Toyota Tundra (2015 year). Manual - part 671
Last Modified: 9-16-2014
6.6 D
Doc ID: RM000000W7I0S2X
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: AB60F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMISSION SYSTEM: DEFINITION OF TERMS; 2015
MY Tundra [08/2014 - ]
DEFINITION OF TERMS
TERM
DEFINITION
Monitor description
Related DTCs
Typical enabling
condition
Preconditions that allow the ECM to detect malfunctions.
With all preconditions satisfied, the ECM sets the DTC when the monitored value(s)
exceeds the malfunction threshold(s).
used to detect the malfunction.
While a sensor is being monitored, the next sensor or component will not be monitored
until the previous monitoring has concluded.
Required
sensor/components
The sensors and components that are used by the ECM to detect malfunctions.
"Once per driving cycle" means that the ECM detects the malfunction only one time
during a single driving cycle.
"Continuous" means that the ECM detects the malfunction every time the enabling
condition is met.
Duration
The minimum time that the ECM must detect a continuous deviation in the monitored
value(s) before setting a DTC. This timing begins after the "typical enabling conditions"
are met.
Malfunction thresholds
Beyond this value, the ECM will conclude that there is a malfunction and set a DTC.
MIL operation
MIL illumination timing after a defect is detected.
"Immediately" means that the ECM illuminates the MIL the instant the ECM determines
that there is a malfunction.
"2 driving cycles" means that the ECM illuminates the MIL if the same malfunction is
detected again in the 2nd driving cycle.
Component operating
range
They cannot be used to judge if a sensor or solenoid is defective or not.
