DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P0451

Evaporative Emission Control System Pressure

Sensor Range / Performance

Comes on

DTC

stored

-

P0452

Evaporative Emission Control System Pressure

Sensor / Switch Low Input

Comes on

DTC

stored

-

P0453

Evaporative Emission Control System Pressure

Sensor / Switch High Input

Comes on

DTC

stored

-

P0455

Evaporative Emission Control System Leak

Detected (Gross Leak)

Comes on

DTC

stored

-

P0456

Evaporative Emission Control System Leak

Detected (Very Small Leak)

Comes on

DTC

stored

-

P0500

Vehicle Speed Sensor "A"

Comes on

DTC

stored

Applies

P0504

Brake Switch "A" / "B" Correlation

-

DTC

stored

Applies

P0505

Idle Control System Malfunction

Comes on

DTC

stored

Applies

P050A

Cold Start Idle Air Control System Performance

Comes on

DTC

stored

-

P050B

Cold Start Ignition Timing Performance

Comes on

DTC

stored

-

P0550

Power Steering Pressure Sensor Circuit

Malfunction

Comes on

DTC

stored

Applies

P0552

Power Steering Pressure Sensor Circuit Low

Input

Comes on

DTC

stored

Applies

P0553

Power Steering Pressure Sensor Circuit High

Input

Comes on

DTC

stored

Applies

P0560

System Voltage

Comes on

DTC

stored

Applies

P0604

Random Access Memory (RAM)

Comes on

DTC

stored

Applies

P0606

ECM / PCM Processor

Comes on

DTC

stored

Applies

P0607

Control Module Performance

Comes on

DTC

stored

-

P060A

Internal Control Module Monitoring Processor

Performance

Comes on

DTC

stored

Applies

P060B

Internal Control Module A/D Processing

Performance

Comes on

DTC

stored

Applies

P060D

Internal Control Module Accelerator Pedal

Position Performance

Comes on

DTC

stored

Applies

P060E

Internal Control Module Throttle Position

Performance

Comes on

DTC

stored

Applies

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P0617

Starter Relay Circuit High

Comes on

DTC

stored

Applies

P062F

Internal Control Module EEPROM Error

Comes on

DTC

stored

Applies

P0630

VIN not Programmed or Mismatch - ECM / PCM

Comes on

DTC

stored

-

P0657

Actuator Supply Voltage Circuit / Open

Comes on

DTC

stored

Applies

P0724

Brake Switch "B" Circuit High

Comes on

DTC

stored

Applies

P101D

A/F Sensor Heater Circuit Performance Bank 1

Sensor 1 Stuck ON

Comes on

DTC

stored

Applies

P102D

O2 Sensor Heater Circuit Performance Bank 1

Sensor 2 Stuck ON

Comes on

DTC

stored

Applies

P103D

A/F Sensor Heater Circuit Performance Bank 2

Sensor 1 Stuck ON

Comes on

DTC

stored

Applies

P105D

O2 Sensor Heater Circuit Performance Bank 2

Sensor 2 Stuck ON

Comes on

DTC

stored

Applies

P106B

Evaporative Emission System Pressure Sensor -

Secondary Air Injection Pressure Sensor

Correlation

Comes on

DTC

stored

-

P1340

Camshaft Position Sensor "A" (Bank 1 Sensor 2) Comes on

DTC

stored

Applies

P1342

Camshaft Position Sensor "A" Low Input (MRE)

Comes on

DTC

stored

Applies

P1343

Camshaft Position Sensor "A" High Input (MRE)

Comes on

DTC

stored

Applies

P144C

Open in Secondary Air Injection System Heater

Control Circuit

Comes on

DTC

stored

Applies

P144D

Short in Secondary Air Injection System Heater

Control Circuit

Comes on

DTC

stored

Applies

P1603

Engine Stall History

-

DTC

stored

Applies

P1604

Startability Malfunction

-

DTC

stored

Applies

P1605

Rough Idling

-

DTC

stored

Applies

P1607

Cruise Control Input Processor

Comes on

DTC

stored

Applies

P1613

Secondary Air Injection Driver Malfunction

Comes on

DTC

stored

Applies

P1614

Secondary Air Injection System Driver Bank 2

Comes on

DTC

stored

Applies

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P2102

Throttle Actuator Control Motor Circuit Low

Comes on

DTC

stored

Applies

P2103

Throttle Actuator Control Motor Circuit High

Comes on

DTC

stored

Applies

P2109

Throttle / Pedal Position Sensor "A" Minimum

Stop Performance

-

DTC

stored

Applies

P2111

Throttle Actuator Control System - Stuck Open

Comes on

DTC

stored

Applies

P2112

Throttle Actuator Control System - Stuck Closed Comes on

DTC

stored

Applies

P2118

Throttle Actuator Control Motor Current Range /

Performance

Comes on

DTC

stored

Applies

P2119

Throttle Actuator Control Throttle Body Range /

Performance

Comes on

DTC

stored

Applies

P2120

Throttle / Pedal Position Sensor / Switch "D"

