Toyota Tundra (2015 year). Manual - part 2591
Last Modified: 9-16-2014
6.6 A
Doc ID: RM000002H8D02MX
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: 3UR-FE FUEL: FUEL PRESSURE REGULATOR: REMOVAL; 2015 MY Tundra [08/2014 - ]
REMOVAL
1. PRECAUTION
NOTICE:
After turning the ignition switch off, waiting time may be required before disconnecting the cable from
the battery terminal. Therefore, make sure to read the disconnecting the cable from the battery
terminal notice before proceeding with work
.
2. DISCHARGE FUEL SYSTEM PRESSURE
3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
4. REMOVE V-BANK COVER
5. REMOVE AIR CLEANER HOSE ASSEMBLY
6. REMOVE FUEL PRESSURE REGULATOR ASSEMBLY
(a) Disconnect the No. 2 fuel tube from the pressure regulator
.
CAUTION:
Put a cloth or equivalent under the pressure regulator.
(b) Disconnect the vacuum sensing hose from the pressure
regulator.
(c) Remove the 2 bolts, and pull out the pressure regulator.
(d) Remove the O-ring from the pressure regulator.
