Toyota Tundra (2015 year). Manual - part 2173

TESTER

DISPLAY

MEASUREMENT ITEM/RANGE

NORMAL CONDITION

DIAGNOSTIC

NOTE

Number of

Trouble Codes

Main Body

TESTER DISPLAY

MEASUREMENT ITEM/RANGE

NORMAL CONDITION

DIAGNOSTIC

NOTE

D Door Courtesy

Driver side door courtesy switch signal / ON or

OFF

ON: Driver door open

OFF: Driver door closed

P Door Courtesy

Front passenger side door courtesy switch

signal / ON or OFF

ON: Front passenger

door open

OFF: Front passenger

door closed

Door Lock SW-Lock Driver side door lock switch signal / ON or OFF

ON: Door control switch

is pushed to lock position

OFF: Door control switch

is not pushed

Door Lock

SW-Unlock

Driver side door unlock switch signal / ON or

OFF

ON: Door control switch

is pushed to unlock

position

OFF: Door control switch

is not pushed

Door Key P/W Up

Function to close the driver side door window

while holding the key to the lock side for more

than about 2.3 seconds / ON or OFF

Customize setting

displayed

Door Key P/W

Down

Function to open the driver side door window

while holding the key to the unlock side for

more than about 2.3 seconds / ON or OFF

Customize setting

displayed

Communication

D-Door Motor

Connection status between power window

regulator motor (for driver side) and main body

ECU / OK or Stop

OK: Connection

Stop: No connection

Communication

P-Door Motor

Connection status between power window

regulator motor (for front passenger side) and

main body ECU / OK or Stop

OK: Connection

Stop: No connection

Communication

Master SW

Connection status between master switch and

main body ECU / OK or Stop

OK: Connection

Stop: No connection

Door Key SW-Lock Door key linked lock switch signal / ON or OFF

ON: Driver side door key

cylinder is turned to lock

position

OFF: Driver side door key

cylinder is not turned

Door Key

SW-Unlock

Door key linked unlock switch signal / ON or

OFF

ON: Driver side door key

cylinder is turned to

unlock position

WINDSHIELD / WINDOWGLASS: POWER WINDOW CONTROL ...

TESTER DISPLAY

MEASUREMENT ITEM/RANGE

NORMAL CONDITION

DIAGNOSTIC

NOTE

OFF: Driver side door key

cylinder is not turned

2. PERFORM ACTIVE TEST

HINT:

Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be

operated without removing any parts. This non-intrusive functional inspection can be very useful because
intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early
in troubleshooting is one way to save diagnostic time. Data List information can be displayed while
performing Active Tests.

(a) Warm up the engine.

(b) Turn the ignition switch off.

(d) Turn the ignition switch to ON.

(e) Turn the Techstream on.

(f) Enter the following menus: Body Electrical / (desired system) / Active Test.

(g) According to the display on the Techstream, perform the Active Test.

CAUTION:

Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam

protection function does not operate.

D-Door Motor

TESTER DISPLAY

TEST PART

CONTROL RANGE

DIAGNOSTIC NOTE

Power Window

Driver side power window

OFF/UP/DOWN

P-Door Motor

TESTER DISPLAY

TEST PART

CONTROL RANGE

DIAGNOSTIC NOTE

Power Window

Front passenger side power window

OFF/UP/DOWN

Main Body

TESTER DISPLAY

TEST PART

CONTROL

RANGE

DIAGNOSTIC

NOTE

IG OFF P/W Control Permission

Output

Power window control permission

output

ON or OFF

WINDSHIELD / WINDOWGLASS: POWER WINDOW CONTROL ...

Last Modified: 9-16-2014

6.6 C

Doc ID: RM000002BQS0AXX

Model Year: 2015

Model: Tundra

Prod Date Range: [08/2014 - ]

Title: WINDSHIELD / WINDOWGLASS: POWER WINDOW CONTROL SYSTEM (w/ Jam Protection Function):

B2311; Power Window Motor Malfunction; 2015 MY Tundra [08/2014 - ]

DTC

B2311

Power Window Motor Malfunction

DESCRIPTION

The power window regulator motor is driven by operating the power window switch. The power window regulator

window regulator motor determines that the fully closed window position has deviated approximately 20 mm

(0.787 in.) or more from the normal position.

HINT:

DTC B2311 is set when the ECU for the front door power window regulator motor assembly LH or RH

malfunctions.

NOTICE:

When the power window regulator motor is reinstalled or replaced, the power window control system must
be initialized.
After a door glass or a door glass run has been replaced, the jam protection function may operate
unexpectedly when the auto up function is used. In such cases, the auto up function can be resumed by
repeating the following operation at least 5 times:

Close the power window by fully pulling up the power window switch and holding it in the auto

up position.

Open the power window by fully pushing down the switch.

Driver Side Motor

DTC

CODE

DTC DETECTION CONDITION

TROUBLE AREA

B2311

Either condition below is met:

The power window regulator motor malfunctions.

The ECU in the power window regulator motor

determines that the fully closed window position

has deviated approximately 20 mm (0.787 in.) or