Circuit

Comes on

DTC

stored

Applies

P2121

Throttle / Pedal Position Sensor / Switch "D"

Circuit Range / Performance

Comes on

DTC

stored

Applies

P2122

Throttle / Pedal Position Sensor / Switch "D"

Circuit Low Input

Comes on

DTC

stored

Applies

P2123

Throttle / Pedal Position Sensor / Switch "D"

Circuit High Input

Comes on

DTC

stored

Applies

P2125

Throttle / Pedal Position Sensor / Switch "E"

Circuit

Comes on

DTC

stored

Applies

P2127

Throttle / Pedal Position Sensor / Switch "E"

Circuit Low Input

Comes on

DTC

stored

Applies

P2128

Throttle / Pedal Position Sensor / Switch "E"

Circuit High Input

Comes on

DTC

stored

Applies

P2135

Throttle / Pedal Position Sensor / Switch "A" /

"B" Voltage Correlation

Comes on

DTC

stored

Applies

P2138

Throttle / Pedal Position Sensor / Switch "D" /

"E" Voltage Correlation

Comes on

DTC

stored

Applies

P2195

Oxygen (A/F) Sensor Signal Stuck Lean (Bank 1

Sensor 1)

Comes on

DTC

stored

-

P2196

Oxygen (A/F) Sensor Signal Stuck Rich (Bank 1

Sensor 1)

Comes on

DTC

stored

-

P2197

Oxygen (A/F) Sensor Signal Stuck Lean (Bank 2

Sensor 1)

Comes on

DTC

stored

-

P2198

Oxygen (A/F) Sensor Signal Stuck Rich (Bank 2

Sensor 1)

Comes on

DTC

stored

-

P219A

Bank 1 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P219B

Bank 2 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P219C

Cylinder 1 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P219D

Cylinder 2 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P219E

Cylinder 3 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P219F

Cylinder 4 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P21A0

Cylinder 5 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P21A1

Cylinder 6 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P21A2

Cylinder 7 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P21A3

Cylinder 8 Air-Fuel Ratio Imbalance

Comes on

DTC

stored

-

P2237

Oxygen (A/F) Sensor Pumping Current Circuit /

Open (Bank 1 Sensor 1)

Comes on

DTC

stored

Applies

P2238

Oxygen (A/F) Sensor Pumping Current Circuit

Low (Bank 1 Sensor 1)

Comes on

DTC

stored

Applies

P2239

Oxygen (A/F) Sensor Pumping Current Circuit

High (Bank 1 Sensor 1)

Comes on

DTC

stored

Applies

P2240

Oxygen (A/F) Sensor Pumping Current Circuit /

Open (Bank 2 Sensor 1)

Comes on

DTC

stored

Applies

P2241

Oxygen (A/F) Sensor Pumping Current Circuit

Low (Bank 2 Sensor 1)

Comes on

DTC

stored

Applies

P2242

Oxygen (A/F) Sensor Pumping Current Circuit

High (Bank 2 Sensor 1)

Comes on

DTC

stored

Applies

P2252

Oxygen (A/F) Sensor Reference Ground Circuit

Low (Bank 1 Sensor 1)

Comes on

DTC

stored

Applies

P2253

Oxygen (A/F) Sensor Reference Ground Circuit

High (Bank 1 Sensor 1)

Comes on

DTC

stored

Applies

P2255

Oxygen (A/F) Sensor Reference Ground Circuit

Low (Bank 2 Sensor 1)

Comes on

DTC

stored

Applies

P2256

Oxygen (A/F) Sensor Reference Ground Circuit

High (Bank 2 Sensor 1)

Comes on

DTC

stored

Applies

P2401

Evaporative Emission Leak Detection Pump

Stuck OFF

Comes on

DTC

stored

-

P2402

Evaporative Emission Leak Detection Pump

Stuck ON

Comes on

DTC

stored

-
