Toyota Hilux (2017 year). Manual - part 159

644

9-1. Specifications

*

1

: If equipped

*

2

: The wattage differs depending on the specification. When replacing, use a

light bulb with the same wattage as the original bulb.

Light bulbs

Light bulbs

W

Type

Exterior

Headlights

High/low beams (halogen headlights)
High beams (LED headlights)

60/55

60

A
B

Front fog lights

*

1

19

C

Front position lights (halogen headlights)

Without daytime running lights
With daytime running lights

5

21/5

D
D

Front turn signal lights

Halogen headlights
LED headlights

21
21

E
F

Rear turn signal lights

21

E

Back-up lights

21

G

Rear fog light

*

1

21

G

License plate light

5

D

Stop/tail lights

21/5

G

Interior

Interior light

*

1

8

H

Personal/interior lights

5 or 8

*

2

D

A: H4 halogen bulbs

B: HB3 halogen bulbs

C: H16 halogen bulbs

D: Wedge base bulbs (clear)

E: Single end bulbs (amber)

F: Wedge base bulbs (amber)

G: Single end bulbs (clear)

H: Double end bulbs

645

9-1. Specifications

9

V

eh

icl

e s
pe

cif

ic

at

io

ns

Fuel information

◆

Gasoline engine

You must only use unleaded gasoline.
Select unleaded gasoline with a Research Octane Number of 91 or
higher for optimum engine performance.

◆

Diesel engine

X

EU area:

You must only use diesel fuel conforming to European standard
EN590.

X

Except EU area (except Russia):

You must only use diesel fuel with a cetane number of 48 or higher.

X

Except EU area (Russia):

You must only use diesel fuel with a cetane number of 48 or higher.
Your vehicle must use only diesel fuel conforming to GOST
R52368-2005.

■

Use of ethanol blended gasoline in a gasoline engine
Toyota allows the use of ethanol blended gasoline where the ethanol content
is up to 10%. Make sure that the ethanol blended gasoline to be used has a
Research Octane Number that follows the above.

■

If you plan to drive in foreign countries (vehicles with DPF system)
Low sulfur diesel fuel may not be available, so please check the availability
with your distributor.

■

If your engine knocks

●

Consult any authorized Toyota dealer or repairer, or another duly qualified
and equipped professional.

●

You may occasionally notice light knocking for a short time while accelerat-
ing or driving uphill. This is normal and there is no need for concern.

646

9-1. Specifications

NOTICE

■

Notice on gasoline fuel quality

●

Do not use improper fuels. If improper fuels are used, the engine will be
damaged.

●

Do not use leaded gasoline.
Leaded gasoline will cause the three-way catalytic converter to lose its
effectiveness and the emission control system to function improperly.

●

Do not use the methanol blended gasoline such as M15, M85, M100. The
use of gasoline containing methanol may cause engine damage or failure.

●

For Kazakhstan: Bioethanol fuel sold under names such as “E50” or “E85”
and fuel containing a large amount of ethanol should not be used. Your
vehicle can use gasoline mixed with 10% max ethanol. The use of fuel
with more than 10% ethanol content (E10) will damage the vehicle’s fuel
system. You must ensure that refueling is carried out only from a source
where fuel specification and quality can be guaranteed. In case of any
doubt, ask any authorized Toyota dealer or repairer, or another duly quali-
fied and equipped professional.

■

Notice on diesel fuel quality

●

Do not use improper fuels. If improper fuels are used, the engine will be
damaged.

●

EU area: FAME (Fatty Acid Methyl Ester) fuel sold under names such as
“B30” or “B100” and fuel containing a large amount of FAME should not be
used. The use of these fuels will damage the vehicle’s fuel system. In case
of any doubt, ask any authorized Toyota dealer or repairer, or another duly
qualified and equipped professional.

647

9

9-1. Specifications

V

eh

icl

e s
pe

cif

ic

at

io

ns

NOTICE

●

Except EU area (except Russia and models for model code destination V
and Blank

*

): FAME (Fatty Acid Methyl Ester) fuel sold under names such

as “B30” or “B100” and fuel containing a large amount of FAME should not
be used. Your vehicle can use diesel mixed with 5% max biodiesel FAME
(B5). The use of fuel with more than 5% FAME content (B5) will damage
the vehicle’s fuel system. You must ensure that refueling is carried out only
from a source where fuel specification and quality can be guaranteed.
In case of any doubt, ask any authorized Toyota dealer or repairer, or
another duly qualified and equipped professional.

●

Except EU area (Russia): FAME (Fatty Acid Methyl Ester) fuel sold under
name such as “B30” or “B100” and fuel containing a large amount of
FAME should not be used.
The use of these fuel will damage the vehicle’s fuel system. In case of any
doubt, ask any authorized Toyota dealer or repairer, or another duly quali-
fied and equipped professional.

*

: See “Checking your vehicle’s model” if you are not sure of which model

your vehicle is. (

→P. 11)
