Last Modified: 9-16-2014 6.6 A Doc ID: RM000002BG803KX Model Year: 2015 Model: Tundra Prod Date Range: [08/2014 - ] Title: 3UR-FBE COOLING: THERMOSTAT: REMOVAL; 2015 MY Tundra [08/2014 - ] REMOVAL HINT: If the thermostat was not installed, cooling efficiency would decrease. Even if the engine tends to overheat, do not remove the thermostat. 1. REMOVE NO. 1 ENGINE UNDER COVER 2. DRAIN ENGINE COOLANT 3. REMOVE V-BANK COVER SUB-ASSEMBLY 4. DISCONNECT OUTLET RADIATOR HOSE 5. REMOVE WATER INLET SUB-ASSEMBLY WITH THERMOSTAT (a) Disconnect the No. 2 and No. 3 air hoses. (b) Disconnect the air pump connector. (c) Disconnect the air pump connector clamp's holder. (d) Using a clip remover, detach the wire harness clamp. (e) Disconnect the No. 5 water by-pass hose. (f) Remove the air tube bracket bolt. (g) Remove the 3 nuts, water inlet with thermostat and gasket. 3UR-FBE COOLING: THERMOSTAT: REMOVAL; 2015 MY Tundra [... |
