Toyota Tundra (2015 year). Manual - part 2349
Last Modified: 9-16-2014
6.6 D
Doc ID: RM000001WYK015X
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: DOOR LOCK: WIRELESS DOOR LOCK CONTROL SYSTEM: CUSTOMIZE PARAMETERS; 2015 MY Tundra
[08/2014 - ]
CUSTOMIZE PARAMETERS
1. CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE)
HINT:
The following items can be customized.
NOTICE:
When the customer requests a change in a function, first make sure that the function can be customized.
Record the current settings before customizing.
When troubleshooting a function, first make sure that the function is set to the default setting.
(a) Connect the Techstream to the DLC3.
(b) Turn the ignition switch ON.
(c) Turn the Techstream on.
(d) Enter the following menus: Customize Setting.
(e) Select the setting by referring to the table below.
Main Body
DISPLAY
DEFAULT
CONTENTS
SETTING
Hazard
Answer Back
ON
When LOCK switch on transmitter is pressed, all hazard warning lights
illuminate once. When UNLOCK switch is pressed, all hazard warning
lights illuminate twice.
ON / OFF
Wireless
Buzzer Resp
ON
Function that makes wireless buzzer sound for answer-back when
transmitter LOCK / UNLOCK switch is pressed.
ON / OFF
Open Door
Warning
ON
If door is not completely closed and transmitter LOCK switch is
pressed, this function sounds a buzzer for 10 seconds.
ON / OFF
Wireless
Control
ON
Panic
Function
ON
Operates security alarm when PANIC switch on transmitter is
continuously pressed for 1 second.
ON / OFF
Unlock / 2
Operation
ON
Function that unlocks driver side door when unlock switch on
transmitter is pressed once, and unlocks all doors when pressed twice.
If setting is OFF, pressing unlock switch once makes all doors unlock.
ON / OFF
Wireless
Auto Lock
ON
ON / OFF
Auto Lock
Time
30
seconds
Function to change time until relocking after unlocking.
60 seconds/30
seconds
2. CUSTOMIZING FUNCTION WITH MULTI-DISPLAY
HINT:
The following items can be customized.
DOOR LOCK: WIRELESS DOOR LOCK CONTROL SYSTEM: CUST...
