start with the engine switch

turned off. However, the engine

will operate normally from the sec-

ond attempt.

The engine switch mode is

recorded by the vehicle. If the bat-

tery is reconnected, the vehicle

will return the engine switch mode

to the status it was in before the

battery was disconnected. Make

sure to turn off the engine before

disconnecting the battery. Take

extra care when connecting the

battery if the engine switch mode

prior to discharge is unknown.

If the system will not start even after

multiple attempts, contact your Toy-

ota dealer.

WARNING

When filling the reservoir

Take care as brake fluid can harm

your hands and eyes and damage

painted surfaces.

If fluid gets on your hands or in

your eyes, flush the affected area

with clean water immediately.
If you still experience discomfort,

see a doctor.

NOTICE

If the fluid level is low or high

It is normal for the brake fluid level

to go down slightly as the brake

pads wear out or when the fluid

level in the accumulator is high.

If the reservoir needs frequent

refilling, there may be a serious

problem.

Battery

-------------------------------------------------------------------------------------------------------------------------------------------------------------

443

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

Add washer fluid in the following
situations:

A washer does not work.

The warning message
appears on the multi-informa-
tion display.

WARNING

Chemicals in the battery

The battery contains poisonous

and corrosive sulfuric acid and

may produce hydrogen gas which

is flammable and explosive. To

reduce the risk of death or serious

injury, take the following precau-

tions while working on or near the

battery:

Do not cause sparks by touch-

ing the battery terminals with

tools.

Do not smoke or light a match

near the battery.

Avoid contact with eyes, skin

and clothes.

Never inhale or swallow electro-

lyte.

Wear protective safety glasses

when working near the battery.

Keep children away from the

battery.

Where to safely charge the

battery

Always charge the battery in an

open area. Do not charge the bat-

tery in a garage or closed room

where there is insufficient ventila-

tion.

Emergency measures regard-

ing electrolyte

If electrolyte gets in your eyes

Flush your eyes with clean

water for at least 15 minutes

and get immediate medical

attention. If possible, continue

to apply water with a sponge or

cloth while traveling to the near-

est medical facility.

If electrolyte gets on your skin

Wash the affected area thor-

oughly. If you feel pain or burn-

ing, get medical attention

immediately.

If electrolyte gets on your

clothes

It can soak through clothing on

to your skin. Immediately take

off the clothing and follow the

procedure above if necessary.

If you accidentally swallow elec-

trolyte

Drink a large quantity of water

or milk. Get emergency medical

attention immediately.

When disconnecting the bat-

tery

Do not disconnect the negative (-)

terminal on the body side. The

disconnected negative (-) terminal

may touch the positive (+) termi-

nal, which may cause a short and

result in death or serious injury.

NOTICE

When recharging the battery

Never recharge the battery while

the engine is running. Also, be

sure all accessories are turned

off.

Adding the washer fluid

-------------------------------------------------------------------------------------------------------------------------------------------------------------

444

7-3. Do-it-yourself maintenance

Check if the treadwear indica-
tors are showing on the tires.
Also check the tires for uneven
wear, such as excessive wear
on one side of the tread.
Check the spare tire condition
and pressure if not rotated.

New tread
Worn tread
Treadwear indicator

The location of treadwear indicators
is shown by a “TWI” or “

” mark,

WARNING

When adding washer fluid

Do not add washer fluid when the

engine is hot or running as

washer fluid contains alcohol and

may catch fire if spilled on the

engine, etc.

NOTICE

Do not use any fluid other

than washer fluid

Do not use soapy water or engine

antifreeze instead of washer fluid.

Doing so may cause streaking on

the vehicle’s painted surfaces, as

well as damaging the pump lead-

ing to problems of the washer

fluid not spraying.

Diluting washer fluid

Dilute washer fluid with water as

necessary.

Refer to the freezing tempera-

tures listed on the label of the

washer fluid bottle.

Tires

Replace or rotate tires in
accordance with mainte-
nance schedules and tread-
wear.

Checking tires

-------------------------------------------------------------------------------------------------------------------------------------------------------------

445

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

etc., molded into the sidewall of
each tire.
Replace the tires if the treadwear
indicators are showing on a tire.

When to replace your vehicle’s

tires

Tires should be replaced if:

The treadwear indicators are

showing on a tire

You have tire damage such as

cuts, splits, cracks deep enough

to expose the fabric, and bulges

indicating internal damage

A tire goes flat repeatedly or can-

not be properly repaired due to the

size or location of a cut or other

damage

If you are not sure, consult with your

Toyota dealer.

