Toyota Tundra (2015 year). Manual - part 1096





DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0343

Camshaft Position Sensor "A" Circuit High Input (Bank 1 or

Single Sensor)

Comes on

DTC

stored

P0345

Camshaft Position Sensor "A" Circuit (Bank 2)

Comes on

DTC

stored

P0347

Camshaft Position Sensor "A" Circuit Low Input (Bank 2)

Comes on

DTC

stored

P0348

Camshaft Position Sensor "A" Circuit High Input (Bank 2)

Comes on

DTC

stored

P0351

Ignition Coil "A" Primary / Secondary Circuit

Comes on

DTC

stored

P0352

Ignition Coil "B" Primary / Secondary Circuit

Comes on

DTC

stored

P0353

Ignition Coil "C" Primary / Secondary Circuit

Comes on

DTC

stored

P0354

Ignition Coil "D" Primary / Secondary Circuit

Comes on

DTC

stored

P0355

Ignition Coil "E" Primary / Secondary Circuit

Comes on

DTC

stored

P0356

Ignition Coil "F" Primary / Secondary Circuit

Comes on

DTC

stored

P0357

Ignition Coil "G" Primary / Secondary Circuit

Comes on

DTC

stored

P0358

Ignition Coil "H" Primary / Secondary Circuit

Comes on

DTC

stored

P0365

Camshaft Position Sensor "B" Circuit (Bank 1)

Comes on

DTC

stored

P0367

Camshaft Position Sensor "B" Circuit Low Input (Bank 1)

Comes on

DTC

stored

P0368

Camshaft Position Sensor "B" Circuit High Input (Bank 1)

Comes on

DTC

stored

P0390

Camshaft Position Sensor "B" Circuit (Bank 2)

Comes on

DTC

stored

P0392

Camshaft Position Sensor "B" Circuit Low Input (Bank 2)

Comes on

DTC

stored

P0393

Camshaft Position Sensor "B" Circuit High Input (Bank 2)

Comes on

DTC

stored

P0401

Exhaust Gas Recirculation Flow Insufficient Detected

Comes on

DTC

stored

P0403

Exhaust Gas Recirculation Control Circuit

Comes on

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0412

Secondary Air Injection System Switching Valve "A" Circuit

Comes on

DTC

stored

P0415

Secondary Air Injection System Switching Valve "B" Circuit

Comes on

DTC

stored

P0418

Secondary Air Injection System Control "A" Circuit

Comes on

DTC

stored

P0419

Secondary Air Injection System Relay "B" Circuit

Comes on

DTC

stored

P0420

Catalyst System Efficiency Below Threshold (Bank 1)

Comes on

DTC

stored

P0430

Catalyst System Efficiency Below Threshold (Bank 2)

Comes on

DTC

stored

P043E

Evaporative Emission System Leak Detection Reference Orifice

Low Flow

Comes on

DTC

stored

P043F

Evaporative Emission System Leak Detection Reference Orifice

High Flow

Comes on

DTC

stored

P0441

Evaporative Emission Control System Incorrect Purge Flow

Comes on

DTC

stored

P0451

Evaporative Emission Control System Pressure Sensor Range /

Performance

Comes on

DTC

stored

P0452

Evaporative Emission Control System Pressure Sensor / Switch

Low Input

Comes on

DTC

stored

P0453

Evaporative Emission Control System Pressure Sensor / Switch

High Input

Comes on

DTC

stored

P0455

Evaporative Emission Control System Leak Detected (Gross

Leak)

Comes on

DTC

stored

P0456

Evaporative Emission Control System Leak Detected (Very Small

Leak)

