TESTER DISPLAY
MEASUREMENT ITEM/RANGE
NORMAL CONDITION
DIAGNOSTIC
NOTE
Door Lock
SW-Unlock
Door manual unlock switch signal /
ON or OFF
ON: Door control switch (for driver
side door) is turned to unlock position
OFF: Door control switch (for driver
side door) is turned to lock position
-
Door Key
SW-Lock
Door key linked lock switch signal /
ON or OFF
ON: Driver side door key cylinder is
turned to lock position
OFF: Driver side door key cylinder is
turned to unlock position
-
Door Key
SW-Unlock
Door key linked unlock switch
signal / ON or OFF
ON: Driver side door key cylinder is
turned to unlock position
OFF: Driver side door key cylinder is
turned to lock position
-
Key Unlock
Warning SW
Unlock warning switch / ON or OFF
ON: Ignition key is inserted
OFF: Ignition key is not inserted
-
HINT:
*1: for Double Cab
*2: for CrewMax
2. PERFORM ACTIVE TEST
HINT:
Using the Techstream to perform Active Tests allows relays, VSVs and actuators and other items to be
operated without removing any parts. This non-intrusive functional inspection can be very useful because
intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early
in troubleshooting is one way to save diagnostic time. Data List information can be displayed while
performing Active Tests.
(a) Connect the Techstream to the DLC3.
(b) Turn the ignition switch ON.
(c) Enter the following menus: Body Electrical / Main Body / Active Test.
(d) Perform the Active Test by referring to the table below.
Main body
TESTER DISPLAY
TEST PART
CONTROL RANGE
DIAGNOSTIC NOTE
Wireless buzzer
Sounds wireless buzzer
ON/OFF
-
Hazard
Flasher relay
ON/OFF
-
Vehicle Horn
Sounds vehicle horn
ON/OFF
-
Security Horn
Sounds security horn
ON/OFF
-
Door Lock
Operate door lock motor
LOCK/UNLOCK
-
D-Door Unlock
Operate driver side door lock motor unlock
ON/OFF
-