Tire life

Any tire over 6 years old must be

checked by a qualified technician

even if it has seldom or never been

used or damage is not obvious.

Low profile tires (18-inch tires)

Generally, low profile tires will wear

more rapidly and tire grip perfor-

mance will be reduced on snowy

and/or icy roads when compared to

standard tires. Be sure to use snow

tires or tire chains on snowy and/or

icy roads and drive carefully at a

speed appropriate for road and

weather conditions.

Maximum load of tire

Check that the maximum load of the

replacement tire is greater than 1/2

of the Gross Axle Weight Ratings

(GAWR) of either the front axle or

the rear axle, whichever is greater.
For the GAWR, see the Certification

Label.

For the maximum load of the tire,

see the load limit at maximum cold

tire inflation pressure mentioned on

the sidewall of the tire. (P.537)

Tire types

Summer tires

Summer tires are high-speed perfor-
mance tires best suited to highway
driving under dry conditions. Since
summer tires do not have the same
traction performance as snow tires,
summer tires are inadequate for
driving on snow-covered or icy
roads. For driving on snow-covered
roads or icy roads, the use of snow
tires is recommended. When install-
ing snow tires, be sure to replace all
four tires.

All season tires

All season tires are designed to pro-
vide better traction in snow and to
be adequate for driving in most win-
ter conditions as well as for use
year-round. All season tires, how-
ever, do not have adequate traction
performance compared with snow
tires in heavy or loose snow. Also,
all season tires fall short in accelera-
tion and handling performance com-
pared with summer tires in highway
driving.

Snow tires

For driving on snow-covered roads
or icy roads, we recommend using
snow tires. If you need snow tires,
select tires of the same size, con-
struction and load capacity as the
originally installed tires. Since your
vehicle has radial tires as original
equipment, make sure your snow

-------------------------------------------------------------------------------------------------------------------------------------------------------------

446

7-3. Do-it-yourself maintenance

tires also have radial construction.
Do not install studded tires without
first checking local regulations for
possible restrictions. Snow tires
should be installed on all wheels.
(P.255)

If the tread on snow tires wears

down below 0.16 in. (4 mm)

The effectiveness of the tires as

snow tires is lost.

Checking the tire valves

When replacing the tires, check the

tire valves for deformation, cracks,

and other damage.

Rotate the tires in the order
shown.

WARNING

When inspecting or replacing

tires

Observe the following precautions

to prevent accidents.

Failure to do so may cause dam-

age to parts of the drive train as

well as dangerous handling char-

acteristics, which may lead to an

accident resulting in death or seri-

ous injury.

Do not mix tires of different

makes, models or tread pat-

terns.

Also, do not mix tires of remark-

ably different treadwear.

Do not use tire sizes other than

those recommended by Toyota.

Do not mix differently con-

structed tires (radial, bias-belted

or bias-ply tires).

Do not mix summer, all season

and snow tires.

Do not use tires that have been

used on another vehicle.

Do not use tires if you do not

know how they were used previ-

ously.

NOTICE

Low profile tires (18-inch

tires)

Low profile tires may cause

greater damage than usual to the

tire wheel when sustaining impact

from the road surface. Therefore,

pay attention to the following:

Be sure to use proper tire infla-

tion pressure. If tires are

under-inflated, they may be

damaged more severely.

Avoid potholes, uneven pave-

ment, curbs and other road haz-

ards. Failure to do so may lead

to severe tire and wheel dam-

age.

If tire inflation pressure of

each tire becomes low while

driving

Do not continue driving, or your

tires and/or wheels may be

ruined.

Driving on rough roads

Take particular care when driving

on roads with loose surfaces or

potholes.

These conditions may cause

losses in tire inflation pressure,

reducing the cushioning ability of

the tires. In addition, driving on

rough roads may cause damage

to the tires themselves, as well as

the vehicle’s wheels and body.

Tire rotation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

447

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

Front

To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.
Vehicles with a tire pressure warn-
ing system: Do not fail to initialize
the tire pressure warning system
after tire rotation.

Your vehicle is equipped with a
tire pressure warning system
that uses tire pressure warning
valves and transmitters to detect
low tire inflation pressure before
serious problems arise.
If the tire pressure drops below
a predetermined level, the driver
is warned by a warning light.
(P.485)

Routine tire inflation pressure

checks

The tire pressure warning system

does not replace routine tire inflation

pressure checks. Make sure to

check tire inflation pressure as part

of your routine of daily vehicle

checks.