Comes on

DTC

stored

P0500

Vehicle Speed Sensor

Comes on

DTC

stored

P0504

Brake Switch "A" / "B" Correlation

-

DTC

stored

P0505

Idle Control System

Comes on

DTC

stored

P050A

Cold Start Idle Air Control System Performance

Comes on

DTC

stored

P050B

Cold Start Ignition Timing Performance

Comes on

DTC

stored

P0550

Power Steering Pressure Sensor Circuit

Comes on

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P0552

Power Steering Pressure Sensor / Switch Circuit Low Input

Comes on

DTC

stored

P0553

Power Steering Pressure Sensor / Switch Circuit High Input

Comes on

DTC

stored

P0560

System Voltage

Comes on

DTC

stored

P0604

Random Access Memory (RAM)

Comes on

DTC

stored

P0606

ECM / PCM Processor

Comes on

DTC

stored

P0607

Control Module Performance

Comes on

DTC

stored

P060A

Internal Control Module Monitoring Processor Performance

Comes on

DTC

stored

P060B

Internal Control Module A/D Processing Performance

Comes on

DTC

stored

P060D

Internal Control Module Accelerator Pedal Position Performance

Comes on

DTC

stored

P060E

Internal Control Module Throttle Position Performance

Comes on

DTC

stored

P0617

Starter Relay Circuit High

Comes on

DTC

stored

P062F

Internal Control Module EEPROM Error

Comes on

DTC

stored

P0630

VIN not Programmed or Mismatch - ECM / PCM

Comes on

DTC

stored

P0657

Actuator Supply Voltage Circuit / Open

Comes on

DTC

stored

P0724

Brake Switch "B" Circuit High

Comes on

DTC

stored

P101D

A/F Sensor Heater Circuit Performance Bank 1 Sensor 1 Stuck

ON

Comes on

DTC

stored

P102D

O2 Sensor Heater Circuit Performance Bank 1 Sensor 2 Stuck

ON

Comes on

DTC

stored

P103D

A/F Sensor Heater Circuit Performance Bank 2 Sensor 1 Stuck

ON

Comes on

DTC

stored

P105D

O2 Sensor Heater Circuit Performance Bank 2 Sensor 2 Stuck

ON

Comes on

DTC

stored

P106A

Evaporative Emission System Pressure Sensor - Manifold

Absolute Pressure Correlation

Comes on

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

SEE

PAGE

P106B

Evaporative Emission System Pressure Sensor - Secondary Air

Injection Pressure Sensor Correlation

Comes on

DTC

stored

P1340

Camshaft Position Sensor "A" (Bank 1 Sensor 2)

Comes on

DTC

stored

P1342

Camshaft Position Sensor "A" Low Input (MRE)

Comes on

DTC

stored

P1343

Camshaft Position Sensor "A" High Input (MRE)

Comes on

DTC

stored

P144C

Open in Secondary Air Injection System Heater Control Circuit

Comes on

DTC

stored

P144D

Short in Secondary Air Injection System Heater Control Circuit

Comes on

DTC

stored

P1603

Engine Stall History

-

DTC

stored

P1604

Startability Malfunction

-

DTC

stored

P1605

Rough Idling

-

DTC

stored

P1607

Cruise Control Input Processor

Comes on

DTC

stored

P1613

Secondary Air Injection System Driver

Comes on

DTC

stored

P1614

Secondary Air Injection System Driver Bank 2

Comes on

DTC

stored

P2102

Throttle Actuator Control Motor Circuit Low

Comes on

DTC

stored

P2103

Throttle Actuator Control Motor Circuit High

Comes on

DTC

stored

P2109

Throttle / Pedal Position Sensor "A" Minimum Stop Performance

-

DTC

stored

P2111

Throttle Actuator Control System - Stuck Open

Comes on

DTC

stored

P2112

Throttle Actuator Control System - Stuck Closed

Comes on

DTC

stored

P2118

Throttle Actuator Control Motor Current Range / Performance

Comes on

DTC

stored

P2119

Throttle Actuator Control Throttle Body Range / Performance

Comes on

DTC

stored

P2120

Throttle / Pedal Position Sensor / Switch "D" Circuit

Comes on

DTC

stored

1UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...
