347

4-5. Using the driving support systems

4

D

riv

in

g

■

Hood

●

If the hood is opened while the engine is stopped by the Stop & Start sys-
tem, the engine may not be restarted by the Stop & Start system or by the
automatic engine start function. In this case, shift the shift lever to P (vehi-
cles with automatic transmission) or N (vehicles with manual transmission)
and restart the engine with the engine switch operation. (

→P. 236, 239)

●

Even if the hood is closed after the engine is started with the hood open, the
Stop & Start system does not operate. Close the hood, turn the engine
switch to the “LOCK” position (vehicles without smart entry & start system)
or off (vehicles with smart entry & start system), wait 30 seconds or more,
and then start the engine.

■

Steering wheel operation
When the engine is stopped by the Stop & Start system, the steering wheel
may become heavier than when driving.

■

When to use the Stop & Start system

●

Use the Stop & Start system when stopping the vehicle temporarily at red
lights, intersections, etc. When stopping the vehicle for a longer period of
time, turn off the engine completely.

●

When the system cannot operate, is canceled, or is malfunctioning, warning
messages and the warning buzzer are used to inform the driver. (

→P. 349)

●

Even if an attempt is made to start the engine during an engine stop, the
engine does not automatically restart. Start the engine by shifting the shift
lever to P (vehicles with automatic transmission) or N (vehicles with manual
transmission) and performing a normal engine start operation.

●

When the engine restarts after having been stopped by the Stop & Start sys-
tem, the power outlet may be temporarily unusable, but this is not a mal-
function.

●

Installation and removal of electrical components and wireless devices may
affect the Stop & Start system, contact any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.

■

If the windshield is fogged up while the engine is stopped by the Stop &
Start system

X

Vehicles with manual air conditioning system:

Restart the engine by pressing the Stop & Start cancel switch, and then set

the air outlet selection dial to

. (

→P. 449)

X

Vehicles with automatic air conditioning system:

Turn the windshield defogger on. (The engine will start due to the automatic
engine start function.) (

→P. 458)

If the windshield fogs up frequently, press the Stop & Start cancel switch to
deactivate the system.

348

4-5. Using the driving support systems

■

Air conditioning system while the engine is stopped by the Stop & Start
system
While the engine is stopped by the Stop & Start system, the air conditioning
system (cooling, heating and dehumidifying functions) is cancelled and it only
blows air or stops blowing air. In order to prevent the air conditioning system
from being cancelled, deactivate the Stop & Start system by pressing the Stop
& Start cancel switch.

■

If an odor comes from the air conditioning system while the engine is
stopped by the Stop & Start system
Vehicles with manual air conditioning system:
If the idling stop time is set to “Long”, change the setting to “Normal”. If an
odor occurs even when “Normal” is selected, press the Stop & Start cancel
switch to deactivate the Stop & Start system.
Vehicles with automatic air conditioning system:
Press the Stop & Start cancel switch to deactivate the Stop & Start system.

■

Switching the idling stop time with the air conditioning system on
When the air conditioning system is on, the Stop & Start system idling stop
time can be adjusted by performing the following operation.

Use the meter control switches to select

 while the vehicle is stopped

and press

, and select

 and press

.

Select “Normal” or “Long”, and then press

.

■

The Stop & Start system protection feature

●

When an excessively loud sound is being projected by the audio system,
the audio system may be automatically cut off in order to reduce battery
consumption. If it occurs, turn the engine switch to the “LOCK” position
(vehicles without smart entry & start system) or off (vehicles with smart entry
& start system), wait for 3 seconds or longer and then turn it to the “ACC” or
“ON” position (vehicles without smart entry & start system), or ACCES-
SORY mode or IGNITION ON mode (vehicles with smart entry & start sys-
tem) to re-enable the audio system.

●

The audio system may not be activated when the battery terminals are dis-
connected and then reconnected. If it occurs, turn the engine switch to the
“LOCK” position (vehicles without smart entry & start system) or off (vehicles
with smart entry & start system), and then repeat the following operation
twice to activate the audio system normally.
• Turn the engine switch to the “ON” position (vehicles without smart entry

& start system), or IGNITION ON mode (vehicles with smart entry & start
system), and then to the “LOCK” position (vehicles without smart entry &
start system) or off (vehicles with smart entry & start system).

1

2

349

4-5. Using the driving support systems

4

D

riv

in

g

■

Replacing battery
→P. 610

■

Displaying the Stop & Start system status
Operation status of the Stop & Start system can be displayed on the
(Drive information) screen of multi-information display. (

→P. 139)

The display of “After Reset” can be reset.

●

To reset the display, press

 of the meter control switches, press “<” or “>”

to select “Reset”, and then press and hold

.

●

To stop the reset procedure, press

.

■

Multi-information display messages
When the engine cannot be stopped by the Stop & Start system, and when
the engine automatically restarts while stopped by the Stop & Start system,
the following messages are displayed on the multi-information display.

●

When the engine cannot be stopped by the Stop & Start system

Smart Stop

Displays the current engine stop time. Also, the
engine stop time when the air conditioning sys-
tem is on can be adjusted using the meter con-
trol switches. (

→P. 348)

After Start

Displays the cumulative time that the engine is
stopped by the Stop & Start system from when
the engine is started until the engine is stopped.

After Reset

Displays the cumulative time that the engine is
stopped by the Stop & Start system from the
previous reset until the system is reset again.

Message

Details/Actions

“Depress brake
firmly to activate”

The brake pedal is not depressed enough.

→ Operates when the brake pedal is

depressed further after stopping the
vehicle.

“For climate con-
trol”

Vehicles with automatic air conditioning sys-
tem:
• The air conditioning system is being used

when the ambient temperature is high or
low.

→ Readily operates when the difference

between the set temperature and cabin
temperature is small.

•

 is pressed.

350

4-5. Using the driving support systems

“Battery charging”

• The battery charge amount may be low.

→ Engine stop is temporarily prohibited

to prioritize charging of the battery, but
if the engine is operated for a short
while, engine stop is allowed.

• A refresh charge may be occurring (Exam-

ples: A short time after replacing the bat-
tery, removing battery terminals, etc.)

→ After a refresh charge of approximately

5 to 40 minutes completes, the system
can be operated.

• The engine may have been started with

the hood opened.

→ Close the hood, turn the engine switch

to the “LOCK” position (vehicles with-
out smart entry & start system) or off
(vehicles with smart entry & start sys-
tem), wait 30 seconds or more, and
then start the engine.

• The battery may be cold.

→ Operating the engine for a short while

allows the system to recover due to
the temperature increase in the engine
compartment.

• The battery may be extremely hot.

→ If the engine is stopped and the engine

compartment is allowed to cool suffi-
ciently, the system recovers.

“For brake
system”

• The brake booster load decreased.
• The vehicle is operated at a high elevation.

→ When a predetermined load is gener-

ated by the brake booster, the system
recovers.

“Driver seat belt
unbuckled”

The driver seat belt is not fastened.

“Non-dedicated
battery”

A non-dedicated battery for the Stop & Start
system may have been installed.

→ The Stop & Start system does not

operate. Have the vehicle inspected by
any authorized Toyota dealer or
repairer, or another duly qualified and
equipped professional.

Message

Details/Actions