Situations in which the tire

pressure warning system may

not operate properly

In the following cases, the tire

pressure warning system may not

operate properly.

• If non-genuine Toyota wheels are

used.

• A tire has been replaced with a

tire that is not an OE (Original

Equipment) tire.

• A tire has been replaced with a

tire that is not of the specified size.

• Tire chains, etc. are equipped.

• An auxiliary-supported run-flat tire

is equipped.

• If a window tint that affects the

radio wave signals is installed.

• If there is a lot of snow or ice on

the vehicle, particularly around the

wheels or wheel housings.

• If the tire inflation pressure is

extremely higher than the speci-

fied level.

• If tires not equipped with tire pres-

sure warning valves and transmit-

ters are used.

• If the ID code on the tire pressure

warning valves and transmitters is

not registered in the tire pressure

warning computer.

Performance may be affected in

the following situations.

• Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise.

• When carrying a portable radio,

cellular phone, cordless phone or

other wireless communication

device.

When the vehicle is parked, the

time taken for the warning to start

or go off could be extended.

When tire inflation pressure

declines rapidly for example when

a tire has burst, the warning may

not function.

Tire pressure warning
system (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

448

7-3. Do-it-yourself maintenance

Warning performance of the tire

pressure warning system

The warning of the tire pressure

warning system will change in

accordance with driving conditions.

For this reason, the system may

give a warning even if the tire pres-

sure does not reach a low enough

level, or if the pressure is higher

than the pressure that was adjusted

to when the system was initialized.

Tire pressure warning system certification

Except for vehicles sold in Canada

-------------------------------------------------------------------------------------------------------------------------------------------------------------

449

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

For vehicles sold in Canada

When replacing tires or wheels,
tire pressure warning valves and
transmitters must also be
installed.
When new tire pressure warning
valves and transmitters are
installed, new ID codes must be
registered in the tire pressure
warning computer and the tire
pressure warning system must
be initialized. Have tire pressure
warning valves and transmitter
ID codes registered by your Toy-
ota dealer. (P.451)

Replacing tires and wheels

If the ID code of the tire pressure

warning valve and transmitter is not

registered, the tire pressure warning

system will not work properly. After

driving for about 20 minutes, the tire

pressure warning light blinks for 1

minute and stays on to indicate a

system malfunction.

Installing tire pressure
warning valves and trans-
mitters (vehicles with a
tire pressure warning sys-
tem)

NOTICE

Repairing or replacing tires,

wheels, tire pressure warn-

ing valves, transmitters and

tire valve caps

When removing or fitting the

wheels, tires or the tire pressure

warning valves and transmit-

ters, contact your Toyota dealer

as the tire pressure warning

valves and transmitters may be

damaged if not handled cor-

rectly.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

450

7-3. Do-it-yourself maintenance

The tire pressure warning
system must be initialized
in the following circum-
stances:

When rotating front and rear
tires which have different tire
inflation pressures.

When changing the tire size.

When the tire inflation pres-
sure is changed such as
when changing traveling
speed or load weight.

When changing between two

registered wheel sets.

When the tire pressure warning
system is initialized, the current
tire inflation pressure is set as
the benchmark pressure.

How to initialize the tire
pressure warning system

1

Park the vehicle in a safe
place and turn the engine
switch off.

Initialization cannot be performed

while the vehicle is moving.

2

Adjust the tire inflation pres-
sure to the specified cold tire
inflation pressure level.
(P.531)

Make sure to adjust the tire pres-

sure to the specified cold tire infla-

tion pressure level. The tire

pressure warning system will oper-

ate based on this pressure level.

3

Turn the engine switch to
ON.

4

Press

 or

 of the meter

control switch to select

.

5

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

6

Press

 or

 to select

“TPWS” and then press

.

7

Press

 or

 to select “Set

Pressure”. Then press and

hold

 until the tire pres-

NOTICE

Make sure to install the tire

valve caps. If the tire valve caps

are not installed, water could

enter the tire pressure warning

valves and the tire pressure

warning valves could be bound.

When replacing tire valve caps,

do not use tire valve caps other

than those specified. The cap

may become stuck.

