Toyota Tundra (2015 year). Manual - part 2374
Last Modified: 9-16-2014
6.6 A
Doc ID: RM00000311L00IX
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: ENGINE IMMOBILISER: TRANSPONDER KEY ECU: REMOVAL; 2015 MY Tundra [08/2014 - ]
REMOVAL
1. PRECAUTION
NOTICE:
After turning the ignition switch off, waiting time may be required before disconnecting the cable from the
battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice
before proceeding with work
.
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the
SRS system.
NOTICE:
When disconnecting the cable, some systems need to be initialized after the cable is reconnected
.
3. REMOVE AIR CONDITIONING UNIT
4. REMOVE TRANSPONDER KEY ECU
shown in the illustration.
