Toyota Tundra (2015 year). Manual - part 2631
Last Modified: 9-16-2014
6.6 G
Doc ID: RM000002WBB015X
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: 3UR-FE STARTING: ACC RELAY: ON-VEHICLE INSPECTION; 2015 MY Tundra [08/2014 - ]
ON-VEHICLE INSPECTION
1. INSPECT MAIN BODY ECU (ACC RELAY)
Standard resistance:
TESTER
CONNECTION
CONDITION
SPECIFIED
CONDITION
DD-47 - DD-8
When battery voltage is not applied between DD-45 and
DD-62
10 kΩ or higher
When battery voltage is applied between DD-45 and DD-62
Below 1 Ω
If the result is not as specified, replace the main body ECU.