To avoid damage to the tire

pressure warning valves and

transmitters

When a tire is repaired with liquid

sealants, the tire pressure warn-

ing valve and transmitter may not

operate properly. If a liquid seal-

ant is used, contact your Toyota

dealer or other qualified service

shop as soon as possible. Make

sure to replace the tire pressure

warning valve and transmitter

when replacing the tire. (

P.449)

Initializing the tire pres-
sure warning system (if
equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

451

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

sure warning light blinks 3
times.

Initialization procedure

Make sure to carry out initializa-

tion after adjusting the tire inflation

pressure.

Also, make sure the tires are cold

before carrying out initialization or

tire inflation pressure adjustment.

If you have accidentally turned the

engine switch off during initializa-

tion, it is not necessary to press

the reset switch again as initializa-

tion will restart automatically when

the engine switch to ON for the

next time.

If initialization has accidentally

been started when it is not neces-

sary, adjust the tire inflation pres-

sure to the specified level when

the tires are cold, and then per-

form the initialization procedure

again.

When initialization of the tire

pressure warning system has

failed

Initialization can be completed in a

few minutes. However, in the follow-

ing cases, the settings have not

been recorded and the system will

not operate properly. If repeated

attempts to record tire inflation pres-

sure settings are unsuccessful,

have the vehicle inspected by your

Toyota dealer.

When attempting to start initializa-

tion, the tire pressure warning light

does not blink 3 times.

After driving for a certain period of

time since the initialization has

been completed, the warning light

comes on after blinking for 1 min-

ute.

The tire pressure warning valve
and transmitter is equipped with
a unique ID code. When replac-
ing a tire pressure warning valve
and transmitter, it is necessary
to register the ID code. Have the
ID code registered by your Toy-
ota dealer.

Your vehicle is equipped with
tire pressure warning system
with the function to have ID
codes registered for a second
wheel set, for example a winter
set, by Toyota dealer.
After registration of a second
wheel set, either of these two
wheel sets can be selected for
usage with the tire pressure
warning system.

WARNING

When initializing the tire pres-

sure warning system

Do not initialize the tire pressure

warning system without first

adjusting the tire inflation pres-

sure to the specified level. Other-

wise, the tire pressure warning

light may not come on even if the

tire inflation pressure is low, or it

may come on when the tire infla-

tion pressure is actually normal.

Registering ID codes

Selecting wheel set

-------------------------------------------------------------------------------------------------------------------------------------------------------------

452

7-3. Do-it-yourself maintenance

Operating conditions for
the function

This function will perform the
change of wheel set only if a
second wheel set has been
registered. If no second wheel
set has been registered, no
change will be made when
selecting this function in the
menu.

Only a change between both
registered wheel set is possi-
ble, mixing between these
wheel sets is not supported.

How to change between
wheel sets

1

Have the vehicle fitted with
the preferred wheel set.

2

Press

 or

 of the meter

control switch to select

.

3

Press

 or

 to select

“Vehicle Settings” and then

press

.

4

Press

 or

 to select

“TPWS” and then press

.

5

Press

 or

 to select

“Change Wheel”. Then press

and hold

until the tire

pressure warning light blinks
slowly 3 times.

6

Initialize the tire pressure
warning system. (P.450)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

453

7-3. Do-it-yourself maintenance

7

Maintena

nce
 a

nd ca

re

The recommended cold tire
inflation pressure and tire size
are displayed on the tire and
loading information label.
(P.531)

Tire valve

Tire pressure gauge

1

Remove the tire valve cap.

2

Press the tip of the tire pres-
sure gauge onto the tire
valve.

3

Read the pressure using the
gauge gradations.

4

If the tire inflation pressure is
not at the recommended
level, adjust the pressure.
If you add too much air, press
the center of the valve to
deflate.

5

After completing the tire infla-
tion pressure measurement
and adjustment, apply soapy
water to the valve and check
for leakage.

6

Put the tire valve cap back
on.

Tire inflation pressure check

interval

You should check tire inflation pres-

sure every two weeks, or at least

once a month. Do not forget to

check the spare.

Effects of incorrect tire inflation

pressure

Driving with incorrect tire inflation

pressure may result in the following:

Reduced fuel economy

Reduced driving comfort and poor

handling

Reduced tire life due to wear

Reduced safety

Damage to the drive train

If a tire needs frequent inflating,

have it checked by your Toyota

dealer.

Tire inflation pressure

Checking the specified
tire inflation pressure

Inspection and adjust-
ment procedure

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     26      27      28      29     ..
