Monitor runs whenever following DTCs not stored None Vehicle speed Less than 3 km/h (1.875 mph) Engine speed 400 to 1000 rpm Engine coolant temperature 75°C (167°F) or higher Air fuel ratio sensor status Activated Battery voltage 11 V or higher Fuel system status Closed loop TYPICAL MALFUNCTION THRESHOLDS P219A: Air Fuel Ratio Sensor Monitoring Method (Bank 1) A/F sensor monitoring method criteria 0.15 or more P219B: Air Fuel Ratio Sensor Monitoring Method (Bank 2) A/F sensor monitoring method criteria 0.2 or more P219C, P219D, P219E, P219F, P21A0, P21A1, P21A2, P21A3: Crankshaft Position Sensor Monitoring Method Crankshaft position sensor monitoring method criteria 1.0 or more MONITOR RESULT Refer to detailed information in Checking Monitor Status
. CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. 1. 1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: P219A-P219F... |
