Toyota Tundra (2015 year). Manual

Last Modified: 9-16-2014

6.6 A

Doc ID: RM000002W7Y00XX

Model Year: 2015

Model: Tundra

Prod Date Range: [08/2014 - ]

Title: INTERIOR: ROOF HEADLINING (for Double Cab): REMOVAL; 2015 MY Tundra [08/2014 - ]

REMOVAL

1. PRECAUTION

NOTICE:

After turning the ignition switch off, waiting time may be required before disconnecting the cable from the

battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice

before proceeding with work

2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL

CAUTION:

Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the

SRS system.

NOTICE:

When disconnecting the cable, some systems need to be initialized after the cable is reconnected

3. REMOVE FRONT SEAT ASSEMBLY (for Manual Seat)

4. REMOVE FRONT SEAT ASSEMBLY (for Power Seat)

5. REMOVE FRONT SEAT ASSEMBLY (for Center Seat)

6. REMOVE REAR SEAT ASSEMBLY

7. REMOVE FRONT DOOR SCUFF PLATE LH

(a) Detach the 6 claws and 3 clips, and remove the front door scuff

plate LH.

8. REMOVE FRONT DOOR SCUFF PLATE RH

HINT:

INTERIOR: ROOF HEADLINING (for Double Cab): REMOVAL; 2015...

Toyota Tundra (2015 year). Manual - part 2396
